- Page 1 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 FB3000 RTU 12-Channel Mixed I/O Module (3MIX12, 3MSG12) Field Installation Guide 3MIX12 Logic Module 3MSG12 Personality Module...
- Page 2 Emerson office. You can also receive the same quality training via our live, interactive Emerson Virtual Classroom and save on travel costs.
- Page 3 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Considerations when Removing/Replacing the 12-Channel Mixed I/O (3MIX12/3MSG12) The 12-Channel Mixed I/O Module consists of: A logic module (3MIX12) which resides in the upper position of the slot.
- Page 4 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Note You can install the 12-channel mixed I/O module in any open chassis slot, except slot 1 of the first (base) chassis which is reserved for the CPU.
- Page 5 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Removing/Replacing the 12-Channel Mixed I/O Logic Module DANGER EXPLOSION HAZARD: Never open the enclosure in a hazardous area. DANGER RISQUE D’EXPLOSION : Ne jamais ouvrir le boîtier dans une zone dangereuse.
- Page 6 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Squeeze the orange tabs at the top and bottom of the logic module (3MIX12) to release the module and slide it straight out of the slot. Removing an I/O Module Press the new replacement module into the slot until it is properly seated.
- Page 7 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Removing/Replacing the 12-Channel Mixed I/O Personality Module (3MSG12) DANGER EXPLOSION HAZARD: Never open the enclosure in a hazardous area. DANGER RISQUE D’EXPLOSION : Ne jamais ouvrir le boîtier dans une zone dangereuse.
- Page 8 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 When replacing an existing personality module that is already wired with an identical personality module, leave wiring connected to the terminal block, and disconnect the terminal block from the personality module by gently rocking the terminal block from side to side until it pops out.
- Page 9 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Press the new replacement personality module into the slot until it is properly seated, then tighten the captive fastening screw. Replacing a Personality Module If you replaced an existing personality module with an identical replacement, reattach the terminal block by pressing it into place.
- Page 10 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Wiring I/O on the Mixed I/O Personality Module (3MSG12) DANGER EXPLOSION HAZARD: Never open the enclosure in a hazardous area. DANGER RISQUE D’EXPLOSION : Ne jamais ouvrir le boîtier dans une zone dangereuse.
- Page 11 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Analog Input (AI) Analog Input (AI) Wiring Using 1-5VDC or 4-20mA External voltage source External current source Power Supply 30VDC Max...
- Page 12 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Analog Input (AI) Wiring Using Loop Power External current source Analog Output (AO) Analog Output (AO) Wiring...
- Page 13 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Digital Input (DI) Digital Input (DI) Wiring (internal pull-up enabled)
- Page 14 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Digital Output (DO) CAUTION Guard against overcurrent on the DO channel to avoid damage to the module. ATTENTION Protéger contre les surintensités sur le canal DO pour éviter d’endommager le module.
- Page 15 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Digital Output (DO) Wiring using the internal Loop Power Output Suppression diodes typical placements Switched load, relay coil shown Note The maximum load for the loop power output is 200 mA.
- Page 16 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Digital Output (DO) Wiring – Dry Contact Closure 500 mA load max field device 30VDC Max Power Supply DOHI_1/DOLO_1 configured as an internal dry contact DOHI_2/DOLO_2 configured as an internal dry contact...
- Page 17 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Digital Output (DO) Wiring – Contact Closure using 24V Loop Supply 500 mA load max field device...
- Page 18 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025 Pulse Input (PI) Pulse Input (PI) Wiring External Device (Because no power supply, requires enabling of internal pull-up) External Device 30VDC Max Power Supply Control signal...
- Page 19 DeltaV FB3000 RTU 12-Channel Mixed I/O Module Field Installation Guide D301873X012 April 2025...
