Regency Fireplace Products Energy E33 Owners & Installation Manual

Natural gas / propane gas insert
Hide thumbs

Advertisement

Quick Links

Download this manual
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
919-379m
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Energy
MODELS:
E33-NG10 Natural Gas
Owners & Installation Manual
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
E33 Gas Insert
™
E33-LP10 Propane
05.08.23

Advertisement

loading
Need help?

Need help?

Do you have a question about the Energy E33 and is the answer not in the manual?

Questions and answers

Related Manuals for Regency Fireplace Products Energy E33

Summary of Contents for Regency Fireplace Products Energy E33

  • Page 1 Energy E33 Gas Insert ™ MODELS: E33-NG10 Natural Gas E33-LP10 Propane Owners & Installation Manual WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 2 Each appliance shall bear a Class IIIB marking with letters on a contrasting background, located adjacent to the controlling device or in an equally conspicuous position where the instruction can be easily read. Energy E33 Video April 22/14: Created draft...
  • Page 3 dimensions UNIT DIMENSIONS LOW PROFILE FACEPLATE 32-1/4” 819mm 24-1/2” (622mm) " (83mm) 2 " " (1181mm) (44mm) 16 " (1078mm) (281mm) 4 " (413mm) This appliance does not have the capability to adjust the fan speed using the supplied remote — even though the remote transmitter allows this function.
  • Page 4 dimensions UNIT DIMENSIONS OPTIONAL VIGNETTE FACEPLATE WITH SPACER E33-10 FPI Direct Vent Gas Insert...
  • Page 5 dimensions UNIT DIMENSIONS OPTIONAL VIGNETTE FACEPLATE WITHOUT SPACER E33-10 FPI Direct Vent Gas Insert...
  • Page 6 dimensions UNIT DIMENSIONS OVERSIZE BACKINGPLATE WITH SPACER E33-10 FPI Direct Vent Gas Insert...
  • Page 7 dimensions UNIT DIMENSIONS OPTIONAL 4 SIDED VIGNETTE FACEPLATE 4 SIDED VIGNETTE FACEPLATE E33-10 FPI Direct Vent Gas Insert...
  • Page 8 dimensions GAS INSTALLATION CHECKLIST REGENCY GAS INSTALLATION CHECKLIST This general checklist does not contain all pertinent installation details or specifics and does not supersede the guidelines in this manual. Your Regency dealer/installer should use it in conjunction with manual instructions. Please follow all local codes and jurisdictions in authority. Customer: Date Installed: Install Address:...
  • Page 9 installation REGENCY GAS INSTALLATION CHECKLIST Finishing If applicable, is only noncombustible material installed in the noncombustible areas? Do clearances meet installation and manual requirements? Do the mantels and/or projections comply with the installation manual? If applicable, was the solid fuel fireplace warning plate installed? Appliance Media Setup Do commands from the remote or wall switch light the pilot and main burner? Are the burner media/log set, glass door, and screen installed per instructions in the manual?
  • Page 10 table of contents Dimensions Oversize Backing Plate Installation ......27 Optional Vignette Inlay Installation ......28 Unit Dimensions ............3 Optional Hearth Trim Installation - Vignette Faceplate with Low Profile Faceplate ..........3 Spacer and Low Profile Faceplate ......30 Unit Dimensions ............4 Optional Hearth Trim Installation - Optional Vignette Faceplate with Spacer .....4 Vignette Faceplate without Spacer ......31 Unit Dimensions ............5...
  • Page 11 safety decal This is a copy of the labels that accompany each E33 Gas Insert. We have printed a copy of the contents here for your review. The safety label is located on a plate inside the base of the unit visible when the bottom louver is opened. Ensure that the safety label is attached to the unit. NOTE: Regency units are constantly being improved.
  • Page 12 requirements MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:...
  • Page 13 installation IMPORTANT MESSAGE CHILDREN AND ADULTS SHOULD 2) Installation and repair should be done by SAVE THESE BE ALERTED TO THE HAZARDS OF a qualified service person. HIGH SURFACE TEMPERATURES, INSTRUCTIONS ESPECIALLY THE FIREPLACE GLASS, 3) The appliance should be inspected before use and at least annually by a professional service AND SHOULD STAY AWAY TO AVOID person.
  • Page 14 installation SPECIFICATIONS INSTALLATION 9) Install standard and optional features. Refer to the following sections where applicable: CHECKLIST At pressures over 1/2 psig, the pipe to the unit a. Brick Panels must be disconnected. Before installing vent system ensure that the damper b.
  • Page 15 installation GAS PRESSURE FACTORY-BUILT (METAL) TESTING WOOD-BURNING FIREPLACE REQUIREMENTS The appliance must be isolated from the gas sup- ply piping system by closing its individual manual NOTE: Any parts that are removed must be removed shut off valve during any pressure testing of the in a way that would allow them to be re-installed if gas supply piping system at test pressures equal the insert is ever removed (removal of rivets or...
  • Page 16 installation MINIMUM FIREPLACE OPENING The minimum fireplace opening for the Regency gas fireplace insert is shown in the following diagram and the table: Front Depth Max Lintel Bar Depth Height Depth Width (Rear) Width (Front) Width Prior to Taper Low Profile Faceplate 16-3/4"...
  • Page 17 installation MINIMUM FIREPLACE OPENING (LOW PROFILE FACEPLATE AND SPACER) The minimum fireplace opening for the Regency gas fireplace insert is shown in the following diagrams: MINIMUM CLEARANCES TO COMBUSTIBLES From Unit Side Walls * A 8" (203 mm) Ceiling 47" (1194 mm) Min.
  • Page 18 installation GAS CONNECTION Part # Description 948-305 3" Flex - 35 ft. GAS CONNECTION 946-529 Regency Co-linear DV Vertical Termination Cap WARNING: Only persons licensed to work Alternate Approved Caps with gas piping may make the 46dva-VC Vertical Termination Cap necessary gas connections to 46dva-VCH High Wind Cap 46dva-GK...
  • Page 19 installation REMOTE RECEIVER INSTALLATION DC SPARK IGNITER BATTERY INSTALLATION 1) Install the heat shield to the receiver with two screws. Install the supplied battery into the DC Sparker Box by opening the battery compartment. NOTE: The battery in the DC Sparker Box will need to be replaced annually.
  • Page 20 installation 7) Insert the back panel by sliding it between the OPTIONAL 4) Remove the two screws from the bottom of sidewalls of the firebox and the rear log support. the baffle plate. Install the bottom clips onto BRICK PANEL the baffle plate (refer to Diagram 1).
  • Page 21 DIRECT VENT FIREPLACE installation LOG SET INSTALLATION LOG INSTALLATION WARNING: 3) Remove the grate by removing the two Phillips Dangerous operating conditions may occur if these screws. Slide the grate outwards to remove it from logs are not positioned in their correct certifi ed loca- the unit (refer to Diagram 1).
  • Page 22 DIRECT VENT FIREPLACE installation 7) Align the bottom grooves of log 03-21 onto the right side of the grate and gently slide the log back until it touches the locating tab (refer to Diagram 4 & 5). 03-23 03-21 03-21 03-17 Locating Diagram 7...
  • Page 23 DIRECT VENT FIREPLACE installation 12) Place log 03-19 over the left center of the grate. Ensure the log set looks like Diagram 12. 03-23 03-18 03-22 03-20 03-17 Diagram 10 03-19 Diagram 12 11) Place log 03-24 over log 03-23 and log 03-21 ensuring the pin hole of log 03-24 lines up with the right pin of log 03-23 and the right pin of log 03-21 13) Separate platinum embers and place at the front...
  • Page 24 E33-10 installation Conversion from NG to LP CONVERSION KIT 342-969 FROM NG TO LP for E33-10 using SIT 829 NOVA Gas Valve for E33-10 using SIT 829 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION!! 6. Unscrew the pilot orifice with the 5/32"...
  • Page 25 installation E33-10 OPTIONAL VIGNETTE FACEPLATE INSTALLATION OPTIONAL VIGNETTE FACEPLATE INSTALLATION 1. Install the lower trim to the unit with 2 screws on each side as shown in the drawing below. 4. Tuck the wires into the silver box and secure them with a small grommet.
  • Page 26 installation E33-10 SPACER INSTALLATION FOR 3 SIDED VIGNETTE FACEPLATE SPACER INSTALLATION FOR 3 SIDED VIGNETTE FACEPLATE 3. Finally, attach the spacer to vignette faceplate (vignette NOTE: faceplate is purchased separately) with 2 side screws • A spacer can be ordered, if required. on the top (1 per side).
  • Page 27 installation E33-10 OVERSIZE BACKING PLATE INSTALLATION OVERSIZE BACKINGPLATE INSTALLATION OVERSIZE BACKING PLATE INSTALLATION OVERSIZE BACKING PLATE INSTALLATION WITH WITHOUT SPACER SPACER Oversize backing plate can be ordered for the unit 1) Install the spacer to the back of the faceplate backing with 6 if required.
  • Page 28 installation OPTIONAL VIGNETTE INLAY INSTALLATION OPTIONAL VIGNETTE INLAY INSTALLATION 1. Remove 5 screws from the backside of the Vignette frame cover 3. Place the Inlay on the Front Trim Assembly. and keep them aside (3 at bottom and 2 at top). Vignette Frame Vignette Frame Cover 2.
  • Page 29 installation E33-10 6. Reverse step1. 5. With the Inlay in position, place the mesh screen over the inlay. NOTE: The flush side of the mesh screen should face the inlay. 7. Install the Vignette frame with Inlay onto the 2 hooks provided on the unit.
  • Page 30 installation LRI4E/HRI4E/LRI6E/HRI6E/E33 OPTIONAL HEARTH TRIM INSTALLATION- VIGNETTE FACEPLATE WITH SPACER AND LOW OPTIONAL HEARTH TRIM INSTALLATION - PROFILE FACEPLATE VIGNETTE FACEPLATE WITH SPACER AND LOW PROFILE FACEPLATE Customizing the Hearth Trim: 5) Secure the hearth trim with a clip on its side to keep it steady as shown in the diagram below . The Hearth Trim can be adjusted to custom fit an installation by pulling apart the top piece from the bottom piece. Minimum height of the hearth trim is 2” and can be adjusted up to maximum 6”. 1) Cut the top of the bottom piece of the hearth trim to the appropriate height using a metal cutting blade. Clip - secures hearth trim NOTE: The tab bends at the back of the top piece of the hearth trim should be used as the measuring point to the hearth to measure the...
  • Page 31 LRI4E/HRI4E/LRI6E/HRI6E/E33 installation OPTIONAL HEARTH TRIM OPTIONAL HEARTH TRIM INSTALLATION- VIGNETTE FACEPLATE WITHOUT SPACER INSTALLATION - VIGNETTE FACEPLATE WITHOUT SPACER Customizing the Hearth Trim The Hearth Trim can be adjusted to custom fit an installation by pulling apart the top piece from the bottom piece. Minimum height of the hearth trim is 2” and can be adjusted up to maximum 6”. 1. Discard the spacer brackets, as these are not required when installing the unit without spacer. 2. Cut the top of the bottom piece of the hearth trim to the appropriate height using a metal cutting blade.
  • Page 32 installation LOW PROFILE FACEPLATE INSTALLATION Low profi le faceplate installation A spacer is supplied and may be installed if required to extend the 4. Tuck the wires into the clip to keep them away from the insert using depth of the faceplate by 1-3/4". Install the spacer onto the back the clip provided.
  • Page 33 installation 11. Run the power cord out on the left side of the unit. Attach the 2 bottom louver hinges to the bottom fl ange on the fi rebox using 2 screws per hinge. 12. Line up the brackets on the outer faceplate with the slots on the faceplate backing–hook outer faceplate on to slots and lower to install.
  • Page 34 installation E33-10 OPTIONAL HEARTH TRIM INSTALLATION- LOW PROFILE OPTIONAL HEARTH TRIM INSTALLATION- LOW PROFILE If you do not have spacer, remove the spacer brackets from the heart trim by removing 3 screws per side. Refer to diagrams 1 and 2 below. Diagram 1-Top View Spacer Brackets Front...
  • Page 35 installation SAFETY SCREEN INSTALLATION / REMOVAL - LOW PROFILE FACEPLATE 1. To remove safety screen, flip open bottom louver and remove 2 screws 2. Pull off safety screen and frame from glass door. in locations shown below. 3. To install, reverse Steps 2-1. STANDARD FLUSH DOOR REMOVAL / INSTALLATION NOTE: See Vignette or Low Profile Faceplate instructions for removal of screen prior to removing glass.
  • Page 36 installation WIRING DIAGRAM Caution: Ensure that the This heater does not require a 120V A.C. supply WARNING: Electrical Grounding Instructions for operation. However, a 120V A.C. power wires do not touch any This appliance is equipped with a three pronged supply is needed for the fan/blower operation.
  • Page 37 operating instructions FIRST FIRE 8) The unit should never be turned off, and on again without a minimum of a 60 second wait. 5. Press and release the ON/OFF button on the remote handheld transmitter. An audible beep The first fire in your stove is part of the paint curing 9) Hook up remote receiver to wire marked 'receiver' should be heard from the receiver.
  • Page 38 operating instructions PROFLAME GTMF SYSTEM OPERATING INSTRUCTIONS SYSTEM DESCRIPTION OPERATING PROCEDURE The Proflame Remote Control System consists of two elements: Pairing the Remote Control to Remote Receiver/Battery Holder (if required) 1. Proflame Transmitter. 2. Proflame Receiver and a wiring harness to connect the Receiver to the Install the 4 AA batteries into the receiver battery bay.
  • Page 39 operating instructions Turn on the Appliance ROOM THERMOSTAT (TRANSMITTER OPERATION) Press the ON/OFF Key on the Transmitter. The Transmitter display will show all active Icons on the screen. At the same time the Receiver connects the The Remote Control can operate as a room thermostat. The thermostat thermopile to the gas valve millivolt coil and the appliance main burner turns can be set to a desired temperature to control the comfort level in a room.
  • Page 40 operating instructions Key Lock This function will lock the keys to avoid unsupervised operation. To activate this function, press the MODE and UP Keys at the same time (fig. 18). To de-activate this function, press the MODE and UP Keys at the same time. Figure 12 LOW BATTERY POWER DETECTION Transmitter...
  • Page 41 operating instructions PROFLAME I REMOTE RECEIVER BATTERY REPLACEMENT Remote Receiver/Battery Holder Battery Replacement & Battery Back up if 120 volt power is lost witihin home Remote Receiver Battery Replacement How to replace/add the batteries on remote receiver. How to replace/add the batteries on remote receiver (Proflame 1). Note:4 AA batteries are mandatory in the remote receiver to operate appliance when using remote control.
  • Page 42 operating instructions COPY OF LIGHTING INSTRUCTION PLATE AUTOMATIC CONVECTION FAN OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING POUR VOTRE SÉCURITÉ – À LIRE AVANT LA MISE EN MARCHE The fan operates automatically. Turn the knob WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, on the side of the faceplate to adjust to the personal injury or loss of life.
  • Page 43 maintenance MAINTENANCE GENERAL VENT C L O T H I N G O T H E R INSTRUCTIONS FLAMMABLE MATERIAL SHOULD MAINTENANCE NOT BE PLACED ON OR NEAR THE 1) Always turn the gas valve to the off position Conduct an inspection of the venting system APPLIANCE.
  • Page 44 maintenance DOOR GLASS To Remove Fan: 8. Remove the rear log support by unscrewing the 2 screws. 1. Turn the unit off and allow it to cool down to Your Regency stove is supplied with high room temperature. temperature, 5 mm Neoceram ceramic glass that will withstand the highest heat that your unit will Screws 2.
  • Page 45 maintenance 7. When removing base brick sides the two screws 12. Pull Fan Assembly forward, to disengage the fan 11. Disconnect the inlet gas line. that hold the grate down must be removed first. clip on the rear wall. Then lift the Fan Assembly up and pull through firebox opening.
  • Page 46 maintenance Gas Maintenance GAS MAINTENANCE - RECOMMENDED ANNUAL ROUTINE Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) • Burner ports & burner air shutter •...
  • Page 47 parts list MAIN ASSEMBLY Part # Description 1) 340-038 Fan Access Plate 2) 340-103 Gasket - Fan Access Plate 3) 320-517/P Fan Assembly 120 V (includes Fan Cover Gasket) 910-331/P Replacement Fan Motor 120 V 5) 910-750 Power Cord 910-752 Wire Harness (Faceplate) 910-330 Fan Speed Controller...
  • Page 48 parts list BURNER & LOG ASSEMBLY Part # Description 52) 340-104 Gasket - Valve Tray 342-574/P Valve Assembly - NG 342-576/P Valve Assembly - LP 57) 910-578 Valve - S.I.T. - Natural Gas 910-580 Valve - S.I.T. - Propane 59) * Valve Tray 66) 910-038/P Pilot Assy-3 Flame-S.I.T.-NG...
  • Page 49 parts list VIGNETTE FACEPLATE Part # Description 342-957 Oversize Backing Plate 342-924 Faceplate Low Profile Mt. Black 342-914 Faceplate Vignette Mt. Black 342-954 Backing Plate Custom 3-Sided 342-934 Faceplate Vignette 4 sided.Mt. Black Vignette 342-934 Faceplate Vignette 4 sided Mt. 342-959 Backing Plate Custom 4 Sided 342-958...
  • Page 50 warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U.S., Inc. (for U.S. customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below.
  • Page 51 warranty At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. All warranty claims must be submitted by the dealer servicing the claim, including a copy of the Bill of Sale (proof of purchase by you).
  • Page 52 warranty Limitations of Liability: The original purchaser’s exclusive remedy under this warranty, and FPI’s sole obligation under this warranty, express or implied, in contract or in tort, shall be limited to replacement, repair, or refund, as outlined above. IN NO EVENT WILL FPI BE LIABLE UNDER THIS WARRANTY FOR ANY INCIDENTAL OR CONSEQUENTIAL COMMERCIAL DAMAGES OR DAMAGES TO PROPERTY.
  • Page 53 warranty Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
  • Page 56 Installer: Please complete the following information Dealer Name & Address: _______________________________________ ___________________________________________________________ Installer: ___________________________________________________ Phone #: ___________________________________________________ Date Installed: _______________________________________________ Serial #: ____________________________________________________ Printed in Canada Regency and Energy are trademarks of Fireplace Products International Ltd. © Copyright 2023, Fireplace Products International Ltd. All rights reserved.
