  • Page 1 Mini LoRaWAN Gateway ® UG63 User Guide...
  • Page 2 UG63 Datasheet Datasheet for UG63 LoRaWAN ® gateway. UG63 Quick Start Guide Quick Installation Guide for UG63 LoRaWAN ® gateway. Declaration of Conformity UG63 is in conformity with the essential requirements and other relevant provisions of the CE, FCC, and RoHS.
  • Page 3 For assistance, please contact Milesight technical support: Email: iot.support@milesight.com Tel: 86-592-5085280 Fax: 86-592-5023065 Address: Building C09, Software Park III, Xiamen 361024, Fujian, China Revision History Date Doc Version Description Mar. 18, 2022 V1.0 Initial version...

  • Page 4: Table Of Contents

    Contents Chapter 1 Product Introduction......................6 1.1 Overview..........................6 1.2 Advantages..........................6 1.3 Specifications........................7 1.4 Dimensions..........................8 Chapter 2 Access to Web GUI......................9 Chapter 3 Web Configuration......................11 3.1 Status............................11 3.1.1 Overview........................11 3.1.2 Network........................12 3.1.3 VPN..........................12 3.2 LoRaWAN..........................14 3.2.1 Packet Forwarder....................
  • Page 5 4.1.1 Via Web Interface....................71 4.1.2 Via Hardware......................72 4.2 Firmware Upgrade......................72 4.3 Ethernet Connection......................73 4.4 Packet Forwarder Configuration..................74 4.5 Connect to Milesight IoT Cloud..................75 4.6 Application Configuration....................77 4.7 Device Configuration......................80 4.8 Send Data to Device......................81 4.9 Connect to UG65/UG67 Gateway..................83...

  • Page 6: Chapter 1 Product Introduction

    It also applies to provide coverage for indoor blind spots. UG63 has integrated with mainstream network servers (such as TTI, ChirpStack, etc.) and Milesight IoT Cloud. Besides, it also supports a built-in network server for easy deployment.

  • Page 7: Specifications

    Milesight DeviceHub provides easy setup, bulk configuration, and centralized management of remote devices The user-friendly web interface design and various upgrading options help administrator to manage the device as easy as pie Web GUI and CLI enable the admin to achieve quick configuration and simple...

  • Page 8: Dimensions

    PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, DDNS, HTTP, HTTPS, DNS, Network Protocols SNTP, Telnet, SSH, MQTT, etc. VPN Tunnel DMVPN/IPsec/OpenVPN/PPTP/L2TP/GRE Management Web, CLI, DeviceHub, Milesight IoT Cloud, Yeastar Workplace Platform Power Supply and Consumption 1. 1 × 802.3 af PoE input Power Supply 2. 5V by Type-C Port Consumption Max 3.3 W...

  • Page 9: Chapter 2 Access To Web Gui

    Username: admin Password: password Connect PC to UG63 ETH port directly or through PoE injector to access the web GUI of gateway. The following steps are based on Windows 10 system for your reference. 1. Go to “Control Panel” → “Network and Internet” → “Network and Sharing Center”, then click “Ethernet”...
  • Page 10 If you enter the username or password incorrectly more than 5 times, the login page will be locked for 10 minutes. 5. After logging in the web GUI, you can view system information and perform configuration of the gateway. It’s suggested that you change the password for the sake of security.

  • Page 11: Chapter 3 Web Configuration

    Chapter 3 Web Configuration 3.1 Status 3.1.1 Overview You can view the system information of the gateway on this page. Figure 3-1-1-1 System Information Item Description Model Show the model name of gateway. Region Show the LoRaWAN ® frequency region of gateway. Serial Number Show the serial number of gateway.

  • Page 12: Network

    3.1.2 Network On this page you can check the Ethernet port status of the gateway. Figure 3-1-2-1 Network Item Description Port Show the name of the Ethernet port. Show the status of the Ethernet port. "Up" refers to a status that WAN Status is enabled and Ethernet cable is connected.
  • Page 13 Figure 3-1-3-2 VPN Status Item Description Name Show the name of the VPN tunnel. Status Show the status of the VPN tunnel. Local IP Show the local tunnel IP of VPN tunnel. Remote IP Show the remote tunnel IP of VPN tunnel. Table 3-1-3-1 VPN Status 3.1.4 Routing You can check routing status on this page, including the routing table and ARP cache.

  • Page 14: Lorawan

    Show the IP address of ARP pool. Show the IP address's corresponding MAC address. Interface Show the binding interface of ARP. Table 3-1-4-1 Routing Information 3.2 LoRaWAN 3.2.1 Packet Forwarder 3.2.1.1 General Figure 3-2-1-1 General Settings Item Description Default Generated from MAC address of the Gateway EUI Show the identifier of the gateway.

  • Page 15: Radios

    Related Configuration Example Packet fowarder configuration 3.2.1.2 Radios Figure 3-2-1-2 Radios-Radio Channel Setting Item Description Default Choose the LoRaWAN ® frequency plan used for the upstream and downlink frequencies and datarates. Based on the Region Available channel plans depend on the gateway’s gateway’s model model.
  • Page 16 Range: center frequency±0.4625. LoRaWAN ® regional document Table 3-2-1-3 Multi Channel Setting Parameters Figure 3-2-1-4 Radios-LoRa Channel Setting Item Description Default Click to enable this channel to transmit Enable Enabled packets. Choose Radio 0 or Radio 1 as center Radio Radio 0 frequency.

  • Page 17: Noise Analyzer

    Table 3-2-1-5 FSK Channel Setting Parameters 3.2.1.3 Noise Analyzer Noise analyzer is used for scanning the noise of every frequency channel and giving a diagram for users to analyze the environment interference condition and select best deployment. RSSI indicates the sensitivity for every channel. Lower the RSSI value, better the signal.
  • Page 18 Figure 3-2-1-7 Advanced-Beacon Setting Item Description Default Interval of gateway sending beacons for Class B Beacon Period device time synchronization. 0 means the gateway will not send beacons. Based on the Beacon Freq The frequency of beacons. supported frequency Based on the Beacon The datarate of beacons.
  • Page 19 Figure 3-2-1-8 Item Description Default Enter the interval of keep alive packet which is sent Keep Alive from gateway to network server to keep the connection 10 s Interval stable and alive. Range: 1-3600. Enter the interval to update the network server with Stat Interval 30 s gateway statistics.

  • Page 20: Custom

    a channel is less than the criteria/target, the channel is considered as idle. Range: -120~0 Table 3-2-1-9 Advanced-LBT Parameters 3.2.1.5 Custom Figure 3-2-1-10 When Custom Configuration mode is enabled, you can write your own packet forwarder configuration file in the edit box to configure packet forwarder. Click “Save” to save your custom configuration file content, and click “Apply”...

  • Page 21: Network Server

    Figure 3-2-1-11 Item Description Refresh Click to obtain the latest data. Clear Click to clear all data. Rfch Show the channel of this packet. Direction Show the direction of this packet. Time Show the receiving time of this packet. Ticks Show the ticks of this packet.
  • Page 22 Item Description Default General Setting Enable Click to enable Network Server mode. Enabled Enabled to connect gateway to Milesight IoT Cloud Mode Disabled Cloud or Yeastar Workplace platform . NetID Enter the network identifier. 010203 Enter the interval time between when the...

  • Page 23: Application

    Channel Plan Setting Choose LoRaWAN channel plan used for the ® Depend on the upstream and downlink frequencies and Channel Plan gateway’s datarates. Available channel plans depend on the frequency gateway’s model. Enabled frequencies are controlled using channel mask. Leave it blank means using all the default standard usable channels specified in the LoRaWAN regional parameters document.
  • Page 24 devices with the same “Payload Codec” and data transmission destination can be added under the same application. You can edit the application by clicking or create a new application by clicking Figure 3-2-2-3 Item Description Enter the name of the application profile. Name E.g Smoker-sensor-app.
  • Page 25 Figure 3-2-2-4 Figure 3-2-2-5 MQTT Settings Item Description Default General Broker MQTT broker address to receive data. Address Broker Port MQTT broker port to receive data.
  • Page 26 Client ID is the unique identity of the client to the server. Client ID It must be unique when all clients are connected to the same server, and it is the key to handle message at QoS 1 and 2. If the client does not get a response after the connection Connection timeout, the connection will be considered as broken.

  • Page 27: Profiles

    Figure 3-2-2-6 HTTP/HTTPS Settings Item Description HTTP Header Header Name A core set of fields in HTTP header. Header Value Value of the HTTP header. Data Type Data type sent to HTTP/HTTPS server. Topic Topic name of the data type using for publish. HTTP/HTTPS server URL to receive data.
  • Page 28 Figure 3-2-2-7 Figure 3-2-2-8 Device Profiles Settings Item Description Default Enter the name of the device profile. Name Null E.g. Smoker-sensor-app. Enter the maximum transmit power. The TXPower indicates power levels relative to the Max EIRP level of the end-device. 0 means using the max EIRP. TXPower EIRP refers to the Equivalent Isotropically Radiated Power.
  • Page 29 personalization directly ties an end-device to a specific network bypassing the join request - join accept procedure. Device type is Class A by default. Users can check the box of Class B or Class C to add the class type. Class Type ---- Note:...

  • Page 30: Device

    only works for CN470/US915/AU915 gateway. PingSlot Period Period of opening the pingslot. Every Second Based on the PingSlot Datarate of the node receiving downlinks. supported DataRate frequency Based on the PingSlot Freq Frequency of the node receiving downlinks. supported frequency The time for confirmed downlink transmissions.
  • Page 31 Application Choose the application profile. Null Choose from: "Disable", "Modbus RTU to TCP", "Modbus RTU over TCP". This feature is only applicable to Milesight class C type LoRaWAN ® Modbus RTU controllers.(UC300/UC501/UC1152, etc.) Data Disable -Modbus RTU to TCP: TCP client can send Modbus Transmission TCP commands to ask for controller Modbus data.
  • Page 32 UG63. Range: 2-84, 86-223. Note: this value must be the same as the Milesight LoRaWAN ® controller’s Fport. Enter the TCP port for data transmission between the TCP Port TCP Client and UG63 (as TCP Server). Null Range: 1-65535.

  • Page 33: Multicast Groups

    3.2.2.5 Multicast Groups Milesight gateways support for creating Class B or Class C multicast groups to send downlink messages to a group of end devices. A multicast group is a virtual ABP device (i.e. shared session keys), does not support uplink, confirmed downlink nor MAC commands.

  • Page 34: Packets

    Address Multicast The network session key (Netwks Key) of all devices in Network Null this group. Session Key Multicast The application session key (AppSKey) of all devices in Application Null this group. Session Key Class Type Class B and Class C are optional. Class C Based on the Datarate...
  • Page 35 Enter the EUI of the device to receive Device EUI Null the payload. Multicast Select the multicast group to send downlinks. Multicast Null Group groups can be added under Multicast Groups tab. Choose from: “ASCII”, “hex”, “base64”. Type ASCII Choose the payload type to enter in the payload Input box. Payload Enter the message to be sent to this device.
  • Page 36 Figure 3-2-2-15 Item Description Addr/Multicast Show the address of the device/multicast group. Addr GwEUI Show the EUI of the gateway. AppEUI Show the EUI of the application. DevEUI/Group Show the EUI of the device/multicast group name. Name Class Type Show the class type of the device or multicast group. True: Device may transmit an explicit (possibly empty) Immediately acknowledgement data message immediately after the reception of a...

  • Page 37: Network

    False: ADR is disabled or Network does not respond in ADR_ACK_DELAY. True: This frame is ACK. False: This frame is not ACK. Show the frame-counter of this packet.The network server tracks the Fcnt uplink frame counter and generates the downlink counter for each end-device. FPort is a multiplexing port field.
  • Page 38 Figure 3-3-1-1 Port Setting Item Description Default Port The port that is fixed as eth0 port and enabled. eth 0 Connection Select from "Static IP", "DHCP Client" and "PPPoE". Static IP Type Set the maximum transmission unit. 1500 Primary DNS Set the primary DNS.
  • Page 39 Figure 3-3-1-2 Static IP Item Description Default IP Address Set the IP address which can access Internet. 192.168.23.150 Netmask Set the Netmask for Ethernet port. 255.255.255.0 Gateway Set the gateway's IP address for Ethernet port. 192.168.23.1 Multiple IP Set the multiple IP addresses for Ethernet port. Null Address Table 3-3-1-2 Static IP Parameters...

  • Page 40: Loopback

    Figure 3-3-1-3 DHCP Client Item Description Obtain peer DNS automatically during PPP dialing. DNS is Use Peer DNS necessary when user visits domain name. Table 3-3-1-3 DHCP Client Parameters 3. PPPoE PPPoE refers to a point-to-point protocol over Ethernet. User has to install a PPPoE client on the basis of original connection way.

  • Page 41: Vpn

    Virtual Private Networks, also called VPNs, are used to securely connect two private networks together so that devices can connect from one network to the other network via secure channels. UG63 supports DMVPN, IPsec, GRE, L2TP, PPTP, OpenVPN, as well as GRE over IPsec and L2TP over IPsec. 3.3.2.1 DMVPN...
  • Page 42 Figure 3-3-2-1 Figure 3-3-2-2 DMVPN Item Description Enable Enable or disable DMVPN. Hub Address The IP address or domain name of DMVPN Hub. Local IP address DMVPN local tunnel IP address. GRE Hub IP Address GRE Hub tunnel IP address. GRE Local IP Address GRE local tunnel IP address.

  • Page 43: Ipsec

    Select from "MODP768_1", "MODP1024_2" and DH Group "MODP1536_5". Enter the preshared key. Local ID Type Select from "Default", "ID", "FQDN", and "User FQDN" IKE Life Time (s) Set the lifetime in IKE negotiation. Range: 60-86400. Select from "DES_MD5", "DES_SHA1", "3DES_MD5", "3DES_SHA1", "AES128_MD5", "AES128_SHA1", SA Algorithm "AES192_MD5", "AES192_SHA1", "AES256_MD5"...
  • Page 44 Figure 3-3-2-3 IPsec Item Description Enable Enable IPsec tunnel. A maximum of 3 tunnels is allowed. Enter the IP address or domain name of remote IPsec IPsec Gateway Address server. IPsec Mode Select from "Tunnel" and "Transport". IPsec Protocol Select from "ESP" and "AH". Local ID Type Select from "Default", "ID", "FQDN", and "User FQDN".
  • Page 45 Figure 3-3-2-4 IKE Parameter Item Description IKE Version Select from "IKEv1" and "IKEv2". Negotiation Mode Select from "Main" and "Aggressive". Encryption Algorithm Select from "DES", "3DES", "AES128", "AES192" and "AES256". Authentication Select from "MD5" and " SHA1" Algorithm DH Group Select from "MODP768_1", "MODP1024_2"...

  • Page 46: Gre

    DPD Interval Time(s) Set DPD interval time to detect if the remote side fails. DPD Timeout(s) Set DPD timeout. Range: 10-3600. IPsec Advanced Enable Compression The head of IP packet will be compressed after it's enabled. Select from "NONE", "GRE" and "L2TP" to enable VPN over VPN Over IPsec Type IPsec function.

  • Page 47: L2Tp

    Remote IP Address Enter the real remote IP address of GRE tunnel. Local IP Address Set the local IP address. Local Virtual IP Set the local tunnel IP address of GRE tunnel. Address Netmask Set the local netmask. Peer Virtual IP Address Enter remote tunnel IP address of GRE tunnel.
  • Page 48 "MS-CHAPv2". Global Traffic All of the data traffic will be sent out via L2TP tunnel after Forwarding this function is enabled. Remote Subnet Enter the remote IP address that L2TP protects. Remote Subnet Mask Enter the remote netmask that L2TP protects. Enter the password of L2TP tunnel.

  • Page 49: Pptp

    connection. Range: 0-600. Set the maximum times of retry to detect the L2TP Max Retries connection failure. Range: 0-10. User can enter some other PPP initialization strings in this Expert Options field and separate the strings with blank space. Table 3-3-2-6 L2TP Parameters 3.3.2.5 PPTP Point-to-Point Tunneling Protocol (PPTP) is a protocol that allows corporations to extend their own corporate network through private "tunnels"...
  • Page 50 Figure 3-3-2-9 PPTP Advanced Settings Item Description Local IP Address Set IP address of PPTP client. Peer IP Address Enter tunnel IP address of PPTP server. Enable MPPE Enable MPPE encryption. Address/Control For PPP initialization. User can keep the default option. Compression Protocol Field For PPP initialization.

  • Page 51: Openvpn Client

    3.3.2.6 OpenVPN Client OpenVPN is an open source virtual private network (VPN) product that offers a simplified security framework, modular network design, and cross-platform portability. Advantages of OpenVPN include: Security provisions that function against both active and passive attacks. Compatibility with all major operating systems. High speed (1.4 megabytes per second typically).

  • Page 52: Certifications

    Local Tunnel IP Set local tunnel address. Remote Tunnel IP Enter remote tunnel address. Global Traffic All the data traffic will be sent out via OpenVPN tunnel when Forwarding this function is enabled. Enable TLS Check to enable TLS authentication. Authentication Username Enter username provided by OpenVPN server.

  • Page 53: System

    Private Key Import/Export private key file. Import/Export TA key file. Preshared Key Import/Export static key file. PKCS12 Import/Export PKCS12 certificate file. Table 3-3-2-11 OpenVPN Client Certification Parameters Figure 3-3-2-14 IPsec Item Description Import/Export CA certificate. Client Key Import/Export client key. Server Key Import/Export server key.
  • Page 54 Figure 3-4-1-1 General Item Description Default System Hostname User-defined gateway name, needs to start with a letter. GATEWAY Web Login You need to log in again if it times out. Range: 100-3600. 1800 Timeout (s) Access Service Port Set port number of the services. Range: 1-65535. Users can log in the device locally via HTTP to access HTTP and control it through Web after the option is checked.

  • Page 55: System Time

    PC. Click "Delete" button will delete the file. Click "Browse" button, choose key file on the PC, and then click "Import" button to upload the file into gateway. Click "Export" button will export file to the PC. Click "Delete" button will delete the file. Table 3-4-1-1 General Setting Parameters 3.4.1.2 System Time This section explains how to set the system time including time zone and time...

  • Page 56: Smtp

    Figure 3-4-1-4 System Time Item Description Current Time Show the current system time. Time Zone Click the drop down list to select the time zone you are in. Click the drop down list to select the time synchronization Sync Type type.

  • Page 57: Email

    Figure 3-4-1-5 SMTP Item Description SMTP Client Settings Enable Enable or disable SMTP client function. Email Address Enter the sender's email account. Password Enter the sender's email password. SMTP Server Address Enter SMTP server's domain name. Port Enter SMTP server port. Range: 1-65535. Enable TLS Enable or disable TLS encryption.

  • Page 58: User Management

    Name Set Email group name. Enter the Email address. You can divide multiple Email Email Address addresses by “;”. Table 3-4-1-4 Email Settings 3.4.2 User Management 3.4.2.1 Account Here you can change the login username and password of the administrator. Note: it is strongly recommended that you modify them for the sake of security.

  • Page 59: Snmp

    Enable SNMP setting. Download MIB file and load it into NMS. Configure MIB View. Configure VCAM. 3.4.3.1 SNMP UG63 supports SNMPv1, SNMPv2c and SNMPv3 version. SNMPv1 and SNMPv2c employ community name authentication. SNMPv3 employs authentication encryption by username and password.

  • Page 60: Mib View

    Figure 3-4-3-1 SNMP Settings Item Description Enable Enable or disable SNMP function. Set SNMP listened port. Range: 1-65535. Port The default port is 161. SNMP Version Select SNMP version; support SNMP v1/v2c/v3. Location Information Fill in the location information. Contact Information Fill in the contact information.

  • Page 61: Vacm

    Included You can query all nodes within the specified MIB node. Excluded You can query all nodes except for the specified MIB node. Table 3-4-3-2 MIB View Parameters 3.4.3.3 VACM This section describes how to configure VCAM parameters. Figure 3-4-3-3 VACM Item Description...

  • Page 62: Mib

    Figure 3-4-3-4 SNMP Trap Item Description Enable Enable or disable SNMP Trap function. SNMP Version Select SNMP version; support SNMP v1/v2c/v3. Server Address Fill in NMS's IP address or domain name. Fill in UDP port. Port range is 1-65535. The default port is Port 162.

  • Page 63: Events

    Figure 3-4-4-1 DeviceHub Item Description Show the connection status between the gateway and the Status DeviceHub. Disconnected Click this button to disconnect the gateway from the DeviceHub. Activation Server IP address or domain of the DeviceHub. Address DeviceHub Server The URL address for the device to connect to the DeviceHub, Address e.g.

  • Page 64: Events Settings

    Figure 3-4-5-1 Events Item Description Mark as Read Mark the selected event alarm as read. Delete Delete the selected event alarm. Mark All as Read Mark all event alarms as read. Delete All Alarms Delete all event alarms. Show the reading status of the event alarms, such as “Read” and Status “Unread”.

  • Page 65: Maintenance

    Event Settings Item Description Enable Check to enable "Events Settings". WAN Up Ethernet cable is connected to WAN port. WAN Down Ethernet cable is disconnected to WAN port. VPN Up VPN is connected. VPN Down VPN is disconnected. Power On The gateway has powered on.

  • Page 66: Schedule

    Figure 3-5-1-2 Traceroute Item Description Host Address of the destination host to be detected. Table 3-5-1-2 Traceroute Parameters 3.5.2 Schedule This section explains how to configure scheduled reboot on the gateway. Figure 3-5-2-1 Schedule Item Description Schedule Select schedule type. Reboot Reboot the gateway regularly.

  • Page 67: System Log

    3.5.3.1 System Log This section describes how to download log file and view the recent log on web. Figure 3-5-3-1 System Log Item Description Download Download log file. View recent (lines) View the specified lines of system log. Clear Log Clear the current system log.

  • Page 68: Upgrade

    Log Settings Item Description Remote Log Server With “Remote Log Server” enabled, gateway will send all Enable system logs to the remote server. Fill in the remote system log server address (IP/domain Syslog Server Address name). Port Fill in the remote system log server port. Local Log File Storage User can store the log file in memory or TF card.

  • Page 69: Backup And Restore

    3.5.5 Backup and Restore This section explains how to create a backup of the whole system configurations to a file, replicate parts of important configuration only for batch backup, restore the config file to the gateway and reset to factory defaults. Figure 3-5-5-1 Backup and Restore Item...
  • Page 70 Figure 3-5-6-1...

  • Page 71: Chapter 4 Application Examples

    Chapter 4 Application Examples 4.1 Restore Factory Defaults 4.1.1 Via Web Interface Log in web interface, and go to “Maintenance → Backup and Restore”. Click “Reset” button under the “Restore Factory Defaults”. You will be asked to confirm if you’d like to reset it to factory defaults. Then click “Reset” button.

  • Page 72: Via Hardware

    Off → Static Green 4.2 Firmware Upgrade It is suggested that you contact Milesight technical support first before you upgrade gateway firmware. Gateway firmware file suffix is “.bin”. After getting firmware file please refer to the following steps to complete the upgrade.

  • Page 73: Ethernet Connection

    Related Topic Upgrade 4.3 Ethernet Connection Go to “Network → Interface → Port” page to select the connection type and configure Ethernet port configuration. Click “Save & Apply” for configuration to take effect.

  • Page 74: Packet Forwarder Configuration

    Related Topic Port Setting 4.4 Packet Forwarder Configuration UG63 gateway has installed multiple packet forwarders including Semtech, Basic station, Chirpstack-Generic MQTT broker, etc. Before connecting make sure the gateway has connected to network. 1. Go to “Packet Forwarder → General”.

  • Page 75: Connect To Milesight Iot Cloud

    Milesight IoT Support portal. 5. Go to “Traffic” page to view the data communication of UG63. 4.5 Connect to Milesight IoT Cloud 1. Go to “Packet Forwarder → General” page to enable the embedded network server.
  • Page 76 2. Go to “Packet Forwarder → Radio” page to select the center frequency and channels. The channels of the gateway and nodes need to be the same. 3. Go to “Network Server” → “General” page to enable the network server and “Cloud mode”, then select “Milesight IoT Cloud”.

  • Page 77: Application Configuration

    4. Log in the Milesight IoT Cloud. Then go to “My Devices” page and click “+New Devices” to add gateway to Milesight IoT Cloud via SN. Gateway will be added under “Gateways” menu. 5. The gateway is online on Milesight IoT Cloud. For UG63, it’s suggested to bind not more than 20 devices. 4.6 Application Configuration...
  • Page 78 2. Click to enter the configuration page, displayed as the following picture： 3. Click “Save” to create this application. 4. Click to add a data transmission type. HTTP or HTTPS： Step 1: select HTTP or HTTPS as transmission protocol. Step 2: Enter the destination URL. Different types of data can be sent to different URLs. Enter the header name and header value if there is user credentials when accessing the HTTP(s) server.
  • Page 79 Step 2: Fill in MQTT broker general settings. Step 3: Select the authentication method required by the server. If you select user credentials for authentication, you need to enter the username and password for authentication. If certificate is necessary for verification, please select mode and import CA certificate, client certificate and client key file for authentication.

  • Page 80: Device Configuration

    4.7 Device Configuration Go to “Device” page and click “Add” to add LoRaWAN node devices. Due to memory ® limitation, it’s suggested to add not more than 20 devices. Please select correct device profile according to device type. You can also click “Bulk Import” if you want to add many nodes all at once. Click “Template Download”...

  • Page 81: Send Data To Device

    4.8 Send Data to Device 1. Go to “Network Server → Packets”, check the packet in the network server list to make sure that the device has joined the network successful. 2. Fill in the device EUI or select the multicast group which you need to send downlinks. Then fill in the downlink commands, ports.
  • Page 82 Ack is “true” means that the device has received this packet. If the device’s class type is Class A, only after the device sends out an uplink packet will the network server sends out data to the device.

  • Page 83: Connect To Ug65/Ug67 Gateway

    2. Go to “Network Server” → “Gateway Fleet” page of UG65/UG67 to add the gateway ID of UG63 gateway and define a name, then save the settings. 3. After connected, the UG63 can transfer node data to UG65/UG67 and you can check the data details on “Network Server” → “Packets” page of UG65/UG67.
  • Page 84 [END]...
