About PGPx914
The PGPx914 is a microprocessor-controlled wireless digital PIR detector, with optional pet immunity.
The device has the following features:
Dealer lock down
Two-factor authentication
Fresnel and cylindrical lenses with uniform detection sensitivity throughout its operating range, up to 12
meters (39 ft)
Target Specific Imaging™ (TSI) technology is used for distinction between humans and pets weighing up to 38
kg (85 lb)
The advanced True Motion Recognition™ algorithm (patented) distinguishes between the true motion of an
intruder and any other disturbances which may cause false alarms
No vertical adjustment is needed
Motion event counter determines whether one (high sensitivity) or two (low sensitivity) consecutive motion
events trigger an alarm
Very low current consumption
Microprocessor-controlled temperature compensation
Front and back tamper protection
Temperature sensing and reporting
Remote firmware upgrade
Low battery indication
Battery reporting
Installation guidelines
The reference to PGPx914 throughout this manual includes the models PGP9914
CAUTION: Only qualified personnel may install this equipment. Place this device in non-hazardous indoor
locations only.
Important: Check the device and the entire alarm system weekly to ensure optimal performance.
Note: To comply with FCC and ISED Canada RF exposure compliance requirements, locate the device at a
distance of at least 20 cm from all persons during normal operation. Do not co-locate the antennas used for
this product, or operate them in conjunction with any other antenna or transmitter.
PGPx914 Wireless PIR Motion Detector
D-308445 PGPx914 Rev. 02
Installation Guide
*D-308445*
D-308445

Advertisement

loading
Need help?

Need help?

Do you have a question about the PGP 914 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Johnson Controls PGP 914 Series

  • Page 1 PGPx914 Wireless PIR Motion Detector Installation Guide About PGPx914 The PGPx914 is a microprocessor-controlled wireless digital PIR detector, with optional pet immunity. The device has the following features: • Dealer lock down • Two-factor authentication • Fresnel and cylindrical lenses with uniform detection sensitivity throughout its operating range, up to 12 meters (39 ft) •...
  • Page 2 Installation guidelines Figure 1: PGPx914 Callout Description Lens Battery pull-tab Enroll button Tamper switch For more information refer to About PGPx914. Figure 2: Optimizing detection and avoiding false alarms 1. Do not install near high-voltage electrical lines. 2. Keep away from heat sources. 3.
  • Page 3 Enrolling the device Enrolling the device Refer to the control panel installation manual for the complete set of enrollment instructions and testing procedures. From the Installation menu, select Devices > Security Sensors > Auto Learn Sensorto add a new device. Remove the battery pull-tab to power on the device and begin the auto-enrollment process.
  • Page 4 Configuring the device parameters Configuring the device parameters Enter the DEVICE SETTINGS menu and select the required configuration as described in the following table. On the IQ panel, select Installation > Devices > Security Sensors > Edit Sensor Table 1: Configuration options Option Action Activation LED...
  • Page 5 Installing the pet mask Installing the pet mask Install the pet mask if you require pet immunity. The optimal installation height for pet immunity is 2.1 m (7 ft), measured from the center of the device. Pet immunity is for pets weighing up to 38 kg (85 lb). Note: Pet mask not evaluated by UL/ULC Note: Pet immunity is not supported at heights of 2.4 m (8 ft) and above.
  • Page 6 Removing the pet mask To close the device cover, clip the cover onto the device base and tighten the cover screw. See the following figure. Figure 5: Closing the device cover Removing the pet mask Remove the pet mask if you do not require pet immunity. Open the device cover.
  • Page 7 Mounting the device using tape Mounting the device using tape Important: When the device is mounted using tape, back tamper protection is not available Peel the release liners off the two strips of double-sided adhesive tape and attach the tape to the back of the bracket.
  • Page 8 Mounting the device using screws Mounting the device using screws Note: Mounting using screws is required for UL/ULC commercial burglary and residential fire type installations. Wall tamper (break-away segment) shall also be enabled. Note: Make sure to fasten the break-away segment to the frame. If the device is forcibly removed from the wall, this segment will break away from the base, causing the tamper switch to open.
  • Page 9 Mounting the device using screws Callout Component Corner mounting insert Corner bracket Stopper snap Break-away segment Screw the corner bracket to the wall. See C in the previous figure. Optional: If the installation surface does not allow for mounting the bracket with screws in the right side, screw the corner bracket using the two left side screw holes.
  • Page 10 Disassembling the device from the bracket Disassembling the device from the bracket Open the device cover. See Figure Remove the battery. Use a screwdriver to press on the stopper snap to release the device base from the bracket. See A1 in the following figure.
  • Page 11 Local diagnostics test Figure 13: Battery removal and insertion Press down on the battery until it fits into place. Close the device cover and fasten the cover screw. See Figure Note: After restoring a low battery, the system may take up to 5 minutes to clear the trouble. Local diagnostics test After power-up or closing the cover, the device automatically enters Test Mode for 15 minutes.
  • Page 12 Local diagnostics test Figure 14: Coverage pattern walk test Fresnel and cylinder type lens with optical attenuation (pet mask) in the lower pattern part of the lens. Number of beams / curtains: 18 Fresnel far, 10 Cylinder mid, 6 Cylinder close. Important! Instruct the user to walk test at least once a week to verify proper function of the device.
  • Page 13 Specifications Specifications Frequency band 912 to 919 MHz Modulation GFSK Communication Protocol PowerG Battery Type 3 V Lithium CR-123A Panasonic, Duracell, and GP only Battery Life 6 to 8 years with typical use at room temperature 25°C (77°F) Note: Not evaluated by UL/ULC. Low Battery Threshold 2.4 V at room temperature 25°C (77°F) Operating Temperature...
  • Page 14 Compliance with standards Le dispositif doit être placé à une distance d'au moins 20 cm à partir de toutes les personnes au cours de son fonctionnement normal. Les antennes utilisées pour ce produit ne doivent pas être situés ou exploités conjointement avec une autre antenne ou transmetteur.
  • Page 15 Limited Warranty Limited Warranty Digital Security Controls warrants that for a period of 12 months from the date of purchase, the product shall be free of defects in materials and workmanship under normal use and that in fulfilment of any breach of such warranty, Digital Security Controls shall, at its option, repair or replace the defective equipment upon return of the equipment to its repair depot.
  • Page 16 EULA EULA IMPORTANT READ CAREFULLY: DSC Software purchased with or without Products and Components is copyrighted and is purchased under the following license terms: This End User License Agreement ("EULA") is a legal agreement between You (the company, individual or entity who acquired the Software and any related Hardware) and Digital Security Controls, a division of Tyco Safety Products Canada Ltd.
  • Page 17 EULA (e) Software Product Transfer - You may transfer all of Your rights under this EULA only as part of a permanent sale or transfer of the HARDWARE, provided You retain no copies, You transfer all of the SOFTWARE PRODUCT (including all component parts, the media and printed materials, any upgrades and this EULA), and provided the recipient agrees to the terms of this EULA.
  • Page 18 SOFTWARE PRODUCT to fail to perform as expected. Website: www.dsc.com Tech. support: 1-800- 387-3630 29011099R003   ©2025 Johnson Controls. All rights reserved. JOHNSON CONTROLS and DSC are trademarks and/or registered trademarks. Unauthorized use is strictly prohibited. D-308445 PGPx914 Rev. 02...
