BYD BATTERY-BOX PREMIUM QUICK START GUIDE

Valid for HVS 5.1/ 7.7/ 10.2/ 12.8

HVM 8.3/ 11.0/ 13.8/ 16.6/ 19.2/ 22.1

BCU-V2.0

Please note that this is a Quick Start Guide only, which is a shortened assistance for the installation of the BYD Battery-Box Premium

HVS/HVM. It does not replace the Operating Manual, which must be read and understood completely before installation. Please

download and view it on this website: www.bydbatterybox.com.

Attention: High Voltage! Improper handling can pose a risk of electric shock and damage.

This guide and procedures described herein are intended for use by skilled workers only.

A skilled worker is defined as a trained and qualified electrician or installer who has all of the following skills and experience:

• Knowledge of the functional principles and operation of on-grid systems.

• Knowledge of the dangers and risks associated with installing and using electrical devices and acceptable mitigation methods.

• Knowledge of the installation of electrical devices.

• Knowledge of and adherence to this guide, the complete installation manual and all safety precautions and best practices.

In order to ensure the normal operation of the BYD Battery System, please download the app Be Connect 2.0 and then finish the

configuration in accordance with this document.

If there are errors generated during the commissioning or operation, please read the Service Guideline and Checklist alongside this

document, or digital version on the website.

If the battery system doesn't start at all, please contact BYD's local after-sales service team within 48 hours. Otherwise, the battery

could be permanently damaged.

Please do not stack up batteries without protective packages when storing or handling batteries, except for installation.

QR Code for the app.

Be Connect 2.0

Google Play

APP Store

Need help?

Do you have a question about the BATTERY-BOX PREMIUM and is the answer not in the manual?

Questions and answers

Summary of Contents for BYD BATTERY-BOX PREMIUM

Page 1 BCU-V2.0 Please note that this is a Quick Start Guide only, which is a shortened assistance for the installation of the BYD Battery-Box Premium HVS/HVM. It does not replace the Operating Manual, which must be read and understood completely before installation. Please download and view it on this website: www.bydbatterybox.com.
Page 3 1. Scope of Delivery Base Power Cable M4x14 Countersunk 6 mm² 10 mm² Communication HVS Module HVM Module Coupler Terminal Terminal Screw Connector Hanger (BCU Part) Documents Hanger (Wall Part) M5 Screw M6 Bolt and Nut Waterproof plug Terminal M4x14 Countersunk Resistor Screw 2.
Page 4 3. Tools Flat-head Screwdriver Network Wire Clamp Marker Phillips Screwdriver Bit Torque Wrench Wire Stripper Hydraulic Plier Wrench Tape Measure Drill YQK-240 Heat Gun Cylinder Screwdriver Connector Wrench Rubber Mallet Crimping Pliers 4. Installation Location Max +50 °C Min -10 °C RH.
Page 5 5. Connection Limitation 2 ≤ N ≤ 5 3 ≤ N ≤ 8...
Page 6 INVERTER INVERTER M = N L = M = N L ≠ M or l ≠ N or M ≠ N INVERTER INVERTER INVERTER ≤ 3 (Towers)
Page 7 9) HVM 19.3 10) HVM 22.1 1) 160-240 2) 240-360 3) 320-480 4) 400-600 5) 120-177 6) 160-236 7) 200-295 8) 240-354 9) 280-413 10) 320-472 -10°C~ 50°C Shenzhen BYD Electronics Co., Ltd. e.g., HVS XX 10 mm 8 Nm...
Page 8 7. Connection Diagram Single Tower INVERTER Terminal Resistor BAT COM Port for an inverter data cable IN port for parallel tower connection PE Cable OUT OUT port for parallel tower connection DC Cable Network port for connecting a router or network switch Grounding cable connecting point DC- to inverter Data Cable...
Page 9 8. Electrical Connections Multiple Towers (Ignore the Slave 1 in the drawing below to get the diagram of two towers) NOTE: Before making all electrical connections, please make sure the air switch on the BCU is off. 8.1 PE Connection INVERTER L = E + (2~3) mm SC10-5...
Page 10 8. Electrical Connections 8.2 DC Connection For 6mm² terminal For 10mm² terminal 10-12mm 11-13mm The burrs need to be trimmed. After trimming, they should not be higher than the right flange, and there should be no broken edges or wire Black Black core leakage.
Page 11 8.3 Connecting the Data Cable to an Inverter NOTICE e.g., CAN L Option a e.g., CAN H The connection diagram with di erent inverters could be INVERTER read in the section 13. Option b e.g., Min. CAT5e Max. 20m 8.4 Connecting the Data Cable to a Router (It's not mandatory, but recommended) T568B Router Min.
Page 12 Saved,encrypted policy and protect your personal information security. After you agree the policy, we will initialize the SDK and collect WLAN: BYD-XXXX BYD-XXXX your device information (such as device_id, MCC, MNC, etc.). You can click Setting- Saved,encrypted...
Page 13 Skip When adding modules, make sure the SOC of the existing tower is similar to the SOC of the extension module (normally about 30%) Configuration was done according to BYD Battery-Box Configuration/ Compatible Inverter List and Operating Manual. Next Next...
Page 14 11. Extension Note: Within 5 days before extension, it is recommended to fully charge the original system to SOC 100% at least once. Voltage = X New Battery Original Battery Voltage (X)/ V SOC (Y) SOC ≈ Y SOC ≈ Y X<100.80 0~5% 100.80≤X<103.20...
Page 15 13. Communication Options with Inverters SMA SBS 2.5/ 3.7/ 5.0/ 6.0 NOTICE Do not crimp the unused pins when making the communication cable NOTICE Battery-Box between the battery and the inverter. Parallel connection is not applicable to SMA Sunny Battery-Box Boy Storage 3.7-6.0.
Page 16 Kaco NH Sungrow SH5.0_6.0_8.0_10RT Sungrow SH3.0/ 3.6/ 4.0/ 5.0/ 6.0 RS BATTERY RJ45-1 RJ45-3 RJ45-5 GRID Terminal-1 Terminal-2 Terminal-3 COM0 RJ45-2 LOAD Sungrow Terminal-4 Battery-Box Kaco NH RJ45-1 RJ45-3 RJ45-5 Terminal-1 Terminal-2 Sungrow Terminal-3 Terminal-4 Battery-Box Battery-Box Kaco NH Battery-Box Battery-Box Kaco NH 1 2 3 4 5 6 7 8...
Page 17 Deye SUN-29.9-50K-SG01HP3-EU-BM4 GE GEH 5.0/ 8.6/ 10-1U-10 Solplanet Solplanet BMS1 BMS2 BATTERY RJ45-1 RJ45-3 RJ45-5 RJ45-1 RJ45-3 RJ45-5 GRID Terminal-1 Terminal-1 Terminal-2 COM0 Terminal-3 LOAD RJ45-2 Terminal-4 Terminal-2 Terminal-3 Terminal-4 Battery-Box Battery-Box Solplanet Battery-Box Deye Battery-Box Battery-Box Solplanet Battery-Box Deye 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8...
Page 18 Maxhub PHN(5-10)KT-BH2 Kontron Solar SolBrid 10-3-2/10-3-4 Maxhub Battery-Box Battery-Box Battery-Box Kontron Solar Kontron Solar 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Battery-Box Maxhub Cable Length≤...
Page 19 WLAN name, password and serial number.
Page 20 + 49 9352 8523999 / +44 (0) 2037695998(UK) + 61 2 8005 6688 + 86 755 89888888-47175 +34 91 060 22 67(ES) / +39 02 87368364(IT) No.3009, BYD Road, Pingshan, Shenzhen, 2/62 Belmore Road, Riverwood, NSW 2210 Bruchtannenstr. 28, 63801 Kleinostheim, Germany 518118, P. R. China www.eft-systems.de...
