D7 DIAGNOSTIC TOOL
USER MANUAL
Version 1.0
Shenzhen XTOOL tech Intelligent Co., LTD

Advertisement

loading
Need help?

Need help?

Do you have a question about the D7 and is the answer not in the manual?

Questions and answers

Related Manuals for Xtool D7

Summary of Contents for Xtool D7

  • Page 1 D7 DIAGNOSTIC TOOL USER MANUAL Version 1.0 Shenzhen XTOOL tech Intelligent Co., LTD...
  • Page 2 XTOOL will not be responsible for any direct, special, incidental, or indirect damages, including economic losses such as lost profits. XTOOL® also reserves the right to make changes at any time without prior notice. IMPORTANT: Before you start using or maintaining this unit, make sure to read this manual...
  • Page 3 Product Support Information Technical Assistance Website: https://www.xtoolonline.com Mail: support@xtoolonline.com ADD: 17&18/F, A2 Building, Creative City, Liuxian Avenue, Nanshan District, Shenzhen, China Corporate & Business: business@xtoolonline.com, sales@xtoolonline.com Manuals / Technical Documentation This manual is periodically revised to ensure the latest information is included. Product Training Videos Diagnostic Tool specific training videos are available on our website.
  • Page 4 ● Knowledge and Skill: The automotive technician must be knowledgeable about the system being tested. Familiarize yourself with proper service methods and test procedures. ● Acceptable Testing Practices: Perform tests in a manner that ensures your safety, the safety of others, and prevents damage to the device and the vehicle. Specific Responsibilities: ●...
  • Page 5 Safety Instructions The safety messages provided here address situations that XTOOL is aware of. XTOOL cannot anticipate, evaluate, or provide advice on all potential hazards. You must be certain that any condition or service procedure encountered does not jeopardize your personal safety.
  • Page 6 No Driving While Testing: Do not drive the vehicle and operate the test equipment simultaneously to avoid distractions that may cause an accident. Service Manual Reference: Refer to the service manual for the vehicle being serviced and adhere to all diagnostic procedures and precautions. Failure to do so may result in personal injury or damage to the test equipment.
  • Page 7 3.3.5 Updates ......................... 7 3.3.6 More ..........................8 3.3.7 Settings ..........................8 3.3.8 Remote Control ......................8 3.3.9 XTOOL ..........................8 3.4 Hidden Toolbar Menu, Main Screen Layout & Main Screen Icons ....9 3.4.1 Hidden Toolbar Menu ....................9 3.5 Main Screen Layout ..................10 3.6 Function of each icon ..................10...
  • Page 8 3.6.3 Clock ..........................11 3.6.4 Email ..........................12 3.6.5 Music ...........................12 3.6.6 Sound Recorder ......................13 3.6.7 Calculator ........................13 3.6.8 Files ..........................14 3.6.9 Adobe Acrobat ......................14 3.6.10 Quick Support ......................15 3.6.11 Settings ........................15 3.6.12 Gallery ........................16 3.6.13 Browser ........................16 3.7 Connect to USB Type-C Port for Data Transfer ..........
  • Page 9 4.12.2.2 DTC Erased and Fault Fixed- History Code ............. 33 4.12.2.3 DTC Erased and Fault Fixed- History Cleared ............34 4.12.3 PID Data ........................34 4.12.3.1 PID Data List ......................34 4.12.3.2 Individual PID Data Graphing ................. 35 4.12.3.3 Set Maximum & Minimum Value Alarms ...............37 4.12.3.4 Zoom In &...
  • Page 10 5.6.3 Clear Trouble Code(Mode $04) ...................63 5.6.4 Live Data(Mode $01) ....................64 5.6.5 Read Freeze Frame(Mode $02) ...................64 5.6.6 I/M Readiness(Smog Check) ..................64 5.6.7 Since DTCs Cleared ......................65 5.6.8 O2S Monitoring Test(Mode $05) .................66 5.6.9 On-Board Monitor Test (Mode $06) ................66 5.6.10 Component Test(Mode $08) ..................
  • Page 11 6.24 FRM Reset ....................91 6.25 EGR Relearn ....................91 6.26 A/C Relearn ....................91 6.27 Headlight ....................91 6.28 SRS ......................91 6.29 Windows Initialization ................91 6.30 VGT Relearn ....................91 6.31 Electronic Pump Activation .................92 6.32 Suspension ....................92 6.33 Airbag Reset ....................92 6.34 Tire Reset ....................92 6.35 Instrument Cluster ..................92 7.
  • Page 12 11.1 Remote Control ..................112 11.2 Data Logging ..................... 112 11.3 App Logging ....................113 11.4 FAQ Database ................... 113 11.5 Training Center ..................113 11.6 User Programs ..................113 11.7 Corporate Purchase .................. 113 11.8 Inventors and Testers Program ..............113 11.9 U-Fluncer Program ..................114 12.
  • Page 13 1. Introduction The XTOOL D7 Diagnostic Tool interfaces with the electronic control unit(ECU) of a vehicle to retrieve diagnostic trouble codes (DTCs), access data stream information, and command actuation tests (bi-directional control tests). Various vehicle control systems, such as engine, transmission, and anti-lock brake system (ABS), SRS(Airbag) system, Chassis, Body and etc are readily diagnosed using this Diagnostic Tool.
  • Page 14 1.3 Main Ports of The Tablet ❶ 7-inch Touch Screen ❷ Power Button ❸ DB15-Port ❹ Micro USB Port ❺ Speaker 1.4 Power Sources XTOOL D7 Diagnostic Tool can receive power from either of the two sources: ● Internal Battery Pack ● AC Power Supply...
  • Page 15 1.5 Internal Battery Pack The D7 Diagnostic Tool can be powered from the internal rechargeable battery pack. A fully charged battery provides sufficient power for about 3.5 hours of continuous operation. Battery charging occurs when the Diagnostic Tool is connected to the AC Power Supply and to a live AC power source.
  • Page 16 0.72KG Weight(Including Battery) 2.2KG Gross Weight -4°F ~ 140°F (-20°C ~ 60°C) Operating Temp Range(Ambient) -40~158°F (-40~70°C) Storage Temp(Ambient) <90% Operating Humidity 1.8 What's In The Box Name VAG to OBD-II-16 Main Cable Charger for Tablet Charger US Adapter Charger EU Adapter Micro USB Cable P700 Tool kit...
  • Page 17 6 hours and then turn it on again. 2.2 Turning Off To turn off the XTOOL D7 Diagnostic Tool, press and hold the power button for more than three seconds. The tool will then automatically power off.
  • Page 18 IMPORTANT: Using the emergency shutdown procedure while communicating with the vehicle ECM may lead to ECM problems on some vehicles. 3.Get to Know the Diagnostic Tool This chapter details the layout and icons of the main diagnostic screen and main screen of the Android tablet used with the Diagnostic Tool.
  • Page 19 3.3 Diagnostic Screen Icons 3.3.1 Auto Scan The Diagnostic Tool automatically detects and decodes the VIN (Vehicle Identification Number), then proceeds to scan comprehensively through all available vehicle electronic control modules for diagnostics. This process ensures thorough assessment and identification of potential issues across the vehicle's systems. 3.3.2 Diagnostic Clicking "Diagnostic"...
  • Page 20 There are too many devices sold in the market, we are not able to remote with all customers if they start the remote at the same time without appointment. 3.3.9 XTOOL This section provides information about how to contact us, including our social media accounts for support or any other inquiries.
  • Page 21 3.4 Hidden Toolbar Menu, Main Screen Layout & Main Screen Icons Swiping up from the bottom of the touchscreen will reveal the toolbar for 3 seconds. Clicking the home button on this toolbar will bring up the main screen of the diagnostic tablet.
  • Page 22 3.5 Main Screen Layout 3.6 Function of each icon 3.6.1 Calender This function displays the calender in day, week and month.
  • Page 23 3.6.2 Contacts This function enables you to manage your contact information. You can add a new contact by clicking the "+" icon at the bottom right, or import contacts in bulk from a VCF file by clicking "IMPORT". 3.6.3 Clock This function allows you to set alarms, timers, use the stopwatch, and access the clock.
  • Page 24 3.6.4 Email This function lets you create a new email account for sending emails or sharing reports. 3.6.5 Music This function allows you to add new songs, playlists, albums, artists, and more.
  • Page 25 3.6.6 Sound Recorder This function enables you to record a voice message. 3.6.7 Calculator This function opens the calculator.
  • Page 26 3.6.8 Files This function allows you to manage documents, reports, files, and folders stored in the memory. 3.6.9 Adobe Acrobat This function enables you to manage PDF files and access your Dropbox account after logging into your Adobe and Dropbox accounts.
  • Page 27 3.6.10 Quick Support This function enables our tech support team to remotely control the Diagnostic Tool. This allows them to check for possible problems with the tool or assist you with navigation paths and other issues. 3.6.11 Settings This function allows you to configure Android tablet settings, including Network & Internet connections, battery management, display settings, sound volume control, and checking memory storage.
  • Page 28 3.6.12 Gallery This function allows you to view screenshots and screen recordings. 3.6.13 Browser This function allows you to get product support from XTOOL website and search information.
  • Page 29 3.7 Connect to USB Type-C Port for Data Transfer To enable data transfer between the Diagnostic Tool and a PC, please follow these steps: Step 1: Connect the Diagnostic Tool to a PC by using a Type-C cable. Insert one end into the Type-C port on the Diagnostic Tool and the other end into a USB 2.0 port on the PC.
  • Page 30 Step 4: On the PC, check the connected devices and click on "D7" to access and manage the files stored in the internal memory of the Diagnostic Tool. 3.8 Red-Green Color Blindness Color Correction Mode To set the Diagnostic Tool to red-green color blindness color correction mode, follow these steps: Step 1: Swipe up from the bottom of the screen to bring up the hidden menu.
  • Page 31 ● The Diagnostic Tool function enables communication with a vehicle's electronic control systems. This capability allows you to retrieve diagnostic trouble codes (DTCs), view PID data, conduct actuation tests, and perform advanced functions such as resets, relearns, matchings, adaptations, initializations, and more. 4.1 My Vehicles "My vehicles"...
  • Page 32 4.1.2 Compatibility Check This Diagnostic Tool is compatible with all OBD-II vehicles for performing generic OBD-II tests, as well as a wide range of vehicle makes and models across regions like the United States, Europe, Asia, Australia, etc., for comprehensive electronic control systems diagnostics.
  • Page 33 The red up arrow indicates that there is a newer version of the software program available for download. When you click on the arrow to update the software program and successfully install it, the Diagnostic Tool will display that a newer version of the software program has been installed.
  • Page 34 4.4 Trial Mode The DEMO program may not accurately represent the latest vehicle diagnostic processes or the actual screen interface. It is crucial to understand that this program is not designed for vehicle coverage or compatibility checks. Its main purpose is to offer practice and help users become familiar with the functions and user interface of the Diagnostic Tool.
  • Page 35 4.6 Product Activation Step 1: After first-time users press and hold the power button to turn on the system, the system will automatically enter the guided process and request the user to select the language for the operating system. Click "Register": Open the registration page. Step 2: After setting the system language, click Next to enter the Wi-Fi connection page, as shown below:...
  • Page 36 Step 3: Select a network to connect to on the Wi-Fi connection page. You need to enter the Wi-Fi password to establish Wi-Fi connectivity and the activation page, as shown in the figure below. You can also click the "TRAIL" button in the upper right corner to try it out before activation.
  • Page 37 Step 5: A pop-up window showing "Activation success" indicates that you have completed the first boot setup. Step 6: Click "OK" to enter the diagnostic system and start using the device. Step 7: Once you see "Registration completed" on the screen, the Diagnostic Tool has been successfully registered and activated.
  • Page 38 "Get verification code". You will receive a verification code from service@xtool.com and input the verification code to proceed to reset the password. If you don't see the verification code in the inbox, please check the spam box as well.
  • Page 39 If you forgot the email address you used for the product activation, please send the S/N (Serial Number) of the Diagnostic Tool to support@xtoolonline.com to recover the registration information. 4.7 Vehicle Connection ⚫ DB15 to OBD2-16 Main Cable ❶ DB15 Port-connect to tablet ❷...
  • Page 40 ⚫ Vehicle Connection The scan tool must be connected to the vehicle's OBD-II port so that the tablet can establish correct vehicle communication. Please perform the following steps: Step 1: Turn on the tablet Step 2: Connect vehicle and tablet via the main test cable Step 3: Switch on the ignition and tap on the Diagnostic application to start your diagnosis.
  • Page 41 Step 1: Follow Screen Prompts: Use the menu-driven prompts to enter the necessary vehicle information. Step 2: Options for Vehicle Identification: ⚫ VIN (Vehicle Identification Number) ⚫ Manufacture area> Model> Year ⚫ Other specific criteria as required by the Diagnostic Tool 4.8.1 Vehicle Identification Click "Auto Scan"...
  • Page 42 NOTE: In cases where vehicle VIN numbers cannot be decoded, if both Auto Scan and Manual Input failed, it is recommended to try using Automatic Detection or Manual Selection instead. 4.8.3 Automatic Detection Click "Diagnostic"> Select region where the vehicle brand is originated, for example "Americas">...
  • Page 43 After performing an automatic scan, the Diagnostic Tool will display the vehicle systems affected by faults and the number of failures in orange at the top of the screen. 4.9 Submit Feedback Clicking the message icon " " in the top right corner allows you to submit feedback to our support team if you encounter any issues with the app or the software programs.
  • Page 44 4.10 CAN fast Scan Scanning all available vehicle systems for vehicles that use the CAN protocol for vehicle communication post-2005 is much faster. 4.11 System Selection Once you have identified where the car problems might be, you can select an individual vehicle module for diagnostics.
  • Page 45 When the erase command is sent through the diagnostic program, the vehicle's electronic control module (ECM) will verify whether the issue has been resolved over several drive cycles. Some faults are immediately detected by the ECU when the key is in the run position, even without the engine running. However, other faults may require very specific test conditions to be met, such as engine coolant temperature within a specific range, vehicle speed maintained within a range for a duration of time, throttle position within a certain range, and so on.
  • Page 46 4.12.2.3 DTC Erased and Fault Fixed- History Cleared If the fault is fixed and you clear the fault codes, the fault history will also be cleared. If you intend to have another technician investigate the car problem, it's not recommended to clear the fault code, as this may erase valuable information that could be helpful to others investigating the issue.
  • Page 47 4.12.3.2 Individual PID Data Graphing Click the "custom" icon on the lower right corner to view graphing for individual PID data and click chart to choose the format you want as shown in picture below: With the click of "chart" button you can choose from four viewing modes: List, Column, Graph, 2D-Graph.
  • Page 48 Graph mode： 2D-Graph mode：...
  • Page 49 Column mode: 4.12.3.3 Set Maximum & Minimum Value Alarms Click " " icon on the right to set maximum and minimum value alarms for individual PID data as shown in picture below:...
  • Page 50 Once the maximum and minimum values are set on the screen, the diagnostic tool will display colors based on the values to indicate whether the PID data exceeds the maximum value or falls below the minimum value you have just set, as shown in the image below: With the click of "chart"...
  • Page 51 Column mode: Graph mode:...
  • Page 52 2D-Graph mode: NOTE: The maximum and minimum values do not have to be within the normal value range for the specific PID data. You may set whatever value you deem fit for you observation. 4.12.3.4 Zoom In & Zoom Out & View In Full Screen Click the magnifier icon to zoom in the x-axis up to 3 times and click the magnifier icon...
  • Page 53 4.12.3.5 Custom Up to 8 PID Data This Diagnostic Tool allows you to tick the boxes for up to 8(eight) PID data and click "Custom" to show custom list of real-time PID data. Cancel Selected - To cancel the PID data you selected so that you can re-select them. Custom - Proceed to display the custom screen for the PID data you selected.
  • Page 54 Record - Recorded data streams Pause - To pause the continuous retrieving process for the real-time PID data. 4.12.3.6 Individual Graphing for Up to 8 PID Data Click the "custom" icon on the custom PID data list screen, and the Diagnostic Tool will show individual list for up to 8 PID data on one single screen, as shown in picture below: With the click of "chart"...
  • Page 55 Column mode: Graph mode:...
  • Page 56 Display All - If you want to view or display other PID data, this button allows you to show all available data streams again for selection, so you don't have to go back and choose them again. Chart - Select the display format you need: List, Column, Graph, 2D-Graph. Record - To record the PID data for later review in Data Playback.
  • Page 57 4.12.14 Fold & Unfold PID Data Name This Diagnostic Tool allows you to fold the PID data name list so that you can view the merged graphs in a bigger screen. To fold the PID data name list, click the up arrow icon as shown below:...
  • Page 58 To unfold it, click the down arrow icon if you want to check the name of the PID data. 4.12.3.8 Data Recording & Playback Click the "Record" icon will start recording the PID data for later review through "Report" function. The Diagnostic Tool allows recording the PID data or graphing for later playback.
  • Page 59 When you have done collecting the PID data, click back icon on the top left and a prompt will pop up on the screen for you to rename the CSV file. Clicking "PREVIEW" will allow you to review the generated CSV file.
  • Page 60 4.12.4 Data View When you have exported the PID data as CSV file, this Diagnostic Tool allows you to view the CSV file on the screen. Go to Main Diagnostic Screen- Report- Data View as shown in picture below: Click "CSV View" icon and you will see all CSV file exported as in picture below:...
  • Page 61 Step 3: Follow the path on your computer and find the CSV file you want to export: My computer > D7 > Internal Shared Storage > Diagnosis > CSV records, select the CSV file you want to export and copy it to your PC memory.
  • Page 62 Step 1: Swipe up the hidden toolbar and click home icon to go to main screen of the Android tablet. Step 2: Click "File"> Local > Home > Diagnosis> CSV_records > Press and hold the CSV file you want to export to activate the selection box> tick the box> Click "More" at the bottom left of the screen>...
  • Page 63 4.12.8 Actuation Tests(Bi-Directional Controls) Actuation tests, often known as bi-directional controls or bi-directional tests, checks the operation of certain actuators, such as solenoid, valves and relays.
  • Page 64 4.12.9 Special Function The Diagnostic Tool can perform advanced functions such as resets, relearns, matchings, adaptations, initializations, and more. The available menu options may vary depending on the vehicle being diagnosed. The special functions listed under the diagnostic menu include some that are also found under "Special Function"...
  • Page 65 To distinguish this diagnostic report from the one generated during the vehicle scan or Auto Scan screen, we refer to it as the "Full System Diagnostic Report". Go to "Report" on the main diagnostic screen and click "Diagnosis Report" to view all diagnostic reports generated.
  • Page 66 4.15 Fault Code Report The other way to generate diagnostic report is through the vehicle scan/Auto Scan result screen. When you have done scanning all available vehicle electronic control modules, a generate "Report" option is available at the bottom which generates a simplified version diagnostic report that only displays the fault codes retrieved and the vehicle systems impacted.
  • Page 67 4.16 Diagnostic Speed The Diagnostic Tool provides fast all vehicle modules scan and diagnostics. However, the time it takes to scan & diagnostic all vehicle modules varies across vehicles. Factors that could influence the diagnostic speed includes the vehicle communication protocol the vehicle uses and number of vehicle control modules it's equipped.
  • Page 68 5.OBD-II/EOBD This chapter describes the concept, protocols, test functions and the basic operation of the OBD-II/EOBD function. To find OBD-II function, go to Diagnostic- Region Selection- OBD-II. This option presents a quick way to check for DTCs, locate the cause of an illuminated malfunction indicator lamp (MIL), check monitor status prior to emissions certification testing, verify repairs, and perform a number of other services that are emissions-related.
  • Page 69 IMPORTANT: Generic OBD-II data are not included in the engine system diagnostic data. 5.1 OBD-II Protocols Global OBD uses 5 communication protocols: • J1850PWM • J1850VPW • ISO 9141-2 • ISO 14230-4 • ISO 15765-4(CAN) 5.2 Basic Operations To access generic OBD-II data, please follow the steps below: Step 1: Click "Diagnostic"...
  • Page 70 5.3 Auto Scan & Protocol Selection And there are two options to access the OBD-II data of the vehicle connected. 5.3.1 Auto Scan When this option is selected, the Diagnostic Tool attempts to establish communication by sequentially trying each protocol in order to determine which one the vehicle uses for communication.
  • Page 71 5.4 10 Modes of OBD-II Mode $01 – I/M Readiness Mode $02 – Read Freeze Frame Mode $03 – Read Trouble Code Mode $04 – Clear Trouble Code Mode $05 – O2S Monitoring Test Mode $06 – On-Board Monitor Test Mode $07 –...
  • Page 72 OBD-II codes are prioritized based on their emission severity, with higher priority codes taking precedence over lower priority ones. This prioritization affects whether the Malfunction Indicator Lamp (MIL) illuminates and how the code erase procedure is managed. Different vehicle manufacturers implement these priorities in varying ways, resulting in differences in how codes are ranked and addressed across various makes and models.
  • Page 73 Use this function following a vehicle repair and code clearing procedure to verify test results after a single drive cycle. ● If a test failed during the drive cycle, the DTC associated with that test is reported. If the pending fault does not occur again within 40 to 80 warm-up cycles, the fault is automatically cleared from memory.
  • Page 74 5.6.2 Permanent Codes 5.6.2.1 First DTC Character The first DTC character is always a letter. There are four types of codes: ● P codes, "P" indicates a problem with the powertrain. It includes the engine, transmission, drivetrain, and fuel system. ●...
  • Page 75 A "1" represents a code that is specific to the car's make or model. It's known as an enhanced code, meaning it doesn't fall under an SAE standard. If you see a "1," reach out to the vehicle manufacturer directly for more information. 5.6.2.3 Third DTC character If the second DTC character is a "0,"...
  • Page 76 5.6.4 Live Data(Mode $01) Use this function to view current emission-related data from the selected electronic control module (ECM) of the vehicle. The main screen layout consists of two primary columns: the left-hand column provides descriptions of each parameter, while the right-hand column displays the corresponding parameter values along with their units or states.
  • Page 77 5.6.7 Since DTCs Cleared Displays the status of monitors since the last time the DTCs are cleared. 5.6.7.1 This Driving Cycle Displays the status of monitors since the beginning of the current driving cycle.
  • Page 78 5.6.8 O2S Monitoring Test(Mode $05) This option opens a menu of tests designed to check the integrity of the oxygen sensors (O2S). Selecting a test displays all pertinent O2S parameters specific to that test. The test ID is prominently displayed at the top of the data list. 5.6.9 On-Board Monitor Test (Mode $06) This function allows you to view the results of On-Board Monitor tests.
  • Page 79 5.6.10 Component Test(Mode $08) This function enables bidirectional control (to limited extend) of the ECM. The purpose of this function is to allow the Diagnostic Tool to control the operation of an onboard system, test, or component, such as EVAP leakage test or other test. This function is useful in determining whether the ECM responds to a command well.
  • Page 80 IMPORTANT: Not all vehicles support all service modes, so the available menu selections will vary accordingly. 6. Special Functions & Maintenance Services This chapter details various scheduled service and maintenance functions, also referred to as "Special Functions." A typical special function screen presents a series of menu-driven executive commands.
  • Page 81 ● If the service lamp is on, you must provide service for the car. After service, you need to reset the driving mileage or driving time so that the service lamp turns off and the system enables the new service cycle. ●...
  • Page 82 Step 3: Enter automatic setting menu. Step 4: Confirm the [New value] you just entered, and then click "OK" at the bottom right to complete the procedure.
  • Page 83 Step 5: Message of "Write successfully" displays when Oil Reset function has been successfully performed.
  • Page 84 6.2 EPB 1. If the brake pad wears the brake pad sense line, the brake pad sense line will send a signal to the onboard computer asking for replacing the brake pad. After replacing the brake pad, you must reset the brake pad to clear the trouble code. Otherwise, vehicle will continue to falsely notify the driver that the brake pads are in need of replacement.
  • Page 85 Step 2: Ensure your vehicle type. Step 3: Enter the maintenance mode menu and release the handbrake brake. Step 4: Wait until the message of "Successful operation" pops up. And press "OK" to exit the menu.
  • Page 86 6.3 SAS Steering Angle Sensors (SAS) System Calibration permanently stores the current steering wheel position as the straight-ahead position in the SAS EEPROM. Therefore, the front wheels and the steering wheel must be set exactly to the straight-ahead position before calibration. In addition, the VIN is also read from the instrument cluster and stored permanently in the SAS EEPROM.
  • Page 87 Step 2: Ensure you vehicle type. Step 3: Enter the Set steering angle sensor menu and follow the instructions displayed. Step 4: Follow the instructions displayed and press "OK" after completing the instructions shown.
  • Page 88 Message of "Function execution is completed" displayed when SAS reset function has been successfully completed. 6.4 BMS Reset The Battery Management System (BMS) allows the Diagnostic Tool to evaluate the battery charge state, monitor the close-circuit current, register the battery replacement and activate the rest state of the vehicle.
  • Page 89 Battery matching is performed to re-match the control module and motoring ● sensor to detect battery power usage more accurately, which can avoid an error message displayed on the instrument cluster. The operation guidelines of the BMS Reset function are shown as below: Step 1: Enter the BMS Reset menu and choose relevant models according to the vehicle being tested.
  • Page 90 Step 3: Click the "Battery Matching" icon. 6.5 Injector Coding This function can write the identification code of the fuel injector into the ECU so that the ECU can recognize the new injector. After the ECU or injector is replaced, the injector code of each cylinder must be confirmed or re-coded so that the cylinder can better identify injectors to accurately control fuel injection.
  • Page 91 Step 1: Enter the Injector coding menu and choose relevant chassis models according to the vehicle being tested. Step 2: Click "injector matching" icon.
  • Page 92 Step 3: Select the option that matches your vehicle. Wait until the message "Write successfully" pops up means that you have done. 6.6 DPF The Diesel Particle Filter (DPF) function manages DPF regeneration, DPF component replacement teach-in, and DPF teach-in after replacing the ECM. The ECM monitors driving style and selects a suitable time to employ regeneration.
  • Page 93 DPF regeneration is used to clear PM (Particulate Matter) from the DPF filter through continuous combustion oxidation mode (such as high-temperature heating combustion, fuel additive or catalyst reduce PM ignition combustion) to stabilize the filter performance. DPF regeneration may be performed in the following cases: The exhaust back pressure sensor is replaced.
  • Page 94 Step 2: Choose the function you are going to perform. Step 3: Click "OK" icon. Follow the instructions on the device screen until you see a confirmation of successful operation.
  • Page 95 6.7 TPMS Reset This function allows to perform the learning and matching and resetting functions of the tire pressure sensor. TPMS Reset may be performed in the following cases: ● Tire replacement ● After troubleshooting tire pressure related problems ● Other causes of loss of signal from the tire pressure sensor The operation guidelines of the DPF function are shown as below: Step 1: For tire pressure sensor matching, some vehicle models may need the TPMS activation tool;...
  • Page 96 And then please enter the sub-menu by the origin region of car make and select the vehicle model you need. TPMS reset can be further divided into 4 methods, such as Automatic Relearn, Static Relearn, Copy ID and OBD Relearn, which is depending on the specific model. Also, even if the relearning methods are the same, the learning procedure may differ.
  • Page 97 Step 4: Enter the tire pressure learning mode through the instrument panel on vehicle. There will be the corresponding prompt, which are differ from different car make and model, please subject to the vehicle manual or consult a professional). Step 5: Starting from the left front wheel (some models flash the turn signal at the corresponding position), use the TPMS Activation Tool to activate the sensor, and the vehicle will sound the horn or flash the turn signal at the corresponding position after successful activation.
  • Page 98 Step 7. Drive at 30-100km/h for more than 15 minutes. If relearn successful, the tire pressure warning light will go off. Otherwise, please repeat steps 4-7. Copy ID Relearn ● Step 1. Use a TPMS Activation Tool to activate the original sensor, copy the sensor ID to the tire pressure activation device Step 2.
  • Page 99 Note: Tire pressure standard is usually displayed in these places: ● Vehicle owner's manual ● Label next to the driver's door (near the B-pillar) ● Drawer next to the driver's seat of the vehicle ● Fuel tank cap 2. This scanning tool is not a replacement for a TPMS activation tool. It only provides TPMS reset/ relearn functions.
  • Page 100 Step 2: Follow the prompt steps and complete the function. Caution The ABS pump screw needs to be unscrewed ● Brake fluid will be under pressure during this process. Secure the bleed hose and ● open bleeder screws slowly Some vehicles do not support automatic bleeding, but manually bleeding ●...
  • Page 101 6.11 EEPROM This function works together with EEPROM adapter which is not included in this package to read and write data into EEPROM. 6.12 Language Change This function is to change the system language of the instrument cluster or control console 6.13 Transport Mode During shipment from the factory, a vehicle is put in a partially activate state called...
  • Page 102 6.18 HV Battery This function is used to check the voltage of individual battery pack. 6.19 Gearbox Match This function can complete the self-learning of the gearbox and improve the shift quality, when the gearbox is disassembled or repaired which may cause shifting delay or impact.
  • Page 103 6.24 FRM Reset This function is to reset the Footwell Room Module when unstable voltage triggered fault and the doors, windows, headlight malfunctions. 6.25 EGR Relearn Also called EGR Adaption. This function is used to learn the EGR (Exhaust Gas Re-Circulation) valve after it is cleaned or replaced.
  • Page 104 or swap of the VGT. This is always done when the component has been detected as operating "out of range". 6.31 Electronic Pump Activation Also known as Electric Water Pump Activation, this function is employed to initiate the operation of the electric water pump following its replacement. 6.32 Suspension This function can adjust the vehicle body height sensor for level calibration after replacing the vehicle height sensor or control module in the air suspension system,...
  • Page 105 7. Settings This chapter covers the settings for the diagnostic software or tablet, including the tablet's language, units used in the diagnostic program, USB port mode configuration, and more. 7.1 Language Go to "Settings"> "Language" to change the language of the Android tablet into the language you want to use.
  • Page 106 7.3 USB Setting Click on USB setting, you can transfer the file via Bluetooth. 7.4 Sound&Display You can adjust the volume of sound and the display of the screen.
  • Page 107 7.5 Subscription Info Here, you can check the expiration date, product activation time, and SN. 7.6 About You can check the serial number and APP version here.
  • Page 108 8. Software Updates This chapter details how the software subscription operates and outlines basic procedures for software updates. ● The subscription is an annual fee that covers compatibility with all makes and models, rather than being tied to individual models or functions. ●...
  • Page 109 To update the software programs, you have 2 (two) options: Option 1: Update All Software Programs Update all by clicking "Update All" at the bottom right of the update menu. Option 2: Update Individual Software Program Update specific software program by clicking the " "icon at the right side of the corresponding software program.
  • Page 110 IMPORTANT： It's advisable not to delete software programs close to the subscription expiration date. Instead, it's recommended to re-download any deleted software programs before the subscription expires. This ensures that you have access to the necessary software even after the subscription period ends. 9.
  • Page 111 9.2 User Manual We plan to regularly update and improve the user manual to enhance customer service. Physical copies of manuals often become outdated quickly. Additionally, the digital PDF version of the User Manual includes a search function, enabling users to locate specific information within the extensive content.
  • Page 112 Step 3: Set up a custom app name(D7 as in example above), to generate a password (16 letters) to log into this custom app. Copy and save this password. Step 4: Go to your Diagnostic Tool, swipe up to bring up the hidden toolbar menu and click the "...
  • Page 113 Step 5: Input your G-mail account and the app password (16 letters) and click "NEXT".
  • Page 114 Step 6: Set the sync frequency and click "NEXT" until it displays "Your account is set up and emails are on their way".
  • Page 115 To Share Diagnostic Report via G-mail Account: Go to Report> select the report you want to print> click "Print PDF Report"> click the job menu icon on the top right corner> Click "Share"> "Email" to go to Email composing page and sent the report via G-mail account. 10.2 Delete Email Account Step 1: Swipe up the hidden toolbar menu, click "Settings>...
  • Page 116 Step 2: Select the G-mail account you added. Step 3: Click "REMOVE ACCOUNT" and confirm.
  • Page 117 10.3 Printing Settings To enable printing service on the Diagnostic Tool, you need to install Print Service App/Print Driver first. Please go through below checklist before the installation of the printing service: 10.3.1 Checklist for Installing Printing Service Make sure your printer supports Wi-Fi connection(Wi-Fi Direct) ●...
  • Page 118 Diagnostic Tool. Step 4: Move the Mopria Print Service apk file to the Diagnostic Tool internal storage through Path: D7-Internal Shared Storage- Download. Step 5: Disconnect the Diagnostic Tool from the PC or laptop and go to ES File Explorer>...
  • Page 119 Step 6: Go to Settings Connected Devices> Connection Preferences> Printing> Mopria Print Service> Switch to On position> Select Printer> Accept the connection on the printer control panel.
  • Page 121 You may need to accept the connection to the printer on the printer's front panel to complete the setup process successfully.
  • Page 122 10.4 For Printer with Wi-Fi Direct If your printer supports Wi-Fi Direct, please follow the steps below to connect the Diagnostic Tool to the printer directly: Step 1: Swipe up the hidden toolbar menu and click “Settings”. Step 2: Click Network & internet- Wi-Fi and click the printer Wi-Fi.
  • Page 123 Step 3: Check the SSID and password displayed on the printer's front panel and use them to establish the Wi-Fi connection. If your printer doesn't have a front panel, print the printer information page on a piece of paper and use the displayed SSID and password for the Wi-Fi connection.
  • Page 124 11.1 Remote Control This function allows you to request remote assistance from our technical team to operate the Diagnostic Tool for tasks that you are not familiar with. Ensure that the Diagnostic Tool is connected to Wi-Fi. Then, click on the "Remote Control"...
  • Page 125 (S/N). This allows our technical team to access the data logs from the server and begin analyzing the issue to find a solution. 11.3 App Logging For issues related to the app, please request an app logging collection tool from our technical support team.
  • Page 126 Manual, it's best to reach out to the company directly through their designated channels. Contacting their support team or customer service would provide you with more detailed information on how to participate in these specific programs. They can guide you on the steps to take and any requirements needed to get involved. 11.9 U-Fluncer Program Whether you are an influencer that have large number of social media subscribers or amateurs that love to post content on social media platforms to to help the...
  • Page 127 This equipment emits radio frequency energy during operation, which can potentially interfere with radio communications if not installed and used as per the provided instructions. While efforts are made to minimize interference, there is no assurance that it will not occur in specific installations. If interference affects radio or television reception, you can determine if this equipment is the cause by powering it off and on.
  • Page 128 Limited Two-Year Warranty Shenzhen XTOOLtech Intelligent Co., LTD.(the Company) warrants to the original retail purchaser of this XTOOL device that should this product or any part thereof during normal usage and under normal conditions be proven defective in material or...
  • Page 129 This warranty does not apply to: 1.Products subjected to abnormal use or conditions, accident, mishandling,neglect, unauthorized alteration, misuse, improper installation/repair or, improper storage; 2. Products whose mechanical serial number or electronic serial number has been removed, altered, or defaced; 3. Damage from exposure to excessive temperature or extreme environmental conditions;...
  • Page 130 Instagram Facebook Facebook: https://www.facebook.com/XTOOLonline Instagram: https://www.instagram.com/xtoolonline/ Tiktok: https://www.tiktok.com/@xtoolonlineus YouTube: https://www.youtube.com/@xtoolonline Invent with us, test products before they hit market, help us make better products for everyone: E-mail: inventers@xtool.com Create social media content, post online and help our community: F-mail: marketing@xtool.com...
  • Page 131 15. Appendix 15.1 Navigation Path Quick Check Misfire Counters: Go Diagnostic> Auto Scan> ISO 15765-4 Module $000007E8> On-Board Monitor Test> Misfire Cylinder 1 Data> Misfire count for last/current driving cycles Fuel Loop Status: Go Diagnostic> Region> Make> Model> Year> System Selection> Full System Diagnosis>...
  • Page 132 15.2 Terms & Terminology Quick Check LTFT= Short for Long Term Fuel Trim STFT= Short for Short Term Fuel Trim MIS= Short for Misfire I/M Readiness Status= Technical term for Smog Check VGT Turbo Actuator Calibration= Turbo Actuator Pre-Align/Self Calibrate Cam Crank Relearn= Cam Pattern Relearn Crankshaft Position Variation Learn= Crankshaft Relearn= CASE Learning= Gear Learning...
  • Page 133 Q6: Can scanner tune up car? A: Sorry, D7 Diagnostic Tool does not have the capability to tune up car. Q7: Can this scanner still be used once the 3 year free updates are finished？...
  • Page 134 A: We are sorry that this diagnostic tool does not support installing Google Play store. However, if you want to install a third-party app, you can download apk file and install it on the diagnostic tool. We don't recommend installing other third-party apps as it may slow down its running speed.
  • Page 135 "send successfully". Since you use Gmail, you can follow below instructions to whitelist our sending mailbox: service@xtool.com https://downtimemonkey.com/blog/how-to-whitelist-an-email-address-in-gmail.php everyone needs to set up the whitelist, since not all the email from our mailbox will be blocked by received mailbox.
  • Page 136 A:Please try to delete the software programs by press and hold it and then re-download it again under the "Updates" to check whether this issue is solved or not. If not, please contact the our support team via support@xtoolonline.com with the S/N of the diagnostic tool.
  • Page 137 Q23: How can I subscribe the update on my D7? A: The update fee for the D7 is $99 per year. If you wish to subscribe, please proceed by transferring the payment directly to info@acartool.com via PayPal. Once the transfer is complete, kindly provide us via support@xtoolonline.com with a...
  • Page 138 Of course, if you still fail to perform the function you want after registering an account, please feel free to contact us via support@xtoolonline.com with the following information: 1. S/N printed back on your device 2. VIN of your vehicle 3.
  • Page 139 Step 3: Change the option from "No data transfer" to "File Transfer". Step 4: On the PC, check the connected devices and click on "D7" to access and manage the files stored in the internal memory of the Diagnostic Tool.
