- Page 1 VZ-ENB & EHB SERIES 55" PROFESSIONAL LED CCTV VIDEO WALL MONITOR USER MANUAL Please read this manual thoroughly before use, and keep it handy for future reference. 05232025-Rev. B...
- Page 2 1. Remote Control Function ................................2. OSD Control and Function ................................Setup SPLICE ........................................RS232 (RJ-45) Pin Map ....................................RS232 Command ......................................Mounting Guide ......................................Specification ........................................Trouble Shooting ................................................................................Warranty ........................................Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 3 The monitor shall not be exposed to dripping or splashing and objects containing liquids such as vases shall be placed near the monitor. The monitor should have ample distance (e.g. 10cm) from the wall for sufficient ventilation. User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 4 If your monitor does not operate normally – in particular, if there is any unusual sound or smell coming from the monitor – unplug it immediately and contact an authorized dealer or the service center. Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 5 While most pixel faults occur in isolated regions, a cluster of dead pixels or sub-pixels can sometimes form for which a separate ruling applies. A cluster is defined as an area of 5x5 pixels. ViewZ’s policy on pixel failure: either as an isolated fault or in the form of a cluster is outlined on the website: www.viewzusa.com User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 6 If some company or product trademark is not particularly stated, the use of trademark has been fully recognized. Do not alter, decompile, disassemble, decode or conduct reverse engineering to the software installed in the product, or it can be deemed as breach of the law. Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 7 Automatic Screwdriver Phillips & Flathead Screwdriver Bit Assembly Components - provided Your ViewZ monitor is shipped with all proper installation hardware and components. If there are parts missing and/or damaged, please stop the installation and contact ViewZ USA at (888)-998-4399.
- Page 8 Before operating the video wall monitor, please make sure you fully understand relevant prerequisites such as the specification or limitation of H/W and S/W. ViewZ shall not be responsible for loss, damage or injury caused by improper use of products.
- Page 9 Refresh Rate Display Port (1.2) In 3840 x 2160 60Hz HDMI1 (1.4) In 3840 x 2160 30Hz HDMI2 (2.0) In / Out 3840 x 2160 60Hz DVI-D In 1920 x 1080 60Hz User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 10 Either way, RJ45 (RS232) cable needs to connect as following figures and add AC Power cables. IR Receiver or RS232C Terminal IR Receiver or RS232C terminal M-Mix Software RJ45 (RS232) cable connection (Daisy Chain) of 2x2 Videowall RJ45 (RS232) cable connection (Daisy Chain) of 3x3 Videowall Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 11 And connect 2 and 3 monitors repeatedly until the last of monitor. Note • ViewZ recommend to use the short HDMI cable (less than 6 feets) for SPLICE mode (Daisy-Chain) connection. User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 12 HDMI 2 Input When the videowall has more than 12 monitors and needs to be daisy-chained, user needs to make daisy-chain as connection as following figure; Connect Method 2 HDMI 2 Input Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 13 3. Press the buttons to change the value you wish to adjust. 4. Press the ENTER button to confirm / the MENU/ EXIT button to exit for saving adjustment value on sub-menu. User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 14 On the remote controller, press ◄ ► ▼ ▲ button to change the brightness of monitor. Note • When any input source is applied, monitor will display current input source resolution and frequency. Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 15 Adjusts the difference between the lightest and darkest parts of the image 0 ~ 100 (Default: 50) BRIGHTNESS Adjusts the brightness Set the dynamic contrast ratio mode ON / OFF (Default: OFF) User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 16 Give the white color a blue-ish tint USER Apply proper values to adjust white balance - Default: R 128(0 ~ 255), G 128 (0 ~ 255), B 128 (0 ~ 255) Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 17 Increases the resolution of an image or video, Default: OFF (Off, High, Middle, Low) making it larger and sharper. DYNAMIC LUMINOUS Automatically adjusts its brightness based on ON / OFF (Default: OFF) CONTROL the content being displayed User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 18 RETURN FUNCTION VALUE ASPECT RATIO Adjust the video format Wide screen, 4:3, 1:1, Auto (Default: Wide Screen) ROTATION Rotate the display image Normal / 900 / 1800 / 2700 (Default: Normal) Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 19 Adjust the volume level AUDIO OUTPUT Select a type of audio output Earphone / Speaker (Default: Earphone) Note • ViewZ UNBS, SNB, SHB, ENB & EHB series do not support internal speaker. User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 20 Set the size of PIP screen Small, Medium, Large (Default: Medium) PIP POSITION Set the position of PIP screen TopRight, TopLeft, BottomRight, BottomLeft Default: TopRight SWAP Swap display images for PIP Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 21 0 ~ 100 (Default: 20) OSD TIME OUT Adjust the OSD display time 0 ~ 100 (Default: 20) OSD ROTATION Rotate the OSD Normal / 900 / 1800 / 2700 (Default: Normal) (Default: Normal) User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 22 CONTROL AND FUNCTION Other ▲/▼ MOVE ◄/►ADJUST ENTER SELECT MENU RETURN FUNCTION VALUE DP VERSION Display the version of DP Default: DP1.2 RESET Reset the monitor settings to the factory default Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 23 This SPLICE feature is effected when each monitor is connected with daisy chained. • For SPLICE setup, please see page 26. • If user uses ViewZ PRO series controller, this SPLICE feature is not needed to setup. User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 24 ROW ADDR & COLUMN ADDR. By using this feature, user can easily define the postion of videowall. 4) These numbers define the physical position (row & column position) on the videowall. Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 25 4 digit Random numbers RandNum 1 to 4. For example, if Random numbers is 7352, select RandNum1 as 7, RandNum2 as 3, RandNum3 as 7, and RandNum4 as 2 in order. User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 26 ROW Addr 2 ROW Addr 2 COLUMN Addr 1 COLUMN Addr 2 COLUMN Addr 3 ROW Addr 3 ROW Addr 3 ROW Addr 3 COLUMN Addr 1 COLUMN Addr 2 COLUMN Addr 3 Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 27 RS232 (RJ45) e Disconnect the IR Receiver and connect the Serial Control Cable at the IN of 1 monitor r Use the remote control program (MixControl) via a computer. Please refer "VZ-UNBS-VideoWall-SW-Manual-M-Mix" User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 28 If your setup is successfully done, you will see the image like below picture. Input Source Input Source Serial Control Interface Cat 5 Cable q-t Connection order of monitors Cable Type HDMI Cable Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 29 ViewZ. RJ45 Connector Firmware Upgrade/Update Process 1. Download or copy Firmware file from ViewZ. 2. Copy the file to the empty USB *Caution - This file should be placed in the root folder of USB. 3. The software name is fixed as FLW_V56, BIN file type. Please note that the firmware file name should not be modified, otherwise the board cannot identify the firmware file.
- Page 30 G GAIN 0 / 1 DOWN / UP B GAIN 0 / 1 DOWN / UP HORIZONTAL POSITION 0 / 1 DOWN / UP VERTICAL POSITION 0 / 1 DOWN / UP Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 31 DOWN / UP HORIZONTAL FRAME 0 ~ 100 ADJUST VERTICAL FRAME 0 ~ 100 ADJUST STILL CHANGE SYSTEM USER RESET INITIAL SYSTEM SAVE DATA SAVE THE VALUES FOR THE ABOVE ADJUSTMENT User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 32 0 / 1 DOWN / UP PREPLAN MODE SAVE PREPLAN MODE 1 ~ 16 SAVE INVOKE PREPLAN MODE 1 ~ 16 INVOKE BACKLIGHT BRIGHTNESS 0 ~ 255 S-SYSTEM AUTO NTSC SECAM Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 33 NORMAL EXCHANGE 2 SETS OF DATA AB GROUP MODE NORMAL MODE MEMORY MODE REPRODUCIBILITY ADJUSTMENT HORIZONTAL DIRECTION 0 / 1 DECREASE / INCREASE VERTICAL DIRECTION 0 / 1 DECREASE / INCREASE User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 34 Please use bolt of correct size and length as instructed. Mounting Safety ! At least two people are recommended to safely install the mount and monitor. Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 35 Accessories AC110V Power Cable x 1, HDMI Cable x 1, Manual x1, CAT5 Cable (RS232) x 1, Remote Controller x 1, IR Receiver x 1, Converter (RJ45 to RS232) x 1 User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 36 At start current input source. If symptom persists, follow the instructions below. After following the instructions below, please contact us at 1-888-99-VIEWZ. - Make sure the cable is correctly plugged into the outlet. - Make sure the power cable is correctly plugged into the monitor.
- Page 37 Failure by limited life of parts such as LED lamps and any other consumables. Damaged by using third party power cable, unstable power input and electric shock. * Above information can be changed without notification - please check our website or contact ViewZ representative for the latest RMA service policy.
- Page 38 05232025-Rev. B NOTE Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 39 05232025-Rev. B NOTE User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 40 What and Who is Covered by this Limited Warranty and for How Long ViewZ USA warrants this product to be free from defects in material and workmanship for 3 years to the original owner of this product. The limited warranty is valid only for the original purchaser of the product.
