- Page 1 LoRaWAN ® Gateway Cloud App Quick Start Guide All software & files can be downloaded from https://www.milesight.com/iot/resources/download-center/#documents www.milesight.com Xiamen Milesight IoT Co., Ltd. UG6x Building C09, Software Park Phase III, Xiamen 361024, Fujian, China...
-
Page 2: Table Of Contents
Table of Contents 1. Packing List………………………………………………………………………………......2. Hardware Introduction……………………………………………………………………………………….. 3. Fitting Installation…………………………………………………………………......4. Power Supply………………………………………………............ 5. Gateway Installation……………………………………………........... 6. Web GUI Access…………………………………………………........………… 7. FCC Statement..................… www.milesight.com... -
Page 3: Packing List
If any of the above items is missing or damaged, please contact your sales LoRaWAN ® Antenna Bracket Fixing Screws Wall Mounting Kits representative. (EA version included) Quick Start Guide Warranty Card 60cm LoRaWAN ® Antenna Kit (Optional) www.milesight.com www.milesight.com... -
Page 4: Hardware Introduction
LED Area & Type-C Port & Reset Button Ethernet Port (PoE) DC Power Connector How to reset the device to factory default? Press and hold the reset button for more than 5 seconds until STATUS/SYS LED is rapidly blinking. www.milesight.com www.milesight.com... -
Page 5: Fitting Installation
Please tighten the SIM dust cover of UG67 with wrench to prevent water into the equipment. Step 2: rotate the antenna into the antenna connector accordingly. For UG67, it is suggested to install coaxial cable to ANT1 connector to distance both antennas. www.milesight.com www.milesight.com... - Page 6 For DC power supply, remove the protective cap of power connector and corresponding interfaces, you can pass them through the waterproof rotate the DC power cable into the power connector. silicone and slide into the grooves. Then screw the protective cover back to the device. www.milesight.com www.milesight.com...
-
Page 7: Power Supply
2. Screw the bracket mounting screws behind the device and hang the device to the mounting bracket on the wall. Desktop: Take off the baffle and mounting plate on the back of the device, then you can place the device on the desktop. www.milesight.com www.milesight.com... - Page 8 2. Hang the device to the mounting bracket via bracket mounting screws on the back of device, then screw the bracket screw to the bottom of the device. www.milesight.com www.milesight.com...
-
Page 9: Web Gui Access
IP address of computer manually, then type 192.168.23.150 to your browser to log in the web GUl of UG6x. This mode only works with UG65 and UG67.You can follow the steps below to configure computer IP address manually based on Windows 10 system. www.milesight.com www.milesight.com... -
Page 10: Fcc Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. www.milesight.com www.milesight.com...
