  • Page 1 Outdoor LoRaWAN Gateway ® UG67 Quick Start Guide...
  • Page 2 The related documents are available on Milesight website: https://www.milesight-iot.com Declaration of Conformity UG67 is in conformity with the essential requirements and other relevant provisions of the CE, FCC, and RoHS. For assistance, please contact Milesight technical support: Email: iot.support@milesight.com...
  • Page 3 Revision History Date Doc Version Description October 30, 2020 V1.0 Initial version May 6, 2021 V1.1 Delete optional mark of LoRa antennas, add DC pinouts July 29, 2021 V1.2 Add antenna accessories and installation method 1. Delete Ethernet cable Oct. 31, 2022 V1.3 2.
  • Page 4 5.2 Configure the Cellular Connection (Cellular Version Only) ............. 17 5.3 Configure the Wi-Fi Connection ......................18 6.Packet Forwarder Configuration ........................21 7.Network Server Configuration ........................22 7.1 Connect to Milesight IoT Cloud ......................22 7.2 Add End Devices ..........................24 7.3 Connect to MQTT/HTTP Server ......................27...
  • Page 5 1. Packing List Before you begin to install the UG67 LoRaWAN ® Gateway, please check the package contents to verify that you have received the items below. 1 × UG67 1 × PoE Injector 1 × Mounting Bracket 4 × Wall Mounting Kits 2 ×...
  • Page 6 (Already Mounted) 0.7 N.m LED/Interface Cover (Clear) 0.7 N.m SIM Dust Cover (Black) 1.1 N.m Cable Gland 2.2 DC Power Connector UG67 supports 6-12 V or solar supply via M12 connector. Cable Color Description Black White Reserved Yellow Reserved +12V 2.3 LED Indicators...
  • Page 7 2.4 Reset Button Description Function SYS LED Action Static Green Press and hold the reset button for more than 5 seconds. Static Green → Reset Release the button and wait. Rapidly Blinking Off → Static Green The gateway resets to factory default. 2.5 Dimensions (mm) 3.
  • Page 8 2. Insert the SIM card into the device according to the direction icon on the device. If you need to take out the SIM card, press into the SIM card and it will pop up automatically. 3. Tighten the SIM dust cover with wrench to prevent water into the device. Note: Ensure the tightening torque is not more than 1.6 N.m.
  • Page 9 PoE injector: 3.4 Gateway Installation UG67 can be mounted to a wall or a pole. Before you start, make sure that your SIM card has been inserted and all cables have been installed. Note: Do not connect device to power supply or other devices when installing.
  • Page 10 5. Hang the device to the mounting bracket via bracket mounting screws on the back of device, then screw the bracket screw to the bottom of the device. Note: It is suggested to install the gateway at the top of the wall to ensure there are not walls around the antennas to affect the signal.
  • Page 11 2. Pass one antenna through the U-strap and attach the U-strap clamp to the short mounting backboard with 2 screws at back of the board. Then screw flat washers, spring washers and nuts onto the front of the board. 3. Slide hose clamps through the rectangular rings in the mounting bracket and short mounting backboard, then wrap them around the pole.
  • Page 12 then screw the bracket screw to the bottom of the gateway. 5. Fix one antenna to the ANT2 connector of gateway directly, then connect the remaining antenna on the short mounting backboard to the gateway with the coaxial cable. 3.5 Antenna Installation The gateway supports to install antennas by following methods.
  • Page 13 3. Connect the antenna on the pole to the ANT1 connector of gateway with a coaxial cable. Note: 1) Both antennas can also be installed before gateway installation. 2) The antennas should be installed vertically always on a site with a good signal. 3) It is suggested to keep two antennas at least 35cm to avoid interference.
  • Page 14 Cable Connector: 3.7 Lightning Protection Take lighting protection measures, including but not limited to: Connect the gateway to the earth ground.  Add lightning arresters on the antenna connectors.  Add PoE surge protectors between gateway and the PoE injector/switch as required. ...
  • Page 15 4. Login the Web GUI UG67 provides a web-based configuration interface for management. If this is the first time you configure the gateway, please use the default settings below: Username: admin Password: password 1. Enable Wireless Network Connection on your computer and search for access point “Gateway_******”...
  • Page 16 3. After logging the web GUI, you can view system information and perform configuration of the gateway. It’s suggested that you change the password for the sake of security. 5. Network Connection This section explains how to connect the gateway to network via WAN connection, Wi-Fi or cellular. 5.1 Configure the Ethernet Connection 1.
  • Page 17 Note: If there is IP conflict when changing the IP address of Ethernet port, please change the subnet of WLAN first. 2. Connect Ethernet port of gateway to devices like router or modem. 3. Go to Maintenance > Tools > Ping to check network connectivity. 5.2 Configure the Cellular Connection (Cellular Version Only) 1.
  • Page 18 2. Go to Status > Cellular page to view the status of the cellular connection. If it shows “Connected”, it means the SIM has dialed up successfully. On the other hand, you can check the status of LTE indicator. If it keeps on light statically, it means SIM has dialed up successfully. 5.3 Configure the Wi-Fi Connection...
  • Page 19 Go to Network > Interface > Port page to select connection type as Static IP and configure an IP address for the Ethernet WAN port. Connect PC to UG67 ETH port directly or through PoE injector. Assign the IP address to computer manually. Take Windows 10 system as an example: Open a Web browser and type in the IP address of the Ethernet port to access the web GUI.
  • Page 20 Click Save and Apply buttons after all configurations are done. Go to Status > WLAN to check the connection status of the client. If it shows “Connected”, it means gateway connects to Wi-Fi successfully. Go to Network > Failover > WAN Failover to switch the wlan0 as main interface, then gateway can use the Wi-Fi to access the network.
  • Page 21 6.Packet Forwarder Configuration UG67 has installed multiple packet forwarders including Semtech, Chirpstack, etc. This section explains how to connect the gateway to network servers. Make sure the gateway connects to the network as shown in Section 1. Go to Packet Forwarder > General page and click to add a network server.
  • Page 22 ® Make sure the gateway connects to the network as shown in Section 7.1 Connect to Milesight IoT Cloud 1. Go to Packet Forwarder > General page to enable the embedded network server.
  • Page 23 Note: after this mode is enabled, the other settings of network server will be not allowed to edit. 4. Log in the Milesight IoT Cloud. Then go to My Devices page and click “+New Devices” to add gateway to Milesight IoT Cloud via SN. Gateway will be added under “Gateways” menu.
  • Page 24 The gateway is online on Milesight IoT Cloud. 7.2 Add End Devices 1. Go to Packet Forwarder > General page to enable the embedded network server. 2. Go to Packet Forwarder > Radio page to select the center frequency and channels. The channels of...
  • Page 25 3. Go to Network Server > General page to enable the network server mode. 4. Go to Network Server > Application to add a new application.
  • Page 26 6. Fill in the information of the end device and click Save&Apply. The information can be found on the end device’s configuration page or from manufacturer’s manuals. Here are the default settings of Milesight end devices: Device EUI: this can be found on the device.
  • Page 27 Click Details to check the properties and payload contents of packets. 7.3 Connect to MQTT/HTTP Server The gateway supports choosing the data transport protocol to send the data of device within this application to third-party servers. One application supports to add a MQTT transmission or a HTTP (HTTPS) transmission at most.
  • Page 28 Enter the header name and header value if there is user credentials when accessing the HTTP(s) server. MQTT： Step 1: select the transmission protocol as MQTT. Step 2: Fill in MQTT broker general settings. Step 3: Select the authentication method required by the server. If you select user credentials for authentication, you need to enter the username and password for authentication.
  • Page 29 If certificate is necessary for verification, please select mode and import CA certificate, client certificate and client key file for authentication. Step 4: Enter the topics to receive data or send downlinks, and choose the QoS. [END]...
