- Page 1 GENERAL INFORMATION...
- Page 2 GENERAL INFORMATION This manual contains programming, operation, and complete parts and electrical wiring diagrams. The V-MAX controller is a microprocessor which will permit pricing per selection from 0.00 to 99.99. This machine also has space-to-sales programming. Specifications: MODEL V-MAX 720 V-MAX 840 V-MAX 576 SELECTIONS...
- Page 3 If the power requirements are not properly met, contact a licensed electrician and have the necessary correction made. Should you require additional information, contact the Technical Service Department of the Vendo office in your area.
- Page 4 CYCLE endo PHASE VENDING MACHINE REFRIGERATED THE VENDO COMPANY FRESNO, CA. POWER REQUIREMENTS FIGURE 4 NOTE: The Model number of the vending machine is located on the top, left hand corner of the serial plate. Do Not use the “BASIC UNIT” number.
- Page 5 STYLE A COIN INSERT COIN INSERT STYLE B STYLE C COIN INSTRUCTION LABEL PRICE DISPLAY PRICE DISPLAY COIN INSTRUCTION LABEL FIGURE 5 FIGURE 6 LABEL INSTALLATION COIN INSTRUCTION LABEL & PRICE LABEL APPLICATION: Apply labels to a clean and dry surface. Peel backing from label and apply with firm, even pressure.
- Page 6 COMPRESSOR DRAIN TUBE CONDENSATION PAN CONDENSER FAN BRACKET FIGURE 8 FIGURE 9 ALIGNMENT CHECKS DOOR ROLLER CHECK: The door support is to insure that the outer door closes squarely to the cabinet. Raising the door can also insure proper alignment of the door latch (see Figure 8). REFRIGERATION AREA CHECK: Check the position of the condensation pan (see Figure 9).
- Page 7 For specific information, refer to product set-up label on machine inner door or contact the Technical Service Department of the Vendo office in your area. Load product evenly. Bottles are loaded with crown end placed toward the back of the column.
- Page 8 VEND MECHANISM PARTS DESCRIPTION The parts listed below are part of the vend motor mechanism (refer to Figure 10 on page G-9). One mechanism is required per column. The parts are interchangeable. Setting will differ between single, double, triple, or quadruple depth. VEND MOTOR ASSEMBLY: P/N 1115821 The motor is attached to the mech.
- Page 9 GATE LINK: P/N 1120140 The rotation of the vend bucket moves the gate link. This opens the gate, allowing one layer of product to drop into the bucket. GAUGE BAR: P/N 1111651 The gauge bar holds the product(s) inside the bucket. It also regulates which product is vended first when double, triple or four deep settings are used (See page G-10 for motor cam settings).
- Page 10 VEND CYCLE Several operations take place during the vend cycle: When a selection is made, the cam and bucket rotate, product is dispensed and the bucket is then reloaded. The sequence of these operations change slightly when the column’s depth setting is changed. With the single depth setting, one purchase is made and the bucket is reloaded.
- Page 11 RELOADING SEQUENCE (See Figure 12) RS1. The gate link rests at a locked position in a cut out on the mech. plate. This locked position prevents the gate from opening out of sequence. RS2. The gate link is guided by a slot in the mech. plate and is actuated ridge on the bucket.
- Page 12 NOTES G-12...
