SWG-4CD CONSOLIDATED SIDEWALL POWER VENTING KIT
Kit Includes:
SWGII-4HD Sidewall Power Venter
WMO-1 Thermal Safety Switch (Must be purchased separately if using other venting kit on
Consolidated Furnaces.)
CK-43F Control Kit
Includes:
For use with the following series of furnaces:
This furnace was built by CONSOLIDATED
INDUSTRIES under the names: QUATRO, TECH-4,
QUADPRO, QUADTECH, MULTIFLOW, BRENTWOOD,
and SUNBURST.
Model Numbers:
MAA040NR2R MBA040NH2R
MAA040NR3R MBA040NH3R
MAA060NR2R MBA060NH2R
MAA060NR3R MBA060NH3R
MAA060NR4R MBA060NH4R
MAA080NR2R MBA080NH2R
MAA080NR3R MBA080NH3R
MAA080NR4R MBA080NH4R
MAA080NR5R MBA080NH5R
MAA100NR3R MBA100NH3R
MAA100NR4R MBA100NH4R
MAA100NR5R MBA100NH5R
MAA120NR4R MBA120NH4R
MAA120NR5R MBA120NH5R
MAA140NR4R MBA140NH4R
MAA140NR5R MBA140NH5R
Note: Model numbers may have suffix "X".
This kit may also be used with furnaces manufactured by
Consolidated Industries and sold by a number of other companies
under their names.
General Information:
Field Controls P/N 46205408
4" MG-1 Barometric Draft Control
Fan Proving Switch
Fixed post purge
MCA040NR2R MDA040NH2R
MCA040NR3R MDA040NH3R
MCA060NR2R MDA060NH2R
MCA060NR3R MDA060NH3R
MCA060NR4R MDA060NH4R
MCA080NR2R MDA080NH2R
MCA080NR3R MDA080NH3R
MCA080NR4R MDA080NH4R
MCA080NR5R MDA080NH5R
MCA100NR3R MDA100NH3R
MCA100NR4R MDA100NH4R
MCA100NR5R MDA100NH5R
MCA120NR4R MDA120NH4R
MCA120NR5R MDA120NH5R
MCA140NR4R MDA140NH4R
MCA140NR5R MDA140NH5R
Page 10
This furnace was built by
CONSOLIDATED INDUSTRIES
under the name PREMIER.
Model Numbers:
HBA040NR3R
HBA060NR4R
HBA080NR4R
HBA100NR5R
HBA120NR5R
Note: Model numbers may have suffix "X".
This kit may also be used with furnaces
manufactured by Consolidated Industries and
sold by a number of other companies under
their names.
