Advantech WISE-4250 Startup Manual

WISE-4250
Industrial Wireless Wi-Fi 2.4/5 GHz I/O and Sensing
Module
Startup Manual
Overview
Thank you for purchasing this WISE-4250 series module.
This is a quick guide to help you deploy the WISE-4250
series module in your application field. It includes power
and application wiring. If you need more instructions, please
refer to the user manual on the Advantech website.
Furthermore, Advantech IoT Academy has produced a
series of outstanding free courses, where IoT experts guide
you in rapidly acquiring product technical knowledge and
developing IoT projects. It is strongly recommended that
you view the videos prior to product use. You can find the
courses here: https://academy.advantech.com/en/courses
Input Power Requirements
The WISE-4250 series system is designed for a standard
industrial unregulated 24 V
plications, it can also accept +10 to +50 V
200mV peak to peak power ripple. The immediate ripple
voltage should be between +10 and +50 V
Packaging List
• 1 x WISE-4250 module with bundled antenna and termi-
nal connector
• 1 x Mounting bracket
• 1 x Startup Manual with China RoHS declaration
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service:
http://support.advantech.com/
This Startup Manual is for the WISE-4250 Series.
Part No. 2041425011
Printed in Taiwan
power supply. For some ap-
DC
power input,
DC
.
DC
Edition 2
March 2025
Switch Settings
Switch Description
Operation
SW1
Mode
Note: After position 1 of SW1 has been changed, users
need to power on the module again to apply the
new operating mode.
WISE-4250 Startup Manual 1
ON
Position
(Default)
Normal
P1
Mode
P2 N/A
OFF
Initial
Mode
N/A
