Rack Assembly; Parts Supplied With The Rack-Mount Kit - IBM 2498B24 - System Storage SAN24B-4 Switch Installation, Service And User Manual

EIA Rack Rail
Inner Slide
3
Front of Switch
7
2X
Figure 3. Rack assembly
1. Unpack the rack-mount kit and verify that all ordered items and parts are
Outer Slide
6
2X
2
present and undamaged. See Table 3 for a list of parts and the quantities
supplied.
Table 3. Parts supplied with the rack-mount kit
Item
1
2
3
4
5
6
7
8
9
10
11
12
4
4X
7
4X
6
5X
Description
Rack mount slide (inner and outer slide)
Right rack mount bracket (optional bracket
for front of switch)
Left rack mount bracket (optional bracket for
front of switch)
Rack mounting bracket (3-hole)
Nut clip, M5
Screw, 8-32 x 3/16 in., zinc
Screw, M5 x 12
Bracket to slide rack kit (contains items 9 -
12)
Screw, 8-32 x 3/8 in., zinc
Washer, flat, No. 8
Washer, lock, No. 8
Nut, hex, 8-32
Chapter 2. Installing and configuring the switch
9
7
8X
4X
See
1
Detail A
2X
5
4X
10
11
8X
8X
12
8X
Detail A
SJ000153
Quantity
2
1
1
4
11
11
11
1
5
5
5
5
11
