- Page 1 Semi-Industrial LoRaWAN Gateway ® UG65 Quick Start Guide Milesight IoT...
- Page 2 Safety Precautions Milesight will not shoulder responsibility for any loss or damage resulting from not following the instructions of this operating guide. The device must not be modeled in any way. Do not place the device close to objects with naked flames.
- Page 3 This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. This transmitter must not be co-located or operating in conjunction with any other antenna or www.Milesight.com...
- Page 4 œuvre de ce matériel devrait avec échangeur distance minimale entre 20 cm ton corps.Lanceurs ou ne peuvent pas coexister cette antenne ou capteurs avec d’autres. Revision History Date Doc Version Description Aug. 31, 2020 V1.0 Initial version Nov. 24, 2020 V2.0 Layout replace May 6, 2021 V2.1 Layout replace www.Milesight.com...
-
Page 5: Table Of Contents
5. Network Connection........................... 15 5.1 Configure the Ethernet Connection....................15 5.2 Configure the Wi-Fi Connection...................... 15 5.3 Configure the Cellular Connection....................16 6. Packet Forwarder Configuration.......................18 7. Network Server Configuration........................20 7.1 Connect UG65 to Milesight IoT Cloud................... 20 7.2 Connect UG65 to MQTT/HTTP Server...................22... -
Page 6: Packing List
1. Packing List Before you begin to install the UG65 LoRaWAN ® Gateway, please check the package contents to verify that you have received the items below. 1 × UG65 1 × Ethernet Cable 1 × DC Jack Power Adapter 1 ×... -
Page 7: Hardware Introduction
2. Hardware Introduction 2.1 Overview A. Front Panel LED Area POWER: Power Indicator STATUS: System Indicator LoRa: LoRa Indicator Wi-Fi: Wi-Fi Indicator LTE: Cellular Indicator ETH: Ethernet Port Indicator LoRa Antenna Connector (only for external antenna version) B. Rear Panel Bracket Mounting Screws SIM Slot Type-C Port... -
Page 8: Led Indicators
2.3 LED Indicators Indication Status Description The power is switched off POWER Power Status The power is switched on Blue Light Static: the system is running properly STATUS System Status Red Light The system goes wrong Packet Forwarder mode is running off LoRa LoRa Status Blue Light... -
Page 9: Hardware Installation
3. Hardware Installation 3.1 SIM Card Installation A. Use screwdriver to open the protective cover on the back panel of UG65. B. Insert the SIM card into the device according to the direction icon on the device. Note: If you need to take out the SIM card, press into the SIM card and it will pop up automatically. ... -
Page 10: Gateway Installation
Note: Please do not let the front panel of products faces to walls if using embedded LoRa antennas. 3.4 Gateway Installation UG65 can be mounted to a wall or a pole. Before you start, make sure that your SIM card has been inserted, your antennas have been attached and all cables have been installed. -
Page 11: Pole Mounting
3.4.2 Pole Mounting Preparation: mounting bracket, bracket fixing screws, hose clamp and other required tools. 1. Loosen the hose clamp by turning the locking mechanism counter-clockwise. 2. Straighten out the hose clamp and slide it through the rectangular rings in the mounting bracket, wrap the hose clamp around the pole. -
Page 12: Login The Web Gui
4. Login the Web GUI UG65 provides web-based configuration interface for management. If this is the first time you configure the gateway, please use the default settings below: ETH IP Address: 192.168.23.150 Wi-Fi IP Address: 192.168.1.1 Wi-Fi SSID: Gateway_****** Username: admin Password: password 4.1 Wireless Access A. -
Page 13: Wired Access
4.2 Wired Access Connect PC to UG65 ETH port through PoE injector. The following steps are based on Windows 10 operating system for your reference. A. Go to “Control Panel” → “Network and Internet” → “Network and Sharing Center”, then click “Ethernet”... - Page 14 D. Enter the username and password, click “Login”. If you enter the username or password incorrectly more than 5 times, the login page will be locked for 10 minutes. E. After logging the web GUI, follow the guide to complete the basic configurations. You can also skip the instructions.
-
Page 15: Network Connection
5. Network Connection This section explains how to connect the gateway to network via WAN connection, Wi-Fi or cellular. 5.1 Configure the Ethernet Connection A. Go to “Network”→ “Interface” → “Port” page to select the connection type and configure Ethernet port information. -
Page 16: Configure The Cellular Connection
C. Type the key of Wi-Fi. D. Go to “Status”→”WLAN” to check Wi-Fi status. If it shows “Connected”, it means gateway connects to Wi-Fi successfully. 5.3 Configure the Cellular Connection A. Go to “Network” → “Interface” → “Cellular” → “Cellular Setting” page to enable cellular settings. - Page 17 B. Choose relevant network type and fill in SIM card information like APN or PIN code. C. Click “Save” and “Apply” for changes to take effect. D. Go to “Status” → “Cellular” page to view the status of the cellular connection. If it shows “Connected”, it means the SIM has dialed up successfully.
-
Page 18: Packet Forwarder Configuration
6. Packet Forwarder Configuration UG65 has installed multiple packet forwarders including Semtech, Chirpstack-Generic MQTT broker, etc. This section explains how to connect the gateway to network servers. Make sure the gateway connects to the network as shown in Section A. Go to “Packet Forwarder” → “General” page and click to add a network server. - Page 19 D. Add the gateway on network server page. For more details about the network server connection please refer to Milesight IoT Support portal. E. Go to “Traffic” page to view the data communication of UG65.
-
Page 20: Network Server Configuration
7. Network Server Configuration UG65 can work as network server and transmit data to Milesight IoT Cloud or other platform via MQTT/HTTP/HTTPS. Make sure the gateway connects to the network as shown in Section 7.1 Connect UG65 to Milesight IoT Cloud A. - Page 21 D. Log in the Milesight IoT Cloud. Then go to “My Devices” page and click “+New Devices” to add gateway to Milesight IoT Cloud via SN. Gateway will be added under “Gateways” menu. The gateway is online on Milesight IoT Cloud.
-
Page 22: Connect Ug65 To Mqtt/Http Server
7.2 Connect UG65 to MQTT/HTTP Server A. Go to “Packet Forwarder” → “General” page to enable the embedded network server. B. Go to “Packet Forwarder” → “Radio” page to select the antenna type, center frequency and channels. The channels of the gateway and nodes need to be the same. C. - Page 23 D. Go to “Network Server”→”Application” to add a new application. After saving the application, you can select HTTP, HTTPS or MQTT protocol and fill in correspond server information to send data to another server. E. Go to “Profiles” page to add a new profile for the device.
- Page 24 F. Go to “Device” page and click “Add” to add LoRaWAN ® node devices. You can also click “Bulk Import” if you want to add many nodes all at once. Click “Template Download” to download template file and add device information to this file. Application...
- Page 25 and device profile should be the same as you created on web page. Import this file to add bulks of devices. F. Go to “Packets” page to check the packets from LoRaWAN ® node devices. The type starts from “Up” means uplinks and “Dn”...
