Main unit components
Main unit x 1
1
Flat head screw
5
(Red:M5x8) x 8
Earth plate
9
x 1
PND components
PND
11 12
x 1
15 SD Card (containing the
application and maps)
x 1
Adapter plug
19
(for United Kingdom)
x 1
Other accessories (Installation manual, user's manual, other documentation)
Tip
When installing the main unit, some vehicle models may require the use of items that need to be obtained
separately such as a power supply adaptor cable, radio antenna adaptor cable or mounting bracket.
Check that all of the following components are present
Check that all of the following components are present
Interconnecting cable
2
(Power and speaker connector)
(16P) x 1
Splicing connector
6
x 1
Cable tie
10
(for GPS antenna) x 4
CD (including TomTom HOME
and the full manual) x 1
16 Production Code Card
x 1
Adapter plug
20
(for Europe)
x 1
- 2 -
Interconnecting cable
3
(Speed pulse, Genuine
steering remote control)
(8P) x 1
Screw
7
(M2x6) x 1
Pouch
13
x 1
17 PND connector cover
x 1
Hex-head bolt
4
(Red:M5x8) x 4
8 GPS antenna
x 1
14 USB Cable
x 1
18 Home Charger
x 1
