PRESONUS STUDIOLIVE 24.4.2 Owner's Manual page 124

8 Tutorials
8.2 A Brief Tutorial on Dynamics Processing
Expansion
124
Attack. Attack sets the speed at which the compressor acts on the
input signal. A slow attack time allows the beginning envelope of a
signal (commonly referred to as the initial transient ) to pass through the
compressor unprocessed, whereas a fast attack time immediately subjects
the signal to the ratio and threshold settings of the compressor.
Release. Release sets the length of time the compressor takes to return the
gain reduction back to zero (no gain reduction) after the signal level drops
below the compression threshold. Very short release times can produce
a very choppy or "jittery" sound, especially in low-frequency instruments
such as bass guitar. Very long release times can result in an overcompressed
sound; this is sometimes referred to as "squashing" the sound. All ranges
of release can be useful at different times, however, and you should
experiment to become familiar with the different sonic possibilities.
Hard/Soft Knee. With hard-knee compression, the gain reduction applied to the
signal occurs as soon as the signal exceeds the level set by the threshold. With soft-
knee compression, the onset of gain reduction occurs gradually after the signal
has exceeded the threshold, producing a more musical response (to some folks).
Auto. Places a compressor in automatic attack and release
mode. The attack and release knobs become inoperative and
a preprogrammed attack and release curve is used.
Makeup Gain. When compressing a signal, gain reduction usually results
in an overall reduction of level. The gain control allows you to restore
the loss in level due to compression (like readjusting the volume).
Compressor Sidechain. The sidechain jack interrupts the signal that the
compressor is using to determine the amount of gain reduction it should apply.
When no connector is inserted into this jack, the input signal goes directly to the
compressor's control circuitry. When a connector is inserted into this jack, the
signal path is broken. The control signal can then be processed by an equalizer,
for example, to reduce sibilance (de-essing) in a vocal track. The control signal
is then returned to the unit via the connector. One common application for
a sidechain is when using a compressor to reduce the level of music or other
background sound whenever a narrator speaks or vocalist sings, allowing the
voice to be clearly heard. In this application, the vocal signal is routed to the
sidechain input, while the music is routed through the main compression
circuitry. Now the compressor will automatically duck—that is, reduce the
level of—the music whenever the narrator speaks or the vocalist sings.
There are two basic types of expansion: dynamic and downward.
Expansion increases the dynamic range of a signal after the signal crosses
the expansion threshold. Dynamic expansion is basically the opposite
of compression. In fact, broadcasters use dynamic expansion to "undo"
compression before transmitting the audio signal. This is commonly
referred to as companding ' or COMPression followed by expANDING .
By far the most common use of expansion is downward expansion . In contrast
to compression, which decreases the level of a signal after it rises above the
compression threshold, expansion decreases the level of a signal after the
signal goes below the expansion threshold. The amount of level reduction is
PreSonus StudioLive 24.4.2
™
