PartsGuide
Note:
The reference numbers on the PWB are arranged
in alphabetical order.
[1]
[2]
[3]
[4]
Parts marked with "
parts with specified ones for maintaining the safety and performance of the set.
PARTS GUIDE
CONTENTS
" are important for maintaining the safety of the set. Be sure to replace these
No. S77O5PG-F200X
DATA PROJECTOR
MODEL
[5]
[6]
[7]
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
PG-F200X

Advertisement

loading

Related Manuals for Sharp PG-F200X

Summary of Contents for Sharp PG-F200X

  • Page 1: Table Of Contents

    PG-F200X PartsGuide PARTS GUIDE No. S77O5PG-F200X DATA PROJECTOR PG-F200X MODEL Note: The reference numbers on the PWB are arranged in alphabetical order. CONTENTS PRINTED WIRING BOARD SUPPLIED ACCESSORIES ASSEMBLIES PACKING PARTS DUNTKE153FMF8 (MAIN Unit) (NOT REPLACEMENT ITEM) CABINET AND MECHANICAL...

  • Page 2: Printed Wiring Board Assemblies

    PG-F200X PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLIES BALLAST POWER Ass'y (with Ballast Control Unit) DSETUE149FMG0 BALLAST POWER Unit *Order the BALLAST POWER Ass'y (DSETUE149FMG0) when Not Available replacing ballast power unit (DUNTKE149WEF0). BALLAST CONTROL Unit...

  • Page 3: Cabinet And Mechanical Parts

    PG-F200X [3] CABINET AND MECHANICAL PARTS 2-11 2-10 2-1-3 2-1-1 2-1-2...
  • Page 4 PG-F200X PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] CABINET AND MECHANICAL PARTS Top Body Ass'y CBDYTA268WEF0 Top Body Not Available Cover GCOVAC364WJSA Decoration Plate HDECPA034WJSA Indicator HiNDPC319WJSC Cover GCOVAC242WJKC Bottom Body Ass'y CBDYUA309WEF0 Lamp Door Ass'y CDORUA075WEF0 2-1-1...

  • Page 5: Optical Mechanism Parts

    PG-F200X [4] OPTICAL MECHANISM PARTS 4-33 4-33 4-11 4-33 4-27 4-33 4-33 4-25 4-16 4-24 4-29 4-36 4-33 4-34 4-33 4-13 4-34 4-33 4-33 4-12 4-33 4-33 4-31 4-33 4-31 4-31 4-26 4-33 4-31 4-31 4-31 4-31 4-28 4-18 4-33...

  • Page 6: Pg-F200X

    PG-F200X PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] OPTICAL MECHANISM PARTS Fixing Metal LANGKB121WJFW Chassis LCHSKA024WJFW Holder LHLDZA845WJKZ Screw (For Focus Ring), x3 LX-EZA027WJFN Spring MSPRPA095WJFW Spring MSPRPA103WJFW Spring MSPRPA097WJFW NFANRA077WJ00 Cover PCOVPA036WJSB 4-10 PCOVPA038WJSB Cover 4-11 PCOVZA089WJFW...

  • Page 7: Supplied Accessories

    PG-F200X [5] SUPPLIED ACCESSORIES PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] SUPPLIED ACCESSORIES CCAPHA027WJSA Lens Cap AC Cord (for U.K. and Singapore) QACCBA036WJPZ AC Cord (for U.S.A. and Canada, etc.) QACCDA007WJPZ AC Cord (for Europe, except U.K.) QACCVA011WJPZ...

  • Page 8: Packing Parts (Not Replacement Item)

    PG-F200X [6] PACKING PARTS (NOT REPLACEMENT ITEM)

  • Page 9: Service Jigs And Equipment (Use For Servicing)

    PG-F200X PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [6] PACKING PARTS (NOT REPLACEMENT ITEM) Packing Add SPAKAA329WJZZ Packing Case SPAKCD814WJZZ Accessory Case SPAKFB224WJZZ Wrapping Paper SPAKPA869WJZZ Packing Add SPAKXB477WJZZ Polyethylene Bag SSAKA0160CEZZ Model Name Label TLABV0003SEZZ Bar Code Label (for U.S.A., Canada, Australia, New Zealand and Oceania) TLABVA333WJZZ C.W.
