Malibu - Cabin Bed
NOT SUITABLE FOR CHILREN
Dimensions
Width - 195cm
Depth - 95cm
Height - 53cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
WARNING
UNDER 4 YEARS OF AGE .
268/5038
275/4433
278/5433
275/7557
249/2032
280/3315
MADE IN
BRITAIN
Issue 1 - 08/07/14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Argos Malibu
Summary of Contents for Argos Malibu
- Page 1 Malibu - Cabin Bed Assembly Instructions - 268/5038 Please keep for future reference 275/4433 278/5433 WARNING 275/7557 NOT SUITABLE FOR CHILREN UNDER 4 YEARS OF AGE . 249/2032 280/3315 Dimensions Width - 195cm Depth - 95cm MADE IN Height - 53cm...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 66kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Horizontal (D2932A) (820 x 287mm) Left End Right End (D2931A) (D2936A) (949 x 529mm) (949 x 529mm)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the 4 drawer fronts Screw 2 metal dowels into each of the 4 drawer fronts Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Prepare the left upright Tap 2 wooden dowels into the left upright Screw a metal dowel into the left upright Place 2 runners the left upright shown. Slide back the top of runner and use the Finished 2nd hole from the front front edge...
- Page 8 Assembly Instructions Step 10 Fit the horizontal to the right upright Fit the horizontal onto the right upright using 2 screws the allen key Finished front edge Finished front edge Step 11 Prepare the middle plinth Plain chipboard Insert 2 large locking surface nuts into the middle...
- Page 9 Assembly Instructions Step 13 Plain chipboard surface Prepare the back Tap 2 wooden dowels into the back Step 14 Fit the back Plain chipboard Push the back onto surface the right upright fix it using 2 screws and the allen key Step 15 Fit the left upright Push the left upright...
- Page 10 Assembly Instructions Step 16 Secure the middle plinth to the left upright Tap a double metal dowel and a large wooden dowel through the left upright and into the middle plinth until they ‘’bottom out’’. Use a screwdriver to tighten the large locking fitted to the middle plinth Step 17...
- Page 11 Assembly Instructions Step 19 Finished front edges Fit the left plinths to the left upright Push the left plinths Finished onto the left upright top edge Use a screwdriver to Front tighten the large locking This is the back Finished nuts fitted to the left of the bed...
- Page 12 Assembly Instructions Step 22 Prepare the 2 bases Tap 2 wooden dowels into each of the 2 bases Step 23 Fit a base Fit a base down onto the 2 uprights using 4 screws the allen key This is the back of the bed...
- Page 13 Assembly Instructions Step 24 Fit the other base 2 people are needed to asssemble this part Fit the other base down onto the 2 uprights using 4 screws and the allen key This is the back of the bed Step 25 Prepare the right end Place 2 runners the right end...
- Page 14 Assembly Instructions Step 26 Prepare the left end Place 2 runners the left end shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
- Page 15 Assembly Instructions Step 28 Fit the 2 support rails Fit the 2 support rails to the left end using 2 screws for each rail and the allen key Note: Use 2 people for This is the back This is the back this step and support the of the bed of the bed...
- Page 16 Assembly Instructions Step 30 Fit the front rail and back rail Fit the front rail to the left end using 2 screws and the allen Fit the back rail the left end using 2 screws and the allen Note: Support the front This is the back This is the back and back rail until the...
- Page 17 Assembly Instructions Step 31 Fit the right end Fit the right end onto the assembly using 16 screws and the allen Step 32 Secure the rear support rail Screw through the 5 holes in the base and into the top edge of the support rail using 5 screws Important: Make sure...
- Page 18 Assembly Instructions Step 33 Secure the back rail Fix the back rail the back edge of the base using 5 screws Step 34 Secure the front rail Loosely fix the 5 brackets to the holes in the base using screws Slide the brackets up against the mark holes in the front rail...
- Page 19 Assembly Instructions Step 35 Fit the drawers Starting with the bottom drawers, slide both the runners forward and locate the drawer sides between them, lining up the holes 2nd threaded in the drawer wrap with hole the 2nd 'threaded' holes in the runners Working from the inside of the drawer, insert 2...
- Page 20 If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3047...
