Autel MaxiCOM MK808S-TS Manual

Autel MaxiCOM MK808S-TS Manual

2024 complete tpms check/activate/relearn tool
Hide thumbs Also See for MaxiCOM MK808S-TS:

Advertisement

Quick Links

Download this manual
Trademarks
®
®
Autel
, MaxiSys
®
and MaxiCheck
in China, the United States, and other countries. All other marks are trademarks or
registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or transmitted in
any form or by any means electronic, mechanical, photocopying, recording, or
otherwise without the prior written permission of Autel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on the latest
information available at the time of printing.
Autel reserves the right to make changes at any time without notice. While information
of this manual has been carefully checked for accuracy, no guarantee is given for the
completeness and correctness of the contents, including but not limited to the product
specifications, functions, and illustrations.
Autel will not be liable for any direct, special, incidental, or indirect damages, or for any
economic consequential damages (including the loss of profits) as a result of using this
product.
IMPORTANT
Before operating or maintaining this unit, please read this manual carefully, paying
extra attention to the safety warnings and precautions.
For Services and Support
pro.autel.com
www.autel.com
1-855-288-3587/1-855-AUTELUS (North America)
0086-755-86147779 (China)
support@autel.com
For technical assistance in all other markets, please contact your local Autel selling
agent.
®
, MaxiDAS
, MaxiPRO
are trademarks of Autel Intelligent Technology Corp., Ltd., registered
®
®
, MaxiRecorder
i
®
, MaxiCOM
, MaxiTPMS
®
,

Advertisement

loading
Need help?

Need help?

Do you have a question about the MaxiCOM MK808S-TS and is the answer not in the manual?

Questions and answers

Related Manuals for Autel MaxiCOM MK808S-TS

Summary of Contents for Autel MaxiCOM MK808S-TS

  • Page 1 Autel will not be liable for any direct, special, incidental, or indirect damages, or for any economic consequential damages (including the loss of profits) as a result of using this product.
  • Page 2 The safety messages herein cover situations Autel is aware of at the time of publication. Autel cannot know, evaluate or advise you as to all of the possible hazards. You must be certain that any condition or service procedure encountered does not jeopardize...
  • Page 3 DANGER When an engine is operating, keep the service area WELL VENTILATED or attach a building exhaust removal system to the engine exhaust system. Engines produce carbon monoxide, an odorless, poisonous gas that causes slower reaction time and can lead to serious personal injury or loss of life. SAFETY WARNINGS Always perform automotive testing in a safe environment.
  • Page 4 CONTENTS 1 USING THIS MANUAL ....................1 ..................... 1 ONVENTIONS 1.1.1 Bold Text ...................... 1 1.1.2 Notes and Important Messages ..............1 1.1.3 Hyperlink ....................... 1 1.1.4 Illustrations ....................2 1.1.5 Procedures ....................2 2 GENERAL INTRODUCTION ..................3 COM MK808S-TS T ................
  • Page 5 ..................20 EHICLE DENTIFICATION 4.3.1 Auto Detect ....................20 4.3.2 Manual Input ....................22 4.3.3 Automatic Selection ..................23 4.3.4 Manual Selection ..................24 ....................... 24 AVIGATION 4.4.1 Diagnostic Screen Layout ................24 4.4.2 Screen Messages ..................27 4.4.3 Making Selections ..................27 ..............
  • Page 6 6.1.1 TPMS Service Menu Layout ............... 52 6.1.2 OEM Part NO..................... 53 6.1.3 Vehicle Manufacturer Buttons ..............53 ................... 53 EHICLE ELECTION 6.2.1 Auto Detect ....................53 6.2.2 Manual Input ....................55 6.2.3 Automatic Selection ..................56 6.2.4 Manual Selection ..................58 TPMS S ................
  • Page 7 7 TOOLKIT ........................85 8 TPMS RETROFIT ......................86 9 UPDATE ........................88 10 DATA MANAGER ...................... 90 10.1 ....................91 EHICLE ISTORY 10.1.1 Historical Test Record ................92 10.2 ................... 94 ORKSHOP NFORMATION 10.3 ......................94 USTOMER 10.4 ....................... 95 MAGE 10.5 ......................
  • Page 8 12.4 BAS U ....................108 PDATE 13 BATTERY TEST ....................... 109 13.1 BAS BT506 B ..............110 ATTERY ESTER 13.1.1 Function Description ................. 110 13.2 .................... 111 OWER OURCES 13.2.1 Internal Battery Pack ................111 AC/DC Power Supply — Using Power Adapter ........111 13.2.2 13.2.3 Technical Specifications ................
  • Page 9 18.1.4 Technical Specifications ................136 18.2 ....................136 PERATIONS 19 QUICK LINK ......................138 20 MAINTENANCE AND SERVICE ................139 20.1 ................139 AINTENANCE NSTRUCTIONS 20.2 ................. 140 ROUBLESHOOTING HECKLIST 20.3 ................... 140 BOUT ATTERY SAGE 20.4 ..................141 ERVICE ROCEDURES 20.4.1 Technical Support ..................
  • Page 10 Using This Manual This manual contains device usage instructions. Some illustrations shown in this manual may make reference to modules and optional equipment that are not included in your system. Contact your sales representative for availability of other modules and optional tools or accessories. 1.1 Conventions The following conventions are used: 1.1.1 Bold Text...
  • Page 11 1.1.4 Illustrations Illustrations used in this manual are samples; the actual testing screen may vary for each vehicle being tested. Observe the menu titles and on-screen instructions to make correct option selection. 1.1.5 Procedures An arrow icon indicates a procedure. Example: ➢...
  • Page 12 General Introduction Together with the ability to quickly read and clear DTCs for all available modules of the majority of the makes and models on the market, MaxiCOM MK808S-TS provides superior special functions, including Oil Reset, EPB (Electronic Parking Brake), SAS (Steering Angle Sensor), and BMS (Battery Management System).
  • Page 13 7.0” LCD Touchscreen Ambient Light Sensor — detects ambient brightness. Power LED — indicates battery level & charging or system status. TPMS Service Symbol — indicates the position of the embedded TPMS antenna. The power LED displays green, yellow or red depending on power level and operating state.
  • Page 14 Figure 2-3 Tablet Top View Micro SD Card Slot — holds the Micro SD card. HDMI (High-Definition Multimedia Interface) Port 10. USB Port 11. Power/Lock Button — turns the device on/off with long press, or locks the screen with short press. 2.1.2 Power Sources The tablet can receive power from any of the following sources: Internal Battery Pack...
  • Page 15 2.1.3 Technical Specifications Table 2-1 Specifications Item Description Recommended Use Indoor Operating System Android RK3566 Quad-core Arm Cortex-A55 processor Processor (1.8 GHz) Memory 4GB RAM & 64GB ROM Display 7-inch LCD screen with 1024 x 600 resolution ⚫ Mini USB 2.0 ⚫...
  • Page 16 Item Description Net Weight 885 g (2.31 lbs.) ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850PWM, ISO11898 (High-speed, Protocols Middle-speed, Low-speed and Single-wire CAN, fault-tolerant CAN), SAE J2610, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6 2.2 MaxiVCI Mini MaxiVCI Mini is a small vehicle communication interface (VCI) that wirelessly connects to the tablet vehicle’s data link connector (DLC) for vehicle data transmission.
  • Page 17 Table 2-2 Power LED Color Description Lights solid green when powered on. Green Flashes red when a system failure occurs. Power Note: The power LED briefly lights red each time the device powers on and then lights green when the device is ready. Table 2-3 Connection LED Color Description...
  • Page 18 2.2.3 Technical Specifications Table 2-4 Specifications Item Description ⚫ BT V.2.1 + EDR Communications ⚫ Mini USB 2.0 Wireless Frequency 2.4 GHz Input Voltage Range 12 V DC to 24 V DC Supply Current 150 mA @ 12 V DC Operating Temp.
  • Page 19 Getting Started Ensure the tablet is sufficiently charged or is connected to an external power supply (see Power Sources on page 5). NOTE The images and illustrations depicted in this manual may differ slightly from those in the most recent product. 3.1 Powering Up Long press the Power/Lock button on the top-right side of the tablet to power on the unit.
  • Page 20 NOTE The tablet screen is locked by default when first powered on. We recommend you lock the screen to protect the information in the system and conserve the power. The touchscreen navigation is menu-driven, enabling quick access to functions and features by tapping on the buttons on the screen.
  • Page 21 Remote Desktop on page Desktop 122 for details. Launches the Support platform which synchronizes Support Autel’s on-line service base station with the MaxiCOM tablet. See Support on page 124 for details. Unlocks the gateway ECU (CGW) for some vehicles to perform...
  • Page 22 Button Name Description MaxiTools Includes log collection and factory data reset two parts. Autel User Allows you to register an account, view and edit your Center personal profile and link your device. 3.1.2 Locator and Navigation Buttons Operations of the navigation buttons at the bottom of the screen are described in the...
  • Page 23 Button Name Description Display Supports the display brightness automatically or manually Brightness adjustment. Opens the VCI Manager application. The BT or the cable badge at the bottom-right corner indicates the tablet is Manager communicating with the VCI device. An X badge will display Shortcut at the bottom-right corner if the tablet is not connected to the VCI device.
  • Page 24 3.2.1 Reboot System In case of a system crash, long press the Power/Lock button and tap the Restart option to restart the system.
  • Page 25 Diagnostics The Diagnostics application can retrieve ECU information, read & erase DTCs, and view live data. The Diagnostics application can access the electronic control unit (ECU) for various vehicle control systems, including engine, transmission, antilock brake system (ABS), and airbag system (SRS). 4.1 Establishing Vehicle Communication Prior to performing the Diagnostics function, ensure the tablet is connected to the test vehicle through the MaxiVCI Mini.
  • Page 26 4.1.2.1 Bluetooth Connection Bluetooth pairing is recommended as the first choice for the communication between the tablet and the MaxiVCI Mini. This is because the Bluetooth connection does not need to repeat the plugging and unplugging procedure which is unavoidable when using traditional wired connection, saving more time and providing higher efficiency.
  • Page 27 displays with check instructions. The following conditions are the possible causes: The MaxiVCI Mini is unable to establish a communication link with the vehicle. ⚫ The system selected for testing is not equipped on the vehicle. ⚫ There is a loose connection. ⚫...
  • Page 28 4.2.1.1 Top Toolbar Buttons The operations of the toolbar buttons at the top of the screen are listed and described in the table below: Table 4-1 Top Toolbar Buttons Button Name Description Home Returns to the MaxiCOM Job Menu. Provides a fast way to identify the test vehicle. Vehicle Identification on page 20 for details.
  • Page 29 4.3 Vehicle Identification The MaxiCOM diagnostics system supports four methods for vehicle identification: Auto Detect Manual Input Automatic Selection Manual Selection 4.3.1 Auto Detect The MaxiCOM diagnostics system features the latest VIN-based Auto Detect function to identify vehicles and scan all the diagnosable ECUs and run diagnostics on the selected system.
  • Page 30 Figure 4-3 Auto Detect Screen Tap Yes to confirm the vehicle profile, or tap No if the information is incorrect. Figure 4-4 Vehicle Profile Screen The tool establishes communication with the vehicle and reads the control unit information. Choose Auto Scan to scan all the test vehicles’ available systems or tap Control Unit to access a specific system to diagnose.
  • Page 31 Figure 4-5 Diagnostic Menu Screen 4.3.2 Manual Input For vehicles not supporting the Auto Detect function, you may manually enter the VIN. ➢ To perform Manual Input Tap the Diagnostics application button from the MaxiCOM Job Menu. The Vehicle Menu displays. Tap the VID button on the top toolbar to open the dropdown list.
  • Page 32 Figure 4-6 Manual Input Screen Tap OK. Once the vehicle is identified, the Vehicle Diagnostics screen displays. at the top-right of the dialog box to exit Manual Input. 4.3.3 Automatic Selection The vehicle VIN can also be automatically acquired after a vehicle manufacturer is selected.
  • Page 33 ➢ To perform Automatic Selection Tap the Diagnostics application button from the MaxiCOM Job Menu. The Vehicle Menu displays. Select a vehicle manufacturer. Tap Automatic Selection and the VIN information will be acquired automatically. Follow the on-screen instruction to display the Diagnostic Menu screen.
  • Page 34 The Diagnostic Menu screen typically includes four sections: Diagnostics Toolbar Status Information Bar Main Section Function Buttons 4.4.1.1 Diagnostics Toolbar The Diagnostics Toolbar contains several buttons such as print and save. The table below provides a brief description for the operations of these buttons: Table 4-2 Diagnostics Toolbar Buttons Button Name...
  • Page 35 When encountering Data an error during testing and diagnosing, use this Logging function to contact Autel's technical staff for solutions. See Data Logging on page 98 for details. ➢ To print data in Diagnostics Tap the Diagnostics application button from the MaxiCOM Job Menu.
  • Page 36 4.4.1.4 Function Buttons The displayed Function Buttons vary depending on the stage of operations. These buttons can be used to navigate menus, to save or clear diagnostic data, to exit scanning, and to perform a number of other control functions. The use of these buttons will be discussed in detail in the following sections of the corresponding test operations.
  • Page 37 Control Unit — displays a selection menu for all available control units of the test vehicle. After a selection is made and the tablet establishes communication with the vehicle, the corresponding function menu or selection menu will display. 4.5.1 Auto Scan The Auto Scan function performs a comprehensive scanning over all the ECUs in the vehicle to locate systems faults and retrieve DTCs.
  • Page 38  : Indicates that the scanned system may not support the code reading function, or there is a communication error between the tablet and the control system.  -?-: Indicates that the vehicle control system has been detected, but the tablet cannot access it.
  • Page 39 4.6 Diagnostic Functions Figure 4-10 Function Menu Screen The Diagnostic Functions are listed on the Function Menu screen. The Function Menu options vary slightly for different vehicles, which may include: ECU Information — provides the retrieved ECU information in detail. An ⚫...
  • Page 40 4.6.1 ECU Information This function retrieves and displays the specific information for the tested control unit, including unit type, version numbers, and other specifications. Figure 4-11 ECU Information Screen Diagnostics Toolbar Buttons — see Table 4-2 Diagnostics Toolbar Buttons on page 25 for detailed descriptions of the operations for each button.
  • Page 41 Figure 4-12 Read Codes Screen Diagnostics Toolbar Buttons — see Table 4-2 Diagnostics Toolbar Buttons on page 25 for detailed descriptions of the operations for each button. Main Section Column 1 — displays the retrieved codes from the vehicle. ⚫ Column 2 —...
  • Page 42 ➢ To erase codes Tap Erase Codes from the Trouble Codes screen. A warning message displays to inform you of data clearing when this function is applied.  Tap Yes to continue. A Confirmation screen displays when the operation is successfully done. ...
  • Page 43 Main Section Name Column — displays the parameter names. ⚫ Check Box — tap the check box on the left side of the parameter name to make item selection. Tap the check box again to deselect the item. Drop-down Button — tap the drop-down button on the right side of the parameter name to open a sub menu, providing data display mode options.
  • Page 44 Each parameter item displays the selected mode independently. ◆ Analog Gauge Mode — displays the parameters in gauge charts. ◆ Text Mode — the default mode that displays the parameters as a text list. NOTE Status parameters, such as a switch reading like ON, OFF, ACTIVE, and ABORT, can only be displayed in Text Mode.
  • Page 45 Full Screen Display — this option is only available in the waveform graph mode, and mostly used in Graph Merge status for data comparison. There are four control buttons available on the top right side of the screen under this mode. Scale Button —...
  • Page 46 function will be executed and the device will automatically record and save the generated data. You can review the saved live data by tapping the Review button at the bottom of the screen. Tap the drop-down button on the right side of a parameter name to open a submenu.
  • Page 47 name. The mark is gray when it is not triggered, and displays orange when triggered. Moreover, two horizontal lines display on each of the data graphs (when Waveform Graph Mode is applied) to indicate the alarm point. The limit lines are shown in different colors to differentiate them from the parameter waveforms.
  • Page 48 ➢ To set live data record duration Tap the Setting button at the bottom of the Live Data screen. Tap the > button to the right of Recording Time After Trigger bar and select a time length. Tap OK to save the setting and return to the Live Data Setting screen; or tap the X button at the upper-right corner to exit without saving.
  • Page 49 Show Selected — displays the selected parameters. ⚫ Graph Merge — merges selected data graphs. ⚫ Back — exits the review and returns to the Live Data screen. ⚫ Back — returns to the previous screen or exits the function. 4.6.4 Active Test The Active Test function is used to access vehicle-specific subsystem and component tests.
  • Page 50 4.6.5 Special Functions These functions perform various component adaptations, including the recalibration or configuration of certain components after repairs or replacements have been completed. Figure 4-19 Special Function Screen 1 Select a function to display detailed information and the execution screen. Figure 4-20 Special Function Screen 2 List Tab Page: Column 1 —...
  • Page 51 ⚫ Column 2 — displays the execution status such as Completed or Activated or the corresponding live data values. ⚫ Column 3 — displays the measurement units of the live data. Tap a function button to perform the selected function or exit the function. 4.7 Generic OBDII Operations This option presents a quick way to check for DTCs, isolate the cause of an illuminated malfunction indicator lamp (MIL), check monitor status prior to emissions certification...
  • Page 52 Figure 4-21 OBDII Diagnostic Menu Select a function to continue. DTC & FFD ⚫ I/M Readiness ⚫ Live Data ⚫ On-Board Monitor ⚫ Component Test ⚫ Vehicle Information ⚫ Vehicle Status ⚫ NOTE The supported functions may vary by vehicles. 4.7.2 Function Descriptions This section describes the various functions of each diagnostic option: 4.7.2.1...
  • Page 53 Figure 4-22 DTC & FFD Screen Stored Codes ⚫ Stored codes are the current emissions-related DTCs from the ECU of the vehicle. OBDII/EOBD codes have a priority according to their emission severity, with higher priority codes overwriting lower priority codes. The priority of the code determines the illumination of the MIL and the codes erase procedure.
  • Page 54 Erase Codes ⚫ This option is used to clear all emissions-related diagnostics data including DTCs, freeze frame data, and specific manufacturer-enhanced data from the vehicle ECU. This option resets the I/M Readiness Monitor Status for all vehicle monitors to “Not Ready”...
  • Page 55 4.7.2.7 Vehicle Status This function checks the current condition of the vehicle, such as the communications protocols of OBDII modules, quantity of fault codes, and the status of the malfunction indicator light (MIL). 4.8 Exiting Diagnostics The Diagnostics application remains open as long as there is an active communication with the vehicle.
  • Page 56 Service The Service application is specially designed to provide quick access to the vehicle systems for various scheduled service and maintenance tasks. The typical service operation screen is a series of menu-driven executive commands. Follow on-screen instructions to select appropriate execution options, enter correct values or data, and perform necessary actions.
  • Page 57 ✓ been completed. NOTE Autel accepts no responsibility for any accident or injury arising from the maintenance of the Electric Parking Brake system. 5.3 Tire Pressure Monitoring System (TPMS) Service This function allows you to quickly look up the tire sensor IDs from the vehicle’s ECU, as well as to perform TPMS replacement and reset procedures after tire sensors are replaced.
  • Page 58 Accident repairs where damage to the steering angle sensor, SAS assembly, or any part of the steering system may have occurred. NOTE Autel accepts no responsibility for any accident or injury arising from servicing the SAS system. When interpreting DTCs retrieved from the vehicle, always follow the manufacturer’s recommendation for repair.
  • Page 59 driven more with higher load and speed. In order for regeneration to take place, a prolonged high exhaust temperature must be obtained. In the event of the car being driven in such a way that regeneration is not possible, i.e., frequent short journeys, a diagnostic trouble code will eventually be registered in addition to the DPF light and “Check Engine”...
  • Page 60 frequency identification between a transponder in the ignition key and a radio frequency reader in the steering column. When the key is placed in the ignition, the transponder sends a signal with a unique identification code to the reader, which relays it to a receiver in the vehicle's computer control module.
  • Page 61 TPMS The TPMS application is used to check the TPMS sensor conditions, program the MX-Sensor, and perform the TPMS Relearn procedure and other basic TPMS diagnostic functions. 6.1 Getting Started 6.1.1 TPMS Service Menu Layout Tap TPMS on the MaxiCOM Job Menu. The Vehicle Menu displays. Select a specific vehicle to perform TPMS service.
  • Page 62 ⚫ Manual Selection 6.2.1 Auto Detect Properly connect the tablet and vehicle first (refer to Establishing Vehicle Communication on page 16 for details), then tap the TPMS application button from the MaxiCOM MK808S-TS Job Menu to access the Vehicle Menu.
  • Page 63 ➢ To perform Auto Detect in TPMS application Tap the TPMS application button from the MaxiCOM Job Menu. The Vehicle Menu displays. Tap the VID button on the Top Toolbar to open the dropdown list. Figure 6-2 VID Screen in TPMS Application Select Auto Detect.
  • Page 64 Tap OK to confirm the vehicle information such as Model, Year, OEM Sensor Part NO., and Area, or tap ESC to return to the previous screen. Figure 6-4 Vehicle Information in TPMS Application Then the TPMS Service Menu will display. See Figure 6-14 TPMS Service Screen.
  • Page 65 Figure 6-5 Manual Input in TPMS Application A VIN Confirmation screen will display. If the VIN is correct, tap OK to enter the Vehicle Information screen. NOTE Before acquiring the vehicle VIN, make sure the tablet is connected to the network. After confirming the vehicle information, tap OK to enter the TPMS Service Menu.
  • Page 66 Figure 6-6 Vehicle Manufacturer Selection Tap Automatic Selection on the Select Diagnostic Type screen. Figure 6-7 Selection Screen in TPMS Application Tap Read to automatically acquire the VIN, or you can manually input the VIN information. If the VIN is correct, tap OK to proceed.
  • Page 67 Figure 6-8 Automatic Selection in TPMS Application Follow the on-screen instructions to confirm the vehicle information and finally enter the TPMS Service screen. See Figure 6-14 TPMS Service Screen. 6.2.4 Manual Selection You can also tap Manual Selection on the Select Diagnostic Type screen to select the vehicle information like model and year step by step.
  • Page 68 Figure 6-9 Vehicle Model Selection Figure 6-10 Vehicle Year Selection The following screen may display for vehicles using Indirect TPMS.
  • Page 69 Figure 6-11 Indirect TPMS Selection Screen For indirect TPMS vehicle, only the Relearn function is supported. Tap the vehicle year information button, in the case of the above screen — 2008/08-2019/12 (indirect), to display the Relearn Procedure screen. Follow the on-screen instructions to complete the operation.
  • Page 70 Figure 6-13 Relearn Procedure for Direct TPMS 6.3 TPMS Service Screen Layout The TPMS Service screen typically includes four sections: Figure 6-14 TPMS Service Screen Top Toolbar Buttons Navigation Tab Main Section Function Buttons...
  • Page 71 6.3.1 Top Toolbar Buttons The top toolbar contains a number of buttons. See Table 4-2 Diagnostics Toolbar Buttons on page 25 for details. 6.3.2 Navigation Tab The navigation tab at the top of the Main Section screen contains the following items: Check Tab —...
  • Page 72 Figure 6-15 Check Screen Sensor ID Tire Pressure Sensor Frequency Tire Temperature Sensor Battery Status Low Battery Icon Successfully Triggered NOTE The default check order on the tablet is LF (left front), RF (right front), RR (right rear), and LR (left rear). The wheel positions correspond with the descriptions on the right of the screen.
  • Page 73 ➢ To check the sensors Select the Check tab. Tap the desired wheel position on the vehicle thumbnail. Hold the tablet with its top-right corner (with the TPMS service symbol) close to the tire sidewall near the valve stem, and then tap the Trigger button. The tablet will send low frequency signal to trigger the sensor.
  • Page 74 6.5 TPMS Diagnostics The Diagnostics function is used to check the status of the TPMS system. This function requires connection with the test vehicle. Refer to Establishing Vehicle Communication on page 16 for details. ➢ To perform TPMS diagnostics function Tap the Diagnostics tab.
  • Page 75 Sensor IDs Retrieved by Activation Sensor IDs Retrieved by OBD — Saved in the TPMS ECU DTCs Retrieved by OBD — Existed in the TPMS ECU NOTE If the OBD function is supported by the test vehicle, the sensor ID saved in the TPMS ECU will be retrieved and displayed on the screen with an OBD mark before it when the communication is completed.
  • Page 76 Figure 6-19 DTCs Screen In the screen above, the detailed fault descriptions will be displayed. Select one of the DTCs and tap Search, the additional information will display. If no DTCs are present in the TPMS ECU, a green “No DTC” message will display in the DTC column.
  • Page 77 6.5.3 Clear DTCs Tap the Clear DTCs button, and the data trouble codes existed in the TPMS ECU will be cleared. 6.5.4 Live Data Tap Live Data to view the data stream of the sensor information. Figure 6-21 Live Data Screen All the parameters displayed on the Live Data screen are default values.
  • Page 78 The Programming function is used to program the sensor data to the MX-Sensor and replace the faulty senor (poor battery life or malfunction). NOTE Programming function will only work with Autel MX-Sensor. The 1-Sensor (Press In) is taken as an example in this manual. Please choose the proper MX-Sensor when programming.
  • Page 79 As shown in the screen above, there are four options available when programming MX-Sensor: Copy by Activation, Copy by OBD, Copy by Input, and Auto Create 1-20 Sensors. The main section of the screen may include: Column 1 — displays wheel positions. ⚫...
  • Page 80 Figure 6-25 Programming Screen 2 6.6.1 Copy by Activation This function allows the user to copy the retrieved sensor ID from the activated sensor to the new MX-Sensor. It is used after the original sensor is triggered. ➢ To copy by activation After performing TPMS check (see TPMS Check on page 62 for details), the...
  • Page 81 Figure 6-27 Copy by Activation Screen Figure 6-28 Copy by Activation Complete Screen When the programming is complete, the programmed ID will display in the column to the right of the wheel designation. In the pictured example, the new ID is displayed to the right of the LF column.
  • Page 82 NOTE If the IDs of the original sensor and the new MX-Sensor are the same and the ID is already registered to the vehicle ECU, there is no need to perform the Relearn function when the new programmed sensor has been installed to the same wheel. If the IDs retrieved from sensor activation and those registered to the TPMS ECU are different, tap Copy by OBD to program the IDs saved in the ECU to the new MX-Sensor.
  • Page 83 6.6.3 Copy by Input The Copy by Input function allows users to program a new MX-Sensor with the ID of an original TPMS sensor. ➢ To copy by input Select one sensor position and place a MX-Sensor near the TPMS antenna of the tablet (the top-right corner), then tap Copy by Input to program the new MX-Sensor.
  • Page 84 ➢ To auto create 1-20 sensors Select the vehicle model, and select a wheel location on the display and place the MX-Sensor(s) near the top-right corner of the tablet. Tap Auto Create 1-20 Sensors to program the new MX-Sensor. When the programming is complete, the programmed ID will display in the table on the screen.
  • Page 85 There are four ways for relearn, namely OBD Relearn, Automatic Relearn, Stationary Relearn, and Copy Relearn. The first three are new sensor ID relearn methods, while the Copy Relearn is a method to clone the sensor ID. 6.7.1 OBD Relearn OBD Relearn is completed via the OBD diagnostic function without needing to drive, and the relearn procedures are basically the same for different models.
  • Page 86 Figure 6-33 OBD Relearn Screen 2 6.7.2 Automatic Relearn Automatic Relearn requires driving to complete. For some vehicle models, the Automatic Relearn procedures can be completed directly by driving, while for some vehicle models, you need to follow the on-screen Learning Process Guide to let the vehicle enter the Automatic Relearn mode before driving.
  • Page 87 Figure 6-35 Automatic Relearn Screen 2 6.7.3 Stationary Relearn Stationary Relearn can be completed without relying on driving and the OBD diagnostics. To activate this mode, it is usually necessary to perform a series of operations to let the vehicle enter the relearn mode first, then use TPMS tools to perform activation or deflation to complete the relearn.
  • Page 88 Copy Relearn is to clone the sensor ID and tire location. Before performing Copy Relearn, you need to first obtain the sensor ID and tire location needed to be cloned, then use Autel tools to clone and program the sensor ID, and install the sensor to the corresponding tire to complete Copy Relearn.
  • Page 89 NOTE Ensure the original sensor will not interfere with the relearn procedures. It is recommended to keep the original sensor at least 100 meters away from the vehicle, or put the sensor in an enclosed metal box to avoid signal interference. Normally, it is not necessary to perform relearn procedures after cloning.
  • Page 90 6.8 TPMS by OEM Part NO. If the sensor’s OEM part number is known, this function is an efficient method to activate and program MX-Sensors. 6.8.1 Application Scenarios This method is ideal for the following two cases: 6.8.1.1 In the workshop If the mounted sensor is faulty and the part number is known to the technician, the technician can use this method to check the original sensor, and then write the retrieved information into a new MX-Sensor via Programming function.
  • Page 91 Or tap the search box on the top-right corner of the screen to enter the part number. Figure 6-41 OEM Part NO. Search Screen When a specific OEM part NO. is selected, the screen will display as below. Figure 6-42 OEM Part NO. Service Menu Screen NOTE Only sensor Check and Programming functions are available with the OEM Part NO.
  • Page 92 information. The original sensor ID, tire pressure, tire temperature, sensor battery status, and sensor frequency will populate the displayed table. Figure 6-43 Check Screen via OEM Part NO. 6.8.2.2 Programming The programming function is used to program the sensor data to the MX-Sensor and replace the faulty sensor (poor battery life or malfunction).
  • Page 93 PSN Code on MX-Sensor NOTE By tapping Auto Create 1-20 Sensors, up to 20 MX-sensors can be programmed at a time. The Product Serial Number (PSN) code, which is printed on the MX-Sensor, acts as a reference to identify the corresponding sensor ID. This can be especially useful when programming multiple MX-Sensors.
  • Page 94 ToolKit This chapter describes auxiliary functions for TPMS service and vehicle diagnostics. Figure 7-1 ToolKit Screen RKE & RF This function is used to check the signal strength of 315 and 433 MHz frequencies of remote keyless entry fobs. Unlock RED I 7002A This function is used to unlock the specified Redi-sensor: 7002A.
  • Page 95 Tap OK at the bottom of the screen to confirm the information of the vehicle. The Retrofit screen opens. Follow the instructions displayed on the screen, which will guide you to choose the procedure, including the Back-up, Retrofit, Restore, Program Autel ECU, Autel ECU Relearn and Service Function buttons. Figure 8-1 TPMS Retrofit Screen...
  • Page 96 NOTE The Retrofit screen has the same layout as the TPMS screen. After the retrofit function is finished, tap on the other tabs to perform optional functions. Accesses the TPMS Retrofit function either by tapping TPMS on the MaxiCOM Job Menu or by directly tapping TPMS Retrofit.
  • Page 97 Update The Update application on the tablet downloads the latest version of the software. The updates improve the MaxiCOM applications’ capabilities, typically by adding new tests, new model coverage or by adding new or enhanced applications. The tablet automatically searches for available updates for all of the MaxiCOM software when it is connected to the Internet.
  • Page 98 Status Bar Left Side — displays the account information, the MaxiCOM device model ⚫ information and serial number. Right Side — indicates the downloading speed. ⚫ Main Section Left Column — displays vehicle buttons. ⚫ Middle Column — displays a brief introduction about the new changes to the ⚫...
  • Page 99 Data Manager The Data Manager application allows you to store, print, and review the saved files, manage the workshop information, and customer information records, and keep test vehicle records. Selecting the Data Manager application opens the file system menu. There are nine main functions available.
  • Page 100 Button Name Description Tap to view the local reports on your tablet. If the report is successfully Report uploaded to cloud, you can also share the report with others. Tap to review the reports stored as PDF format. Review Data Tap to review the recorded data.
  • Page 101 Figure 10-2 Vehicle History Screen Top Toolbar Buttons — displays navigation and application controls. Main Section — displays all the vehicle history records. ➢ To activate a test session for the recorded vehicle Tap the Data Manager application on the MaxiCOM Job Menu. Select Vehicle History to open the screen.
  • Page 102 NOTE The MaxiCOM tablet must establish connection to the MaxiVCI Mini device to restart test sessions on the previously tested vehicles. Figure 10-3 Historical Test Record Sheet ➢ To edit the Historical Test record Tap Data Manager on the MaxiCOM Job Menu. Select Vehicle History.
  • Page 103 10.2 Workshop Information The Workshop Information form allows you to edit, input, and save the detailed workshop information, such as shop name, address, phone number, and other remarks, which, when printing vehicle diagnostic reports and other associated test file, will display as the header of the printed documents.
  • Page 104 NOTE The items that must be filled are indicated as required fields. Some customers may have more than one vehicle for service. You can always add new vehicle information to the account. Tap Add New Vehicle Information, and then fill in the vehicle information. Tap the button to cancel.
  • Page 105 Figure 10-5 Image Screen Top Toolbar Buttons — used to edit, print, and delete the stored image files. See the following table for detailed information. Main Section — displays the stored images. Table 10-2 Toolbar Buttons in Image Screen Button Name Description Back...
  • Page 106 Select the image(s) you want to edit by tapping the check box at the bottom-right corner of the image. Tap the Delete icon to delete the selected images or delete all images. Tap Print to print the selected image(s). Tap Email to send the selected image(s) to an email.
  • Page 107 This section uses the standard Adobe Reader application for file viewing and editing. Please refer to the associated Adobe Reader manual for more detailed instructions. 10.7 Review Data The Review Data section allows you to play back the recorded data frames of live data streams.
  • Page 108 10.9 Uninstall Apps This section allows you to manage the firmware applications installed on the MaxiCOM diagnostics system. Selecting this section opens a managing screen, on which you can check all available vehicle diagnostic applications. Select the vehicle firmware you want to delete by tapping on the vehicle manufacturer icon, the selected item will display a blue mark at the upper-right corner.
  • Page 109 Settings Access the Settings menu to adjust default settings and view information about the MaxiCOM system. The following options are available for the MaxiCOM system settings: Unit ⚫ Language ⚫ Printing Settings ⚫ Report Settings ⚫ Push Notifications ⚫ Auto Update ⚫...
  • Page 110 To install the PC Link driver program Download the Maxi PC Suite software from www.autel.com > Support > Downloads > Autel Update Tools, and install it to your windows-based computer. Double click on Setup.exe. Select the installation language and the wizard will load momentarily.
  • Page 111 NOTE ⚫ Make sure the tablet is connected to the same network with your computer, either via Wi-Fi or LAN, before printing. ⚫ Make sure the computer installed with the Printing Services program is connected to a printer. ➢ To perform printing through the PC Run the PC Link program on the PC.
  • Page 112 Per Week, Limit to 1 Notification Per Week, and Disable All Notifications. Select whichever you prefer. NOTE ⚫ Notifications will display on the screen. Slide the screen from top to check the received messages. If the message list covers more than one screen, slide the list up or down to view them.
  • Page 113 ➢ To adjust the vehicle list setting Tap Settings on the MaxiCOM Job Menu. Tap Vehicle list on the left column. Select the desired sort type. A check mark will display to the right of the selected item. Tap the Home button on the top-left corner to return to the MaxiCOM Job Menu, or select another setting option for the system setup.
  • Page 114 VCI Manager This application pairs the tablet with the MaxiVCI Mini, checks the communication status and update the VCI firmware. Figure 12-1 VCI Manager Screen Connection Mode — there are four connection modes available for selection. The connection status is displayed alongside. ⚫...
  • Page 115 12.1 VCI Bluetooth Pairing The MaxiVCI Mini needs to be connected to a vehicle, so that it is powered during the synchronization procedure. Ensure the tablet has sufficient battery power or is connected to an external power supply. ➢ To pair the MaxiVCI Mini with the tablet Power on the tablet.
  • Page 116 > Support > www.autel.com Downloads > Autel Update Tools, and install it onto your PC. Using a Mini USB cable to connect the MaxiVCI Mini to the PC. Launch the PC Suite on the PC which is installed after the installation of Maxi PC Suite and click the MaxiVCI Mini icon in the Device Selection window.
  • Page 117 12.4 BAS Update Before updating the battery tester firmware, please make sure the network connection is stable. ➢ To update the battery tester’s firmware Power on the diagnostic tablet and the battery tester. Connect the battery tester to the tablet via Bluetooth. Tap the VCI Manager application on the MaxiCOM Job Menu of the tablet.
  • Page 118 The Battery Test application allows the user to perform in-vehicle battery test and out-vehicle battery test functions when the BT506 battery tester is connected to the MaxiCOM MK808S-TS tablet and a battery. The BT506 battery tester enables technicians to view the health status of the vehicle's battery and electrical system.
  • Page 119 13.1 MaxiBAS BT506 Battery Tester 13.1.1 Function Description Figure 13-2 MaxiBAS BT506 Tester Power Button Status LED Power LED USB Port Battery Clamp Cable Table 13-1 LED Description Color Description The tester is communicating via USB Flashing Green cable. The tester is communicating via Status LED Flashing Blue Bluetooth.
  • Page 120 Color Description The tester is powered on and the Solid Green battery is sufficiently charged. The tester is charging. (Turns solid Flashing Green green when battery is fully charged.) Power LED Solid Red The device is in boot mode. The battery level is low. Please Flashing Red charge.
  • Page 121 13.2.3 Technical Specifications Table 13-2 Technical specifications Item Description ⚫ USB 2.0, Type C Connectivity Bluetooth 4.2 ⚫ Input Voltage 5 V DC Working Current < 150 mA at 12 V DC Internal Battery 3.7 V/800 mAh Lithium-ion Polymer battery CCA Range 100 to 2000 A Voltage Range...
  • Page 122 ➢ To pair with the MaxiCOM tablet Turn on both the MaxiCOM MK808S-TS tablet and the BT506 battery tester. Ensure that the units are sufficiently charged before you begin. Enable Bluetooth on the tablet by tapping VCI Manager > BAS BT. Tap Scan at the top-right corner.
  • Page 123 13.4 In-vehicle Test The In-vehicle Test is used for testing batteries that are installed in a vehicle. An in-vehicle test includes the Battery Test, Starter Test, and Generator Test. These tests help determine the health of the battery, the starter, and the generator. IMPORTANT A disclaimer will appear when first accessing any function on the Home screen.
  • Page 124 Please refer to the table below for a list of buttons that may appear when accessing the functions: Table 13-3 Top Toolbar Buttons Button Name Description The value on the icon indicates the real-time Battery voltage of the tested battery. In the battery test, Connection the button will turn green if the battery is good.
  • Page 125 Figure 13-6 Battery Screen Wait until the test is completed. The test results will be displayed on the tool. Figure 13-7 Battery Test Results Screen The battery test results include a color-coded results summary, a list of test data, and repair tips.
  • Page 126 Table 13-4 Test Results Result Repair Tip Good Battery Battery is good. Good & Battery is good but insufficiently charged. Recharge the battery. Recharge Charge & Retest Battery requires charge to determine its condition. Bad Cell Replace the battery. Replace Battery Replace the battery.
  • Page 127 Table 13-5 Starter Test Results Result Description Cranking Normal The starter is good. Current Too Low Low momentary discharge capacity. Voltage Too Low Low battery storage capacity. Not Started The starter is not detected for starting. 13.4.3 Generator Test Follow the on-screen instructions to complete the test. The test results will appear as follows: Figure 13-9 Generator Test Results Screen...
  • Page 128 Table 13-6 Generator Test Results Result Description Charging Normal The generator is functioning normally. The belt linking the starter and the generator is ⚫ loose; Output Too Low ⚫ The cable linking the starter and battery is loose or corroded. ⚫...
  • Page 129 Figure 13-10 Out-vehicle Test Screen The test results will display in a few seconds. Figure 13-11 Out-vehicle Test Results Screen...
  • Page 130 13.5.2 Test Results Table 13-7 Out-Vehicle Test Results Result Description Good Battery Battery meets required standards. Battery is good, but low on charge. Fully charge the Good & Recharge battery. Check for causes of low charge. Charge & Retest Battery requires charge to determine its condition. Replace Battery Battery fails to meet industry-accepted standards.
  • Page 131 The Remote Desktop application launches the TeamViewer QuickSupport program, which is a simple, fast, and secure remote-control interface. You can use the application to receive remote support from Autel’s support center, colleagues or friends, by allowing them to control your MaxiCOM tablet on their PC via the TeamViewer software.
  • Page 132 downloading TeamViewer program (full version) online (see http://www.teamviewer.com), and then launch the software. Provide your ID to your partner and wait for him/her to send you a remote-control request. A prompt will appear asking you to allow remote control on your device. Tap Allow to accept, or tap Deny to reject.
  • Page 133 15.1 Product Registration In order to get access to the Support platform and obtain update and other services from Autel, you are required to register the MaxiCOM tablet the first time you use it. ➢ To register the MaxiCOM tablet Visit the website: pro.autel.com.
  • Page 134 User Information — displays detailed information of your registered online Autel ⚫ account, such as your Autel ID, name, address, and other contact information. Device Information — displays the registered product information, including the ⚫ product serial number, registration time, expired time, and warranty period.
  • Page 135 Tap Send to deliver your message to Autel support. 15.5 Training The Training section provides quick links to Autel’s online video library. Select a video channel by language to see all available online tutorial videos on topics such as product usage techniques and vehicle diagnostics practice.
  • Page 136 Payment — displays questions and answers about online product payment ⚫ methods or procedures.
  • Page 137 OEM Authorization The OEM Authorization application allows you to unlock the gateway ECU (CGW) for some vehicles to perform advanced diagnostics tests. NOTE Make sure the tablet is connected to the Internet before launching the OEM Authorization application. ➢ To unlock the gateway ECU (CGW) Connect the MaxiCOM tablet to the vehicle through the MaxiVCI Mini.
  • Page 138 MaxiViewer The MaxiViewer allows you to search the functions supported by our tools and the software version information. There are two ways of searching, either by searching the tool and the vehicle or searching the functions. ➢ To Search by the vehicle Tap the MaxiViewer application on the MaxiCOM Job Menu.
  • Page 139 Figure 17-2 Function Viewer Screen 2 ➢ To search by the functions Tap the MaxiViewer application on the MaxiCOM Job Menu. The Function Viewer screen displays. Tap the tool name on the top-left to drop down the tool list. Tap the one you want to search.
  • Page 140 NOTE Fuzzy search is supported, so type in part of the function you want to search can also find out all the related information.
  • Page 141 MaxiVideo The MaxiVideo application configures the MaxiCOM diagnostics tablet to operate as a digital video scope by simply connecting the tablet to a MaxiVideo Camera. This function allows you to examine difficult-to-reach areas normally hidden from sight, with the ability to record digital still images and videos, which offers you an economical solution to inspect machinery, facilities, and infrastructure in a safe and quick way.
  • Page 142 18.1 Additional Accessories The MaxiVideo Camera and its fittings are the additional accessories. Both sizes (8.5 mm and 5.5 mm) of the imager head are optional and available for purchase along with the standard MaxiCOM tool kit. 18.1.1 MaxiVideo Camera Figure 18-1 MaxiVideo Camera Removable Imager Head Cable —...
  • Page 143 Mirror — helps to look around corners and see the unreachable areas. Hook — unclogs obstacles and picks up wires in the pipes or confined areas. Magnet — picks up small metal objects such as dropped rings or screws. Figure 18-3 5.5 mm Imager Head Accessories Mirror —...
  • Page 144 18.1.3.2 For 5.5 mm Imager Head The two accessories, including the Magnet and Mirror, can be attached to the Imager Head in the same manner described below: Hold the accessory and the imager head. Screw the thread part of the accessory over the imager head to fix the accessory.
  • Page 145 18.1.4 Technical Specifications Table 18-1 Specifications Item Description 0.79" to 2.36" (2 cm to 6 cm) with 8.5 mm ⚫ Optimal Viewing diameter imager head Distance ⚫ 0.79" to 2.36" (2 cm to 6 cm) with 5.5 mm diameter imager head ⚫...
  • Page 146 Select the Camera icon at the lower-right corner to take images. Tap the blue ring on the screen. The view finder now displays the captured picture and auto-saves the taken photo. Tap the thumbnail image on the top-right corner of the screen to view the stored image, slide the screen left or right to view the images.
  • Page 147 Quick Link The Quick Link application provides you with convenient access to Autel’s official website and many other well-known sites in automotive service industry to provide technical help, knowledge bases, forums, and training and expertise consultations. Figure 19-1 Quick Link Screen ➢...
  • Page 148 Maintenance and Service To ensure that the MaxiCOM diagnostic tablet performs at its optimum level, we advise that the product maintenance instructions covered in this section is read and followed. 20.1 Maintenance Instructions The following shows how to maintain your devices, together with precautions to take. Use a soft cloth and alcohol or a mild window cleaner to clean the touch screen of ⚫...
  • Page 149 Your device may have not been connected to the charger properly. Check the ⚫ connector. NOTE If your problems persist, please contact Autel’s technical support personnel or your local selling agent. 20.3 About Battery Usage Your tablet is powered by a built-in Lithium-ion Polymer battery. This means that, unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your tablet’s autonomy due to the “battery memory effect”...
  • Page 150 20.4.1 Technical Support If you have any question or problem on product operations, please contact us. Autel North America ⚫ Phone: 1-855-AUTEL-US (288-3587) (Monday-Friday, 9AM-9PM Eastern Time) ⚫ Fax: (631) 357-3304 ⚫ Email: Tech Support: ussupport@autel.com;...
  • Page 151 Address: 7th, 8th and 10th Floor, Building B1, Zhiyuan, Xueyuan Road, Xili, Nanshan, Shenzhen, 518055, China ⚫ Fax: 0086-755-8614-7758 ⚫ Web: www.auteltech.cn Autel Latin America ⚫ Phone: +52 33 1001 7880 (Spanish in Mexico)，+55 19 97816 4911 (Portuguese in Brazil) ⚫ Email: latsupport@autel.com (in Mexico);...
  • Page 152 20.4.2 Repair Service If it becomes necessary to return your device for repair, please contact us first and then download the repair service form from www.autel.com, and fill it in. The following information must be included: Contact name ⚫ Return address ⚫...
  • Page 153 Compliance Information FCC Compliance FCC ID: WQ8-MX808S-TS2152 This device complies with Part 15 of the FCC rules and Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 154 -- Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The radiated output power of this device is below the FCC radio frequency exposure limits.
  • Page 155 Warranty Limited One Year Warranty Autel Intelligent Technology Corp., Ltd. (the Company) warrants to the original retail purchaser of this MaxiCOM diagnostics device that should this product or any part thereof during normal usage and conditions, be proven defective in material or...
