Anderson - 2+2 Sideboard
Assembly Instructions -
Dimensions
Width - 80cm
Depth - 40cm
Height - 77.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
289/8533
609/5538
412/7714
MADE IN
BRITAIN
Issue 9 - 28/04/15
Advertisement
Related Manuals for Argos Anderson 2 plus 2 Sideboard
Summary of Contents for Argos Anderson 2 plus 2 Sideboard
- Page 1 Anderson - 2+2 Sideboard Assembly Instructions - 289/8533 Please keep for future reference 609/5538 412/7714 Dimensions Width - 80cm Depth - 40cm MADE IN Height - 77.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 9 - 28/04/15...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 28kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below (D2184A) (796 x 396mm) Left Side Right Side (D2182A) (D2183A) (747 x 375mm) (747 x 375mm) Base...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the drawer fronts Screw 2 metal dowels into the holes shown on the back of each drawer front Note: Tighten metal dowels up fully against...
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Runners must be Step 7 pushed up against Turn the drawers over the drawer front Fit runners to the drawers Fit the runner to the bottom edge of the left drawer side , as shown, making sure that it is pushed up against the back of the drawer front...
- Page 8 Assembly Instructions Step 9 screw screw Prepare the right side Tap a wooden dowel into the right side Screw 3 metal dowels into the right side Insert a large locking into the right side Fit the runner to the right side The 1st screw uses the 2nd hole in from the...
- Page 9 Assembly Instructions Step 11 Join the right side and base Push the base onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to p l a the base i n c h i p a r d Note: Turn the large s u r...
- Page 10 Assembly Instructions Step 14 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 3 large locking nuts fitted to the base and plinth Step 15 Prepare the top Screw 4 metal dowels into the top...
- Page 11 Assembly Instructions Step 16 Prepare the divider Insert 2 large locking nuts into the divider Finished front edge Note: The 2 holes for the large locking nuts may be drilled in either surface of the divider screw screw Fit a runner this surface of the divider Note: Use the finished...
- Page 12 Assembly Instructions Step 17 Fit the divider Push the divider onto the top Use a screwdriver to tighten the 2 large locking nuts fitted to Finished the divider front edge Note: The 2 large locking nuts may be on either surface of the divider.
- Page 13 Assembly Instructions Step 19 The measurement from top corner X to bottom corner X must be Fit back panel equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x equals y to y.
- Page 14 Assembly Instructions Step 20 Fit the shelf Insert 4 shelf studs the required height. Lower the shelf down onto the shelf studs Step 21 Prepare the 2 doors Push fit 2 hinges into each of the doors Secure each hinge with 2 screws Note: Before securing with the screws, make...
- Page 15 Assembly Instructions Step 22 IMPORTANT You will need to drill the doors to Drill the handle holes in the door suit the handles supplied Important: Please follow these instructions You will need to drill 1 door as carefully. shown in this diagram Lay the doors down ONLY drill...
- Page 16 Assembly Instructions Step 23 Fit doors and handles Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinge. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 17 Assembly Instructions Step 24 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 18 Assembly Instructions Step 25 Fit the drawers Slide the wheels of the runners fitted to the drawers, over the wheels of the runners fitted to the side panels and push the drawers into position. Side panel Drawer...
- Page 19 If in doubt, consult an expert. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 20 ALR2742...
