Argos New Sywell 282/8417 Assembly Instructions Manual

2 drawer bedside

Hide thumbs

page of 76

/ 76
Bookmarks

Quick Links

Download this manual

New Sywell - 2 Drawer Bedside

Assembly Instructions -

Dimensions

Width - 39.5cm

Depth - 40cm

Height - 39cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

282/8417

268/4792

281/2612

279/9618

MADE IN

BRITAIN

Issue 4 - 11/03/15

Need help?

Do you have a question about the New Sywell 282/8417 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos New Sywell 282/8417

Page 1 New Sywell - 2 Drawer Bedside Assembly Instructions - 282/8417 Please keep for future reference 268/4792 281/2612 279/9618 Dimensions Width - 39.5cm Depth - 40cm MADE IN Height - 39cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 4 - 11/03/15...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 10kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side (D2542A) (D2543A) (D2541A) (388 x 396mm) (388 x 396mm) (363 x 394mm) Rail...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer fronts Screw 2 metal dowels into the holes shown on the back of each drawer front Note: Tighten the metal dowels up fully against...
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back down onto the drawer base Make sure that the drawer base...
Page 7 Assembly Instructions Step 7 Prepare the left side Finished front edge Place 2 runners the left side . Slide back the top of the runner and use the 2nd hole from the front to fit the 1st screw Screw 4 metal dowels into the left side Slide the runner back the other way and...
Page 8 Assembly Instructions Step 9 Prepare the top Tap 2 wooden dowels into the top Note: Wooden dowels must not stick out from the edge by more than Finished 10mm or they may front edge damage other panels. Insert 4 large locking nuts into the 10mm...
Page 9 Assembly Instructions Step 12 Fit the 2 rails Push the 2 rails onto the right side Use a screwdriver to tighten the large locking fitted to each of the 2 rails Note: Support this rail until the left side has been fitted in the next step.
Page 10 Assembly Instructions Step 14 The measurement from top corner X to bottom corner X must be Fit the back and equal to the measurement from top corner Y to bottom corner Y plastic nails Square up the unit by making sure that measurement x to x equals y to y.
Page 11 Step 16 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
