Field Controls 46334200 Instruction Sheet page 2

SWG-4AM AMANA SIDEWALL POWER VENTING KIT
Kit Includes:
SWGII-4HD Sidewall Power Venter
CK-43 Control Kit
Includes:
Recommended For Use On The Following Amana Model Furnaces:
NOT For Use On The Following Amana Model Furnaces:
Furnace Configuration and Vent Pipe Restrictions
Type B-1 vent pipe shall be used to join the furnace to the venting system and for the entire length of
the venting system. Exception: Up to 24" of single wall vent pipe may be used to connect the furnace
to the barometric damper. The barometric damper tee may be single wall. Type B-1/double wall vent
pipe MUST be used from the barometric damper tee to the power venter.
For Furnace Models GUIA, GUIB, GUIC, and GUID
BTU/Hr. Diameter of
Flue Collar
on Furnace
46,000
69,000
92,000
115,000
138,000
For Furnace Models GCIA, GCIB, and GCIC
BTU/Hr. Diameter of
Flue Collar
on Furnace
46,000
69,000
92,000
115,000
138,000
Field Controls P/N 46205411
4" MG-1 Barometric Draft Control
Fan Proving Switch
Adjustable Post Purge
GBI GCIC GUI
GCIA GMI GUIB
GCIS
Installer
Provided Flue
Pipe Transition
Size Diameters
4" None
4" None
4" None
4" None
4" None
Installer
Provided Flue
Pipe Transition
Size Diameters
3" 3" to 4"
3" 3" to 4"
3" 3" to 4"
3" 3" to 4"
3" 3" to 4"
GUID GCI GHI
GCIB GSI GUIC
GUIS GUIV
Maximum
Equivalent Length
(ft.) for 4" Vent Pipe
100
100
100
85
65
Maximum
Equivalent Length
(ft.) for 4" Vent Pipe
100
100
100
85
65
Page 2
GUIA
Maximum
Equivalent Length
(ft.) for 5" Vent Pipe
100
100
100
95
80
Maximum
Equivalent Length
(ft.) for 5" Vent Pipe
100
100
100
95
80
