MAXISYS
PRODUCT DESCRIPTION
MaxiSys MS909CV provides the full functionality and online
repair information you need when diagnosing vehicles,
identifying faults and researching repair issues. It features
a powerful octa-core
capacitive touchscreen for swift diagnosis and optimum
viewing. As an intelligent diagnostics and information system
MaxiSys MS909CV not only displays the relevant repair
fixes and cases gathered from experienced industry experts,
but provides step-by-step guidance to ensure the repair is
done correctly and efficiently.
MaxiSys MS909CV has three main components:
• MaxiSys Display Tablet — the central processor and
monitor for the system
• VCI — vehicle
• B200 — battery & electrical system tester
1 9 7" TFT-LCD Capacitive Touchscreen
2 Ambient Light Sensor — detects ambient
brightness
3 Power LED
4. Front Camera
5 Microphone
6 Speaker
7 Collapsible Stand — extends from the back to
allow hands-free viewing of the tablet
8 Rear Camera
9 Camera Flash
10. Headphone Jack
11 USB Port
12 USB Port
13 Mini USB Port
14 HDMI (High-Definition
15 Mini SD Card
16. DC Power Supply Input Port
17 Lock/Power Button
the Display Tablet, or tap to lock the screen
Ms909cv
processor and 9.7-inch TFT-LCD
communication interface
Multimedia Interface) Port
Slot
long press to turn on/off
