Components

Components
Main unit components
Main unit x 1
1
Hex-head bolt
5
(Red:M5x8) x 4
Earth plate
9
x 1
PND components
PND
11 12
x 1
PND connector cover
15
x 1
Other accessories (Installation manual, user's manual, other documentation)
Tip
When installing the main unit, some vehicle models may require the use of items that need to be obtained
separately such as a power supply adaptor cable, radio antenna adaptor cable or mounting bracket.
Check that all of the following components are present
Check that all of the following components are present
Interconnecting cable
2
(Power and speaker connector)
(16P) x 1
Flat head screw
6
(Red:M5x8) x 8
Cable tie
10
(for GPS antenna) x 4
CD (including TomTom HOME
and the full manual) x 1
16 Home Charger
x 1
- 2 -
Interconnecting cable
3
(Speed pulse, Parking, USB,
iPod, etc)
(14P) x 1
Splicing connector
7
x 3
Pouch
13
x 1
Interconnecting cable
4
(Reverse, Back-eye camera,
etc)
(16P) x 1
GPS antenna
8
x 1
14 USB Cable
x 1
