Non-operating Shock and Vibration Specifications

Non-operating Shock
Specifications
Table 16 Non-operating
(Unpackaged) Shock
Specifications
Non-operating Packaged
Vibration Specifications
Table 17 Random Survival
Non-operating (Packaged)
Vibration Specifications
DLT-V4 Product Specification
Table 16 lists the shock specifications for the tape drive without its
shipping package (non-operating).
6
Specification
Pulse Shape
Peak Acceleration
Duration
Application
Table 17, table 18, and
drive in its shipping package (non-operating).
6
Factor
Frequency
Range
Acceleration
Level
Application
Chapter 6 Shock and Vibration Specifications
Non-operating Shock and Vibration Specifications
40 G Shock
Square Wave
40 G
10 ms
X, Y, and Z axis, twice
in each axis (once in
each direction)
table 19 list the vibration specifications for the tape
Criteria Comments
5 to 200 Hz
1.46 G
rms
X, Y, and Z axis 30 minutes per axis
142 G Shock
½ Sine Pulse
142 G
2 ms
X, Y, and Z axis, twice
in each axis (once in
each direction)
6
