CCTR-800/801/803 Vehicle Real Time GPS Tracker
Welcome to use Real Time GPS tracker CCTR-800/CCTR-801/CCTR-803, This product is with GPS
module and GSM module, It has many new and unique functions, such as real time uploading current
location to website, display history tracking on website, listen & monitor sound around the tracker, Also it
has SMS locating with internet link map or text description location or Longitude & latitude, and the other
function are also very especial, such as magnetic pin or magic paste tape, built in shock sensor to control
power saving, built in rechargeable Li-battery life is 1-10 days (standby mode), break geo-fence (in or out
area) alarm, over speed alarm, emergency SOS help, etc.
With GPS and GSM, the tracker sends the present location information through GPRS to internet
server, so that user visit the website
any computer with internet, and without downloaded any software. And it can help to arrange the whole
fleet or the vehicles of company or group or personal vehicles with the anti-hijack function.
Call the tracker or send SMS to the tracker also can trigger the tracker send back location with
internet link map or text description location or Longitude & latitude by SMS.
And also user use mobile phone visit website:
password (defined in the Terminal management), the last location information & location map will display
on your mobile phone.
It can be used as tracking cars, company vehicles, buses, taxis, trucks, outside workers, moving
equipments, transportations etc.
Tracking Platform:
www.999gps.com
www.999gps.com
with the given user name and password through
www.999gps.mobi
with the vehicle name and check
Advertisement
Table of Contents
Related Manuals for Carscop CCTR-800
Summary of Contents for Carscop CCTR-800
- Page 1 CCTR-800/801/803 Vehicle Real Time GPS Tracker Welcome to use Real Time GPS tracker CCTR-800/CCTR-801/CCTR-803, This product is with GPS module and GSM module, It has many new and unique functions, such as real time uploading current location to website, display history tracking on website, listen & monitor sound around the tracker, Also it has SMS locating with internet link map or text description location or Longitude &...
-
Page 2: Packing List
Packing list GPS tracker, Wirings, SOS button, manual etc. CCTR-800 Parts List: USB Charging Wire 12/24V Car Adapter The following is the optional accessory 12-24V DC Adapter Home AC Adapter (USA) Home AC Adapter (Europe) CCTR-801 Parts List: ON/OFF Button... - Page 3 GPRS user name & password. (Call the mobile company to confirm) 3. Before installing or uninstalling the SIM card, please power off the tracker. CCTR-800: Pulling out the long narrow rubber stopple beside the tracker, you can see the SIM card socket, beside which, press the yellow switch button with a tool and then the holder will come out.
- Page 4 � When the battery voltage in the tracker is too low, the tracker will power off automatically. CCTR-800 � When power is OFF, press the “SOS” button till the GREEN LED is ON, release the button and the tracker is power ON.
- Page 5 4. Recharge and power supply � For CCTR-800, power supply is 5V, car adapter or AC adapter is necessary for recharging, the recharging will cost 4-5 hours. If it is used in car, we recommend connect a 12-24V DC adapter to the car battery, the output insert to the tracker, and the input connect to the car battery.
-
Page 6: How To Use
moving 2 minutes, the tracker will turn off GPS & GPRS automatically (Stop uploading location), this can make the battery life longer and save GPRS data charge. 8. Using Condition The working temperature is -20 C to 60 C, over this range the specification maybe can not reach the standard level, the storage temperature can reach to -40 C to 80 How to Use... - Page 7 this can be used as fleet management, ask your dealer to contact us to get your administrator user name and password of your fleet. 8. The data & time of the tracker upload to the website is GMT time (Greenwich Mean Time, add or minus a fixed digit is your local time), you can send a SMS to the tracker to change the time to your local time,(“TIMEZONE*123456*XXX”, XXX is from -12 to +12, for example: Newyork is -05, Paris is +01,Tokyo is +09).
- Page 8 the agents. Notice: The tracker has default IP address is : “113.106.89.149,9066”, it is not necessary to set again, unless our IP address has been changed or you change the setting, If the IP is changed, we will notice on the website. Set APN name: For some mobile phone company, there must be to set the APN name to get through the internet by GPRS.
- Page 9 is a command; “123456” is password; “A” is preset number location, every tracker have 3 preset phone number locations, A and B, and C, so you can preset 3 phone numbers, if the add operation is success, the tracker will send back the information ”Add Preset Phone OK”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”.
- Page 10 (map website link) of current location to the caller. user use mobile phone to click the website link to visit internet, and the location on map will display on the mobile phone(the phone SIM card need enable the GPRS function). If the tracker has not preset number, any phone call can trigger the tracker to locate immediately, if the tracker has preset number, then only preset phone call can trigger the tracker to locate immediately.
- Page 11 Cut Oil Power (Remote Turn Off Car Engine) Send SMS “STOPENGINE*123456” to tracker, “STOPENGINE” is a command, “123456” is password, the car engine will be turned off immediately. The tracker will send back information “Car Engine turn off”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”.
- Page 12 1-2 days according the different using condition (CCTR-800 standby time is 5-7 days, uploading time is 24 hours, and CCTR-800/801 standby time is 2 days, uploading time is 8 hours, but if the GPS and GSM signal is not good will reduce the time.) “SOS”...
-
Page 13: Instruction List
The SOS function need installing the external SOS button (for CCTR-800 has not external SOS button, user can press the SOS button beside the box), install the external SOS button in a hidden place that driver can press the button, connect one wire of the SOS button to GND (car body), another wire of the SOS button to tracker SOS wire. - Page 14 location Listen & Monitor Any mobile Call back and pick up Call back to MONITOR*123456 sound phone can set the calling can listen operation phone Remote turn off car STOPENGINE*1234 Only preset Reply to operation Car Engine Turn Off engine phone can set phone Keep Tracker Online...
-
Page 15: Specification
Locate precision 10-20 Meters GPS Cold Start Time 36 seconds GPS Hot Start Time 1 second GSM / GPS Antenna Built in Battery (CCTR-800) 2000mAh Battery (CCTR-801/803) 800mAh Uploading Current <200mA / 5V Standby Current < 10 mA Working Temperature... -
Page 16: Warranty
Tracker S/N or ID: Address: □ □ □ Model: CCTR-800 CCTR-801 CCTR-803 Distributor: Notes: The explanation of this manual is belonged to our company, some small changes may not notice customer, if you have any problems please contact us, thanks!
