Projection (PRJ) Mode

The projector can use any of the 4 projection modes shown in the diagram below. Select the mode
most appropriate for the projection setting in use. (You can set the PRJ mode in "SCR-ADJ" menu.
See page 42.)
■ Table mounted, front projection
[Menu item ➞ "Front"]
■ Table mounted, rear projection
(with a translucent screen)
[Menu item ➞ "Rear"]
Indication of the Projection Image Size and Projection Distance
Example: NORMAL Mode (4:3)
Picture Size
300"
200"
100"
84"
60"
■ Ceiling mounted, front projection
[Menu item ➞ "Ceiling + Front"]
■ Ceiling mounted, rear projection
(with a translucent screen)
[Menu item ➞ "Ceiling + Rear"]
Projection
Distance
19
