- Page 1 Industrial PC HPC-MT6771-080 PN: HPC-MT6771-080 Content can change at anytime, check our website for latest information of this product. www.chipsee.com...
-
Page 2: Table Of Contents
Contents HPC-MT6771-080 1. Overview 2. Ordering Options 3. Standard Accessories 4. Optional Modules 5. Hardware Specification 6. Connectivity 6.1. TF Card and SIM Card 6.2. NFC 6.3. Scanner 6.4. Bottom Pogo Pins 6.5. Serial Port 6.6. USB 7. Charging 8. Buttons 9. -
Page 3: Hpc-Mt6771-080
HPC-MT6771-080 HPC-MT6771-080 Front View Chipsee Page 3 of 29... -
Page 4: Rear View
HPC-MT6771-080 Rear View Chipsee Page 4 of 29... -
Page 5: Side View
HPC-MT6771-080 Side View 1 Chipsee Page 5 of 29... - Page 6 HPC-MT6771-080 Side View 2 Chipsee Page 6 of 29...
-
Page 7: Overview
HPC-MT6771-080 Overview Overview The HPC-MT6771-080 Handheld Tablet PC is an 8.0 inch rugged tablet PC, it’s waterproof, dustproof, suitable for outdoor operation scenarios, especially in warehousing, supermarkets, medicare, retail and other fields. The device supports 2D barcode scanner and RFID, it takes advantage of GPRS, 4G, WiFi, Bluetooth and other wireless communication channels to transmit data at a high speed efficiently. -
Page 8: Standard Accessories
HPC-MT6771-080 Standard Accessories Standard Accessories • 1 x 5V/3A Charger. • 1 x Hand strap. • 1 x Screen Protector The standard accessories include a hand strap. When you use the strap, notice the installation directions, as shown in the image below: 1 - 4 or 2 - 3 are the correct strap installation directions. - Page 9 HPC-MT6771-080 Standard Accessories Chipsee Page 9 of 29...
-
Page 10: Optional Modules
HPC-MT6771-080 Optional Modules Optional Modules The HPC-MT6771-080 does not include the following modules. Barcode Scanner. Fingerprint module. Ultra high frequency (UHF) RFID. Chipsee Page 10 of 29... -
Page 11: Hardware Specification
HPC-MT6771-080 Hardware Specification Hardware Specification Product HPC-MT6771-080 Helio P60, MediaTek MT6771, Octa(8)-Core 2.0GHz, 4 x Cortex-A53 + 4 x Cortex-A73 @ 2.0 GHz(Max) Mali-G72, 800MHz(Max) RAM/Storage 4GB+64GB / 6GB+128GB / 8GB+256GB Embedded Multi Chip Package(eMCP) Display 8.0-inch(diagonal), 1200x1920, 400 NIT IPS;... - Page 12 HPC-MT6771-080 Hardware Specification Product HPC-MT6771-080 Air Pressure Sensor, Distance Sensor, Light Sensor, Electronic Compass, Gyroscope, Sensors Accelerometer Android 11 Operating Temp. From -20°C to +60°C Storage Temp. From -25°C to +80°C Waterproof IP65; Designed for IP67 Dropping Proof 1.2m, Six Sides Dimensions 234 x 144 x 16.8 mm...
-
Page 13: Connectivity
HPC-MT6771-080 Connectivity Connectivity TF Card and SIM Card The HPC-MT6771-080 supports one SIM card and one TF card. To insert a TF card or SIM card, check the image below for the correct direction. Chipsee Page 13 of 29... -
Page 14: Nfc
HPC-MT6771-080 The HPC-MT6771-080 has one NFC module. By default, NFC is enabled in the Android OS. If NFC is not responding, please go to system settings to check if NFC is enabled. If NFC is enabled, but is still not working, try rebooting the device then test NFC again. -
Page 15: Scanner
HPC-MT6771-080 Scanner Scanner When using a scanner to scan 1D/2D barcode, first ensure the scanner switch is toggled to “ON” in the system setting. While holding the “F” button, the scanner’s led will be turned on, then you can aim the scanner at 1D barcode or 2D barcode, the code data will appear on the screen. -
Page 16: Bottom Pogo Pins
HPC-MT6771-080 Bottom Pogo Pins Bottom Pogo Pins The bottom pogo pin supports charging the device in a dock, here is the pin definition: Definition Note Pin 1 VCHG(5V IN) Charging Pin 2 VBUS(5V OUT) Pin3 USB2.0 Pin4 USB2.0 Pin5 Pin6... - Page 17 HPC-MT6771-080 Bottom Pogo Pins Chipsee Page 17 of 29...
-
Page 18: Serial Port
HPC-MT6771-080 Serial Port Serial Port RS232 Port Mini USB /dev/ttysWK1 There is a Serial Chat app installed in the Android system, you can use a mini USB cable to connect the RS232 port (protocol is RS232, data is transmitted through mini USB) and test with the app. -
Page 19: Usb
HPC-MT6771-080 There are 2 USB-A ports and 1 USB-C port. One USB-A is on the top, the other is on the bottom. There is a software OTG switch in the system setting. When USB OTG is toggled to “OFF”, USB-C is enabled, USB-A’s are disabled. When OTG is toggled to “ON”, USB-C is disabled, USB-A’s are enabled. -
Page 20: Charging
The HPC-MT6771-080 can be charged through: 5V/3A DC charger. USB-C port. The HPC-MT6771-080 ships with a 5V/3A charger; you can charge the device through the DC input port on the top of the product. The product ships with a DC charger. - Page 21 HPC-MT6771-080 Charging Chipsee Page 21 of 29...
-
Page 22: Buttons
HPC-MT6771-080 Buttons Buttons There are several buttons on the device, here is how to use them. Key P/H are reserved for customization, they have no functionality out of factory. Power Button • Short press: wake the device/put the device to sleep. -
Page 23: Dimension
HPC-MT6771-080 Dimension Dimension The dimension of HPC-MT6771-080 is 234 x 144 x 16.8 mm. Chipsee Page 23 of 29... -
Page 24: While Using The Device
HPC-MT6771-080 While Using the Device While Using the Device Do not short circuit the ports with metal, it might damage the circuits inside the device. Cleaning Please use dry, soft cloth when cleaning. Do not use chemical solvent, or the color might fade and the case might deformate. - Page 25 HPC-MT6771-080 Others Avoid exposure to direct strong sunlight or heat, they might affect the internal circuit and the case. Condensation might occur when environment temperature changes rapidly. In this case, wait an hour before using the device, to allow it to adapt to the new environment.
-
Page 26: Safety
HPC-MT6771-080 Safety Safety Please take care of the following aspects when you use this device: Follow the regulations when the device is used in the hospitals. Keep the device and accessories out of children’s reach. Put the batteries in e-waste bins if the old batteries are to be recycled. - Page 27 HPC-MT6771-080 Safety If the wireless signal is poor, go to the coverage area to take advantage of the wireless communication features. Screen performance might change due to significant temperature changes and long time usage. Chipsee Page 27 of 29...
-
Page 28: Trouble Shooting
HPC-MT6771-080 Trouble Shooting Trouble Shooting If below situations occur, please follow the instructions to fix the issues. Contact a professional if none of these help. • Device Does Not Turn On (Not pressing the power button correctly) Hold the power button for at least 2 seconds. -
Page 29: Disclaimer
If you cannot find the solution you’re looking for, feel free to contact us. Please email Chipsee Technical Support at support@chipsee.com, providing all relevant information. We value your queries and suggestions and are committed to providing you with the assistance you require.
