New Sywell - 5 Drawer Chest
Assembly Instructions -
Dimensions
Width - 69cm
Depth - 40cm
Height - 88.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
257/7579
280/2110
280/5935
282/2248
MADE IN
BRITAIN
Issue 4 - 13/01/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos New Sywell 5 Drawer Chest
Summary of Contents for Argos New Sywell 5 Drawer Chest
- Page 1 New Sywell - 5 Drawer Chest Assembly Instructions - 257/7579 Please keep for future reference 280/2110 280/5935 282/2248 Dimensions Width - 69cm Depth - 40cm MADE IN Height - 88.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 4 - 13/01/15...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 28.5kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below (D2546A) (658 x 394mm) Rail (D2549A) (658 x 78mm) Left Side Right Side (D2552A) (D2555A)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the drawer fronts Screw 2 metal dowels into the holes shown on the back of each drawer front Note: Tighten the metal dowels up fully against...
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back down onto the drawer base Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Prepare the left side Place 5 runners Finished the left side . Slide front edge back the top of the runner and use the 2nd hole from the front to fit the 1st screw Screw 5 metal dowels into the left side Slide the runner back the other way and...
- Page 8 Assembly Instructions Step 10 Prepare the top Tap 2 wooden dowels into the top Note: Wooden dowels must not stick out from the edge by more than 10mm or they may Finished damage other panels. front edge Insert 4 large locking nuts into the Note: The arrow on the...
- Page 9 Assembly Instructions Step 12 Prepare the 3 rails Tap 2 wooden dowels into each of the 3 rails Insert 2 large locking nuts into each of the 3 rails Step 13 Fit the 3 rails Push the 3 rails onto the right side Use a screwdriver to tighten the large locking...
- Page 10 Assembly Instructions Step 14 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 5 large locking nuts fitted to the top and the 3 rails Step 15 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by...
- Page 11 Assembly Instructions Step 16 Fit the plastic nails Tap 2 plastic nails into the bottom edge of each of the sides Stand the unit up for the next step. Step 17 Fit the drawers Starting with the bottom drawer, slide both the runners forward and locate the drawer sides...
- Page 12 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3015...
