- Page 1 VZ-ENB SERIES 49" and 55" PROFESSIONAL LED CCTV VIDEO WALL MONITOR USER MANUAL Please read this manual thoroughly before use, and keep it handy for future reference. 10072022-Rev. B...
-
Page 2: Table Of Contents
1. Remote Control Function ................................2. OSD Control and Function ................................Setup Daisy Chain ......................................RS232 (RJ-45) Pin Map ....................................RS232 Command ......................................Mounting Guide ......................................Specification ........................................Trouble Shooting ................................................................................Warranty ........................................Visit the ViewZ USA website at https://www.viewzusa.com User Manual... -
Page 3: Safety Instruction
The monitor shall not be exposed to dripping or splashing and objects containing liquids such as vases shall be placed near the monitor. The monitor should have ample distance (e.g. 10cm) from the wall for sufficient ventilation. User Manual Visit the ViewZ USA website at https://www.viewzusa.com... -
Page 4: Mark Indication & Substance
If your monitor does not operate normally – in particular, if there is any unusual sound or smell coming from the monitor – unplug it immediately and contact an authorized dealer or the service center. Visit the ViewZ USA website at https://www.viewzusa.com User Manual... -
Page 5: Available Temperature & Humidity
While most pixel faults occur in isolated regions, a cluster of dead pixels or sub-pixels can sometimes form for which a separate ruling applies. A cluster is defined as an area of 5x5 pixels. ViewZ’s policy on pixel failure: either as an isolated fault or in the form of a cluster is outlined on the website: www.viewzusa.com User Manual Visit the ViewZ USA website at https://www.viewzusa.com... -
Page 6: Fcc Rf Interference Statement
If some company or product trademark is not particularly stated, the use of trademark has been fully recognized. Do not alter, decompile, disassemble, decode or conduct reverse engineering to the software installed in the product, or it can be deemed as breach of the law. Visit the ViewZ USA website at https://www.viewzusa.com User Manual... -
Page 7: Installation
Automatic Screwdriver Phillips & Flathead Screwdriver Bit Assembly Components - provided Your ViewZ monitor is shipped with all proper installation hardware and components. If there are parts missing and/or damaged, please stop the installation and contact ViewZ USA at (888)-998-4399. -
Page 8: Features
Before operating the video wall monitor, please make sure you fully understand relevant prerequisites such as the specification or limitation of H/W and S/W. ViewZ shall not be responsible for loss, damage or injury caused by improper use of products. -
Page 9: Interface Ports
Display Port 3840 x 2160 30Hz HDMI1 (2.0) In 3840 x 2160 60Hz HDMI2 (2.0) In / Out 3840 x 2160 60Hz DVI-D In 3840 x 2160 30Hz 1920 x 1080 60Hz User Manual Visit the ViewZ USA website at https://www.viewzusa.com... -
Page 10: Remote Control Function
'ENTER' 'MENU/EXIT' 5. Press the button to confirm / the button to exit for saving adjustment value on sub-menu. 6. Press the 'MUTE' button to on / off audio-out of monitor. Visit the ViewZ USA website at https://www.viewzusa.com User Manual... -
Page 11: Select Input Source
Press ▲ / ▼ button to change input source and then press ENTER button to select input source on remote controller. If you connect any input source, monitor will display current input source resolution and frequency. User Manual Visit the ViewZ USA website at https://www.viewzusa.com... - Page 12 Give the white color a neutral tint COOL Give the white color a blue-ish tint 0 ~ 255 USER Apply user selected values - Red, Green & Blue (default: R128, G128, B128) Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
-
Page 13: Function
PANORMA / POINT TO POINT (default: AUTO) NOISE REDUCTION Estimates the amount of noise automatically and applies OFF / LOW / MIDDLE / suitable noise reduction processing HIGH / DEFAULT (default: OFF) User Manual Visit the ViewZ USA website at https://www.viewzusa.com... - Page 14 60 / 90 / 120 / 180 / 240 MIN (default: OFF) AUTO SLEEP Setup the time of automatic sleeping mode NEVER / 4 / 6 / 8 HOURS (default: NEVER) Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 15 COLOR RANGE Set the color range (default: AUTO) HDMI TYPE DVD MODE Switch between DVD and PC display mode FAN MODE Set the fan mode ON / OFF / AUTO (default: OFF) User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 16 1) This mode shuold process when all RS232 is connected based on daisy chain setup. 1) After setup of ID setting on each monitor, user should setup this for video wall monitor matrix. Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 17 To return or see all OSD on monitor, push 'POWER ON' button. 2) Change the number according the ID to unlock ID SETTING 3) Change the screen row & column number when NUMBER ('3') is matching with ID number User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
-
Page 18: Daisy Chain Connection
There are two ways to set up the daisy-chained video wall. 1. Use the IR remote controller 2. Use the Serial Control Program (M-MixControl) Input Source Before the daisy chain setup, the monitor will be shown as above Input Source Visit the ViewZ USA website at https://www.viewzusa.com User Manual... - Page 19 HDMI2 IN of 2 monitor. And connect 2 and 3 monitors repeatedly until the last of monitor. e Connect an IR sensor at RS232 (RJ45)-IN at 1 monitor. RS-232 (RJ45) IN User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 20 Press POWER ON button to unlock single screen control. i Repeat r to u to set up ID SETTING at right-top monitor (ROW-1, COLUMN-2). Finish to setup ID SETTING until the last of monitor. Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 21 ROW : 2 ROW : 2 COLUMN : 1 COLUMN : 2 COLUMN : 3 ROW : 3 ROW : 3 ROW : 3 COLUMN : 1 COLUMN : 2 COLUMN : 3 User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 22 Disconnect the IR Receiver and connect the Serial Control Cable at the IN of 1 monitor r Use the remote control program (MixControl) via a computer. Please refer " VZ-UNBS-VideoWall-SW-Manual-M-Mix" on ViewZ website; https://viewzusa.com/download/manual/VZ-UNBS-VideoWall-SW-Manual-M-Mix.pdf Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 23 If your setup is successfully done, you will see the image like below picture. Input Source Input Source Serial Control Interface Cat 5 Cable q-t Connection order of monitors Cable Type HDMI Cable User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
-
Page 24: Rs232 (Rj-45) Pin Map
ViewZ. RJ45 Connector Firmware Upgrade/Update Process 1. Download or copy Firmware file from ViewZ. 2. Copy the file to the empty USB *Caution - This file should be placed in the root folder of USB. 3. The software name is fixed as FLW_V56, BIN file type. -
Page 25: Rs232 Command
G GAIN 0 / 1 DOWN / UP B GAIN 0 / 1 DOWN / UP HORIZONTAL POSITION 0 / 1 DOWN / UP VERTICAL POSITION 0 / 1 DOWN / UP User Manual Visit the ViewZ USA website at https://www.viewzusa.com... - Page 26 DOWN / UP HORIZONTAL FRAME 0 ~ 100 ADJUST VERTICAL FRAME 0 ~ 100 ADJUST STILL CHANGE SYSTEM USER RESET INITIAL SYSTEM SAVE DATA SAVE THE VALUES FOR THE ABOVE ADJUSTMENT Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 27 0 / 1 DOWN / UP PREPLAN MODE SAVE PREPLAN MODE 1 ~ 16 SAVE INVOKE PREPLAN MODE 1 ~ 16 INVOKE BACKLIGHT BRIGHTNESS 0 ~ 255 S-SYSTEM AUTO NTSC SECAM User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 28 NORMAL EXCHANGE 2 SETS OF DATA AB GROUP MODE NORMAL MODE MEMORY MODE REPRODUCIBILITY ADJUSTMENT HORIZONTAL DIRECTION 0 / 1 DECREASE / INCREASE VERTICAL DIRECTION 0 / 1 DECREASE / INCREASE Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
-
Page 29: Mounting Guide
Please use bolt of correct size and length as instructed. Mounting Safety ! At least two people are recommended to safely install the mount and monitor. User Manual Visit the ViewZ USA website at https://www.viewzusa.com... -
Page 30: Specification
Accessories AC110V Power Cable x 1, HDMI Cable x 1, Manual x1, CAT5 Cable (RS232) x 1, Remote Controller x 1, IR Receiver x 1, Converter (RJ45 to RS232) x 1 Visit the ViewZ USA website at https://www.viewzusa.com User Manual... -
Page 31: Trouble Shooting
At start input source. If symptom persists, follow the instructions below. After following the instructions below, please contact us at 1-888-99-VIEWZ. - Make sure the cable is correctly plugged into the outlet. - Make sure the power cable is correctly plugged into the monitor. -
Page 32: Rma
Failure by limited life of parts such as LED lamps and any other consumables. Damaged by using third party power cable, unstable power input and electric shock. * Above information can be changed without notification - please check our website or contact ViewZ representative for the latest RMA service policy. - Page 33 10072022-Rev. B NOTE User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
- Page 34 10072022-Rev. B NOTE Visit the ViewZ USA website at https://www.viewzusa.com User Manual...
- Page 35 10072022-Rev. B NOTE User Manual Visit the ViewZ USA website at https://www.viewzusa.com...
-
Page 36: Warranty
What and Who is Covered by this Limited Warranty and for How Long ViewZ USA warrants this product to be free from defects in material and workmanship for 3 years to the original owner of this product. The limited warranty is valid only for the original purchaser of the product.
