- Page 1 SEAMLESS Connect Universal dvLED Cart/Trolley LEDMTM Series configuration configuration drawing drawing 2025-04-15 #:009-9180-1...
- Page 2 WARNING ENG - Do not begin to install product until you have read and understood the instructions and warnings contained in this user guide. Always use an assistant or mechanical lifting equipment to safely lift and position equipment. This product must be installed onto flat, hard, level surface to prevent tipping. Use with heavier displays may result in instability causing tip over resulting in death or serious injury.
- Page 3 Parts (Before beginning, make sure you have all parts shown below). *Refer to parts list included with your model. Parts List Description Qty* base leg upright, long base leg caster non-locking caster locking attachment bracket caster non-locking 1/4" washer upright, long upright, short latch assembly extrusion end cap...
- Page 4 barbed fastener M6 x 10mm 5mm allen stand-off wrench bracket M5: for spacer extension #91294A541 for spacer M5 cup M6/M8 cup M5 flat M6 flat M8 flat M10 flat #520-1179 washer washer head screw head screw head screw head screw for spacer for spacer extension...
- Page 5 Parts List Description Qty. 3mm allen wrench spacer spacer AAA spacer extension BBB 3mm allen wrench CCC laser target DDD 4mm allen wrench 4mm allen wrench EEE spacer extension FFF shim plate GGG M4 flat head screw shim plate laser target M4 flat head screw LEDUNVSPACER3 Kit sold separately.
- Page 6 Join vertical uprights using nut bars provided. Arrange so that longest upright is at the bottom. Ensure threaded holes are at bottom of the bottom upright. TOP VIEW SIDE VIEW MIN 25 in. • lb (2.82 N.M.) Threaded end. 2025-04-15 #:009-9180-1...
- Page 7 Slide brackets onto vertical upright. Note, your configuration may require vertical upright installed with offset bracket (EE). Refer to configuration drawing specific to your model. Hand tighten hardware. TOP VIEW 2025-04-15 #:009-9180-1...
- Page 8 For displays narrower than 960mm, determine the required extrusion length with the following extrusion cut to length formula: Video Wall Width - 0.25" (6mm) = Extrusion Length Connect two horizontal extrusions using connector plate. MIN 25 in. • lb Front View Loosen.
- Page 9 With uprights laying down, space them based on number of display columns in your video wall. 2 COLUMN VIDEO WALL 3 COLUMN VIDEO WALL 37.75" 75.5" (960mm) (1920mm) 4 COLUMN VIDEO WALL 5 COLUMN VIDEO WALL 75.5" 75.5" 56.5" 56.5" (1920mm) (1920mm) (1440mm)
- Page 10 Slide nut bars into top and bottom channels of horizontal extrusions. With uprights still laying down, position horizontal extrusions into the openings of the attachment brackets. Align nut bars inside the top and bottom channels of horizontal extrusion with holes of attachment brackets. Secure using hardware provided.
- Page 11 Hand tighten. Lock wheels. MIN 25 in. • lb (2.82 N.M.) 2025-04-15 #:009-9180-1...
- Page 12 Determine the combined height of TWO displays being mounted and locate the same dimension on the front of spacer. If height is above 686mm, attach spacer extension. If height is not listed on the spacer, use measurement of the combined height of TWO displays to set custom spacing. X >...
- Page 13 Move spacer bracket and clamp to align window of spacer bracket with corresponding height value (measurement "X", step 7-1). Align window to desired Loosen. Adjust. Tighten. height value. 8b-1 If the combined height of TWO displays is not listed on the spacer, measure them to set custom spacing.
- Page 14 8b-2 With spacer brackets positioned wide enough to fit TWO displays inside, position notch of top spacer bracket flush with top edge of display. Slide the bottom spacer bracket to the bottom edge of display. Tighten screws of bottom spacer bracket. Avoid damage to module(s).
- Page 15 Stand cart upright. Refer to drawing specific to your model for measurements to locate top horizontal extrusion's height. The top of attachment bracket shall be flush with top of vertical upright. If a lower A.F.F. (Above Finished Floor) height is desired, adjust the height of the top horizontal extrusion as needed. Loosen, adjust, tighten.
- Page 16 Refer to configuration drawing specific to your model to locate height of bottom horizontal extrusion. Y = Bottom of horizontal extrusion second from the bottom to the top of bottom horizontal extrusion. Loosen, adjust, tighten. 2025-04-15 #:009-9180-1...
- Page 17 Optional: If uprights would be visible above the video wall, uprights may be cut as needed. Set the laser level so that it is parallel to the cart. With the horizontal extrusion set all the way back, measure from face of extrusion to laser, in various locations.
- Page 18 Install column covers and extrusion end caps. 2025-04-15 #:009-9180-1...
- Page 19 Number of Rows M5 x 22mm M6 x 25mm If mounting hardware is M8 x 22mm preinstalled, remove and replace with hardware provided. M10 x 25mm HH,II,JJ Not included. If display has raised mounting points, use boss washers as shown. EVEN Number of Rows Join two cabinets together...
- Page 20 14-1 Install stand-off brackets to the bottom extrusion using drop-in nut bars as shown. 14-2 Hook display cabinets onto horizontal extrusion, adjust height to level and join cabinets together using display's connecting system. Adjust plumb with depth adjustment bracket, close latch, then run cables one at a time starting from left to right.
- Page 21 14-3 One stand-off bracket shall be located at every seam between two displays. Secure stand-off brackets to the bottom mounting holes of the bottom row of displays. M5 x 22mm M6 x 25mm M8 x 22mm M10 x 25mm SIDE VIEW 2025-04-15 #:009-9180-1...
- Page 22 Hook display cabinets onto horizontal extrusion, adjust height to level and join cabinets together using display's connecting system. Close latch, then run cables one at a time starting from left to right. ENSURE LATCH IS UNLOCKED PRIOR TO INSTALLATION. To remove, start from the top right. Open latch assemblies, disconnect cables, separate cabinets and remove displays one at a time.
- Page 23 This page intentionally left blank. 2025-04-15 #:009-9180-1...
- Page 24 +44 (0) 1923 200 100 +31 (0) 70 770 8037 +52 (81) 8384-8300 © 2025 Peerless Industries, Inc. Peerless-AV is a registered trademark of Peerless Industries, Inc. All rights reserved. ® Other parties’ marks are the property of their respective owners.
