- Page 1 BYD Battery-Box HV User Manual Battery-Box H 5.1/6.4/7.7/9.0/10.2/11.5 Version 5.0...
- Page 2 6.2.2 Recharge Requirements When Over Discharged ................9 7 Compatible Inverter List ........................9 8 Common Issues and Solutions ......................9 8.1 Common Issues of BYD Battery-Box HV and Solutions ................. 9 8.2 Common Issues Displayed On Inverter and Solutions ................ 10 8.3 Emergency................................10 9 Warranty ............................
- Page 3 1 General Information 1.1 Validity This user manual is applicable to the BYD Battery-Box H 5.1 / 6.4 / 7.7 / 9.0 / 10.2 / 11.5. 1.2 Application This user manual contains BYD Battery-Box HV product information, usage guidance, safety information, and details on common operating issues and subsequent corrective actions.
- Page 4 BYD Battery-Box HV User Manual BCU: Battery Control unit and Base. Two parts consisting of both the battery management and control component mounted on top of the battery modules as well as structural base, which physically supports the battery modules underneath.
- Page 5 BYD Battery-Box HV User Manual Operation Precautions Do not touch the battery pack with wet hands. Do not crush, drop or puncture the battery. Always dispose of the batteries according to local safety regulations. Store and recharge battery in a manner in accordance with this user manual.
- Page 6 It will take 2 minutes for the charge current to adjust Discharge Current at Various Temperatures Ranges Temperature Range (℃) Normal Current(A) -10~40 40~50 0.5C -10 °C to 12 °C will be derating. BYD Compatible Inverter List is a document packaged with BCU or available on the website: www.eft-systems.de.
- Page 7 BYD Battery-Box HV User Manual 4 Technical Items Terms Comment Discharge Battery output power for load Charge To put electricity into battery by charger Full charged Battery had been full charged, SOC is 100%. Idle Ready for charging and discharging...
- Page 8 BYD Battery-Box HV User Manual Major Components: B-Plus H 1.28 Base 5.2 BYD Battery-Box HV Configuration Table Configuration Energy Name Voltage(V) (kWh) B-Plus H 1.28 Base Battery-Box H 5.1 5.12 160~225 Battery-Box H 6.4 6.40 200~282 Battery-Box H 7.7 7.68 240~338 Battery-Box H 9.0...
- Page 9 6 Cleaning and Maintenance 6.1 Cleaning It is recommended that the BYD Battery-Box HV system be cleaned periodically. If the enclosure is dirty, please use a soft，dry brush or a dust collector to remove the dust. Liquids such as solvents, abrasives or corrosive liquids should not be used to clean the enclosure.
- Page 10 ≤7 days 7 Compatible Inverter List To make sure that the system can operate normally, please choose BYD compatible inverters and size the battery quantity accordingly. For more details, please refer to the Compatible Inverter List. 8 Common Issues and Solutions 8.1 Common Issues of BYD Battery-Box HV and Solutions...
- Page 11 BYD Battery-Box HV User Manual If the BYD Battery-Box HV system has been connected to the router, user can monitor the running status of battery, warning, and alarm information via the built-in webpage, the log-in procedure is as following: Enter the correct IP address in the browser (IE, Google Chrome or Mozilla Firebox browsers are recommended), and then enter the account and password to log in (the login ID: user;...
- Page 12 Europe EFT-Systems GmbH Address: Buchenstr.37 97816 Lohr a. Main Customer Service Mailbox: service@eft-systems.de Telephone: +49 9352 8523999(DE) +34 91 0602267 (ES) +39 02 87368364 (IT) +44 2037695998 (UK) Website: www.eft-systems.de Copyright © BYD Lithium Battery Company Limited. All rights reserved.
