Example #1: Create Two VLANs
Use the following commands to create two VLANs and to assign the VLAN IDs while leaving the names
blank.
console(config)#vlan database
console(config-vlan)#vlan 2
console(config-vlan)#vlan 3
console(config-vlan)#exit
Example #2: Assign Ports to VLAN2
This sequence shows how to assign ports to VLAN2, specify that frames will always be transmitted
tagged from all member ports, and that untagged frames will be rejected on receipt.
console(config)#interface ethernet 1/g1
console(config-if-1/g1)#switchport mode general
console(config-if-1/g1)#switchport general allowed vlan add 2
console(config-if-1/g1)#switchport general acceptable-frame-type tagged-only
console(config-if-1/g1)#exit
console(config)#interface ethernet 1/g2
console(config-if-1/g2)#switchport mode general
console(config-if-1/g2)#switchport general allowed vlan add 2
console(config-if-1/g2)#switchport general acceptable-frame-type tagged-only
console(config-if-1/g2)#exit
Example #3: Assign Ports to VLAN3
This example shows how to assign the ports that will belong to VLAN 3. Untagged frames will be
accepted on ports 1/g3 and 1/g4.
Note that port 1/g2 belongs to both VLANs and that port 1/g1 can never belong to VLAN 3.
console(config)#interface ethernet 1/g2
cconsole(config-if-1/g2)#switchport general allowed vlan add 3
console(config-if-1/g2)#exit
console(config)#interface ethernet 1/g3
console(config-if-1/g3)#switchport general allowed vlan add 3
console(config-if-1/g3)#exit
console(config)#interface ethernet 1/g4
console(config-if-1/g4)#switchport general allowed vlan add 3
Example #4: Assign VLAN3 as the Default VLAN
This example shows how to assign VLAN 3 as the default VLAN for port 1/g2.
console(config)#interface ethernet 1/g2
console(config-if-1/g2)#switchport general pvid 3
