- Page 1 Industrial PC PPC-CM5-070-D PN: CS10600RA5070P-D Content can change at anytime, check our website for latest information of this product. www.chipsee.com...
-
Page 2: Table Of Contents
Contents PPC-CM5-070-D 1. Product Overview 2. Ordering Options ® 2.1. Pi CM5 Module 2.2. Operating System 2.3. Optional Features 3. Specifications 4. Power Input 4.1. Ignition Signal 5. Touch Screen 6. Connectivity 6.1. RS232/RS485/CAN 6.2. GPIO Port 6.3. USB Connectors 6.4. -
Page 3: Ppc-Cm5-070-D
PPC-CM5-070-D PPC-CM5-070-D Front View Chipsee Page 3 of 38... -
Page 4: Rear View
PPC-CM5-070-D Rear View Chipsee Page 4 of 38... -
Page 5: Side View
PPC-CM5-070-D Side View 1 Chipsee Page 5 of 38... - Page 6 PPC-CM5-070-D Side View 2 Chipsee Page 6 of 38...
-
Page 7: Product Overview
Installation on an industrial cabinet • Integration with the existing equipment ® The PPC-CM5-070-D industrial Pi PC is based around the powerful Raspberry Pi Compute ® Module 5, powered by the Quad Cortex -A76 processor with a processor speed of 2.4GHz. Chipsee... -
Page 8: Ordering Options
® The PPC-CM5-070-D industrial Pi PC does not include the CM5 Raspberry Pi module by default. If you would like to purchase it with a CM5, you can select it at the Chipsee store during the ordering process. Operating System This product comes with a pre-installed Raspberry Pi OS. -
Page 9: Optional Features
Optional Features The PPC-CM5-070-D industrial Pi PC does not include the 3G/4G/LTE modules by default. These modules are optional and can be selected at the Chipsee store during the ordering process. The product has a PCIe Gen 2 × 1 (5Gbps), M.2 M-Key 2230/2242 socket (PCIe 3.0 is possible but experimental for CM5), you can use it with your NVMe SSD or other modules that can fit in the slot and supports the protocol. -
Page 10: Specifications
PPC-CM5-070-D Specifications Specifications The PPC-CM5-070-D industrial Pi PC offers a broad range of performance and connectivity options for scalable integration, providing expandability according to future needs. Some of the key features are listed in the table below. PPC-CM5-070-D ® Raspberry Pi CM5/CM5Lite; BCM2712 Quad(4) Core Cortex-A76 at 2.4GHz... - Page 11 The RS485 circuit controls the Input and Output direction automatically, there’s no need to control it from within the software. The default product without the CM5 does not include a Wi-Fi/BT module. You can include a CM5 that has the Wi-Fi/BT module at the Chipsee store during the ordering process. Chipsee Page 11 of 38...
-
Page 12: Power Input
Power Input Power Input The PPC-CM5-070-D industrial Pi PC can be powered by a wide range of input voltages: From 9V to 30V (supports optional 24V ignition signal) DC. There are two DC input interfaces on this device: a 3-pin, 3.81mm screw terminal connector, and a 2.1mm DC input head. - Page 13 PPC-CM5-070-D Power Input For a proper 2.1mm x 5.5mm x 9.5mm DC power connector, refer to the figure below: DC Jack Chipsee Page 13 of 38...
-
Page 14: Ignition Signal
PPC-CM5-070-D Ignition Signal Ignition Signal The product has a “ignition signal” optional feature. By default the ignition signal is not installed. If you need this feature you can contact us when placing an order. In this setup, Pin 3 is the ignition signal pin. - Page 15 PPC-CM5-070-D Ignition Signal Power Input Definition Pin Number Definition Description Pin 1 Positive Input DC Power Positive Terminal Pin 2 Negative Input DC Power Negative Terminal Pin 3 Ignition Ignition Signal Table 329 Power Connector with Ignition Signal Chipsee Page 15 of 38...
-
Page 16: Touch Screen
Use a high-quality Power Adapter Unit (PSU) with low EMR. You can also provide power from a battery. Make sure that the PPC-CM5-070-D Power Input connector (pin 3) is properly connected to the Power System Ground to provide sufficient EMI shielding and eliminate the problem entirely. -
Page 17: Connectivity
Connectivity Connectivity There are many connectivity options available on the PPC-CM5-070-D industrial Pi PC. It has 1 x USB 3.0 type-A Host, 1 x USB 2.0 type-A Host, 1 x USB type-C OTG, 2 x Giga LAN (RJ45) Ethernet connector supporting up to 1 Gbps, and 4 x UART and 1 x CAN terminals (RS232/ RS485/CAN). - Page 18 PPC-CM5-070-D RS232/RS485/CAN RS232-RS485-CAN on the PPC-CM5-070-D Industrial PC RS232 / RS485 / CAN Pin Definition: Definition Description OS Node Number Pin 16 CAN_H CPU SPI0, CAN BUS “H” signal CAN0 Pin 15 CAN_L CPU SPI0, CAN BUS “L” signal Pin 14 RS485_5- CPU UART5, RS485 –(B) signal...
- Page 19 PPC-CM5-070-D RS232/RS485/CAN RS232 / RS485 / CAN Pin Definition: /dev/ ttyAMA4 Pin 13 RS485_5+ CPU UART5, RS485 +(A) signal /dev/ Pin 12 RS232_5_RXD CPU UART5, RS232 RXD signal ttyAMA4 Pin 11 RS232_5_TXD CPU UART5, RS232 TXD signal /dev/ Pin 10 RS485_3- CPU UART3, RS485 –(B) signal...
- Page 20 PPC-CM5-070-D RS232/RS485/CAN Attention RS485_3 and RS485_5 can control the input and output direction automatically. There’s no need to control it from within the software. The 120Ω match resistor for RS485 is NOT mounted by default. The 120Ω match resistor for CAN is NOT mounted by default. Be sure to mount the match resistor when testing CAN.
-
Page 21: Gpio Port
PPC-CM5-070-D GPIO Port GPIO Port The PPC-CM5-070-D industrial Pi PC has a 10 Pin 3.81mm GPIO Connector, as shown in the figure below. The table below gives details about the definition of every Pin. Attention In order to use the Isolated Output, you need to add an external Isolated Power to the VDD_ISO and GND_ISO. - Page 22 PPC-CM5-070-D GPIO Port GPIO Connector GPIO Connector Pin Definition: Pin Number Definition Description Pin 10 VDD_ISO Isolated Power +5V ~ +24V Input Pin 9 GND_ISO Isolated Ground Pin 8 OUT1 Isolated Output 1 Pin 7 OUT2 Isolated Output 2 Pin 6...
-
Page 23: Usb Connectors
PPC-CM5-070-D USB Connectors USB Connectors There are 1 x USB 3.0 type-A Host, 1 x USB 2.0 type-A Host, 1 x USB type-C OTG onboard, as shown in the figure below. USB HOST Connectors Attention 1. These two USB host connectors can drive 500mA for each channel at most. - Page 24 PPC-CM5-070-D USB Connectors USB Type-C OTG Connector Warning Be careful not to touch surrounding electronic components accidentally while plugging in USB devices into the embedded Industrial PC version. Chipsee Page 24 of 38...
-
Page 25: Lan
PPC-CM5-070-D The 2 x Giga LAN provides Ethernet connectivity over standardized Ethernet cables as shown in the figure below. The integrated Ethernet interface supports up to 1 Gbps data throughput. These Giga LAN signals come from the CM5 module directly. -
Page 26: Wifi & Bt Module
WiFi & BT Module WiFi & BT Module The default PPC-CM5-070-D without the CM5 does not include a Wi-Fi/BT module. If you include a CM5 that has the Wi-Fi/BT module, the product will have Wi-Fi/BT feature. The product also has an SMA connector for an external WiFi/BT antenna: WiFi+BT Antenna ... -
Page 27: 3G/4G/Lte Module
3G/4G/LTE Module 3G/4G/LTE Module The PPC-CM5-070-D industrial Pi PC is equipped with a mini-PCIe connector that can connect to a 3G/4G/LTE module. The customer will also need a SIM Card Holder and a 3G/ 4G/LTE antenna to ensure 3G/4G/LTE works on the PPC-CM5-070-D. SIM card does NOT support hot plug. - Page 28 PPC-CM5-070-D 3G/4G/LTE Module 3G/4G/LTE Module Attention The product does not come shipped with the 3G/4G/LTE module by default. If you need to use 3G/4G/LTE, you can contact us when placing an order, we can install the necessary hardware for you.
-
Page 29: M.2 Module
M.2 Module M.2 Module The PPC-CM5-070-D industrial Pi PC has a M.2 slot, it supports NVME m.2 SSD or other m.2 modules such as an AI compute module. It’s PCIe Gen 2 × 1 (5Gbps), M.2 M-Key 2230/2242 socket. The modules are not included in the product by default. -
Page 30: Camera Connector
PPC-CM5-070-D Camera Connector Camera Connector The PPC-CM5-070-D industrial Pi PC has a 22 Pin Camera Connector. The camera signals come from CAM1. The table below gives details about the definition of every pin. Camera Connector Camera Connector Pin Definition: Pin Number... - Page 31 System +3.3V Power Output, No more than 500mA Current output Table 332 Camera Connector Pin-out Attention The camera connector is supported but not mounted by default. Please contact us when placing an order if you need to use camera on the PPC-CM5-070-D. Chipsee Page 31 of 38...
-
Page 32: Tf Card Slot
PPC-CM5-070-D TF Card Slot TF Card Slot The PPC-CM5-070-D industrial Pi PC features 1 x TF Card (micro SD) slot. A slot can address up to 128GB of memory. TF (micro SD) Card Slot Attention The TF card cannot be used for memory extension. It is only used for system boot-up for CM5 LITE model. -
Page 33: Audio Connectors
PPC-CM5-070-D Audio Connectors Audio Connectors The PPC-CM5-070-D industrial Pi PC features some audio peripherals. It has 1 x 3.5mm audio output jack. Also, the PPC-CM5-070-D industrial Pi PC has a miniature 2W internal speaker for audio reproduction, as well as a small buzzer for alarm/notification sounds. -
Page 34: Hdmi Connector
PPC-CM5-070-D HDMI Connector HDMI Connector The PPC-CM5-070-D industrial Pi PC supports 1 x HDMI-D (Micro HDMI) 2.0 out, can be driven up to 4K 60FPS. Micro HDMI Connector Chipsee Page 34 of 38... -
Page 35: Prog Button
PPC-CM5-070-D PROG Button PROG Button The PPC-CM5-070-D industrial Pi PC has one button for entering usb download mode, as shown in the figure below. When booting with the button being pressed, the Raspberry Pi will boot from the USB connector. You can use this feature to download the OS software to the internal eMMC. -
Page 36: Mounting Procedure
PPC-CM5-070-D Mounting Procedure Mounting Procedure The PPC-CM5-070-D industrial Pi PC can be mounted with 4 x M4 screws, enabling simplified installation onto any standard mounting fixture. CS10600RA5070P-D You can mount CS10600RA5070P-D with VESA mounting (guide): 75 x 75 mm, 4 x M4 (6mm) screws. -
Page 37: Mechanical Specifications
PPC-CM5-070-D Mechanical Specifications Mechanical Specifications CS10600RA5070P-D For CS10600RA5070P-D, the outer mechanical dimensions are 188.05 x 123.11 x 33.20mm (W x L x H). Please refer to the technical drawing in the figure below for details related to the specific product measurements. -
Page 38: Disclaimer
If you cannot find the solution you’re looking for, feel free to contact us. Please email Chipsee Technical Support at support@chipsee.com, providing all relevant information. We value your queries and suggestions and are committed to providing you with the assistance you require.
