Field Controls 46334200 Instruction Sheet page 4

SWG-4AT AMERICAN STANDARD AND TRANE
Kit Includes:
SWGII-4HD Sidewall Power Venter
CK-43F Control Kit
Includes:
For Use With The Following American Standard And Trane Furnaces:
Furnace Configuration And Vent Pipe Restrictions:
Furnace Input
100,000
120,000
140,000
General Wiring
Refer to the Diagrams on the following page for guidance in wiring the Power Venter and Control Kit
to the appliance.
For complete installation information refer to the Field Controls SWG-4AT Power Venter Installation
Manual for details (P/N 46306700.)
SIDEWALL POWER VENTING KIT
Field Controls P/N 46205405
4" MG-1 Barometric Draft Control
Fan Proving Switch
Fixed post purge
AUD-C
TUD-C
AUD-R
TUD-R
Diameter Of Vent Pipe
BTU/Hr Collar On Furnace (In.)
40,000
60,000
80,000
CUE-A ADD-R
TUE-A TDD-R
ADD-C CDE-A
TDD-C TDE-A
Maximum Equivalent
Vent Length (Ft.)
4
4
4
4
4
4
Page 4
65
65
65
65
65
65
