Advantech WISE-2211 Startup Manual

WISE-2211
LPWAN Self-powered Sensor Node
Startup Manual
Overview
Thank you for purchasing the WISE-2211 module. This
quick start guide is intended to help you deploy your new
module. The guide contains basic information on the power
and application wiring.
Should you require additional instructions, please refer to
the user manual.
Input Power Requirements
WISE-2211 is self-powered sensor node, power source
comes from an analog input which is connected to a
4~20mA sensor transmitter. In other words, WISE-2211
measures data and gets power current from a connected
sensor transmitter.
Packaging List
• 1 x WISE-2211 module
• 1 x Mounting bracket
• 1 x Quick start manual
• 1 x China RoHS declaration (UA series only)
*Antenna should be ordered as per required frequency
range.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service:
https://www.advantech.com/support/
This startup manual is for WISE-2211.
Part No. 2043221101
Printed in Taiwan
I/O Pinout & Application Wiring
Analog Input current: Direct Current
(4~20mA)
Quick Start
1. Connect the module to your computer via the micro-
2. Open WISE Studio and click Go To Configuration.
2nd Edition
Nov 2019
USB port.
WISE-2211 Startup Manual 1
