- Page 1 Industrial PC KIOSK-CM4-215 PN: CS19108RA4215-KK Content can change at anytime, check our website for latest information of this product. www.chipsee.com...
-
Page 2: Table Of Contents
9.2. GPIO Port 9.3. USB Connectors 9.4. LAN 9.5. WiFi & BT Module 9.6. 3G/4G/LTE Module 10. TF Card Slot 11. Audio Connectors 12. PROG Button 13. Mechanical Specifications 13.1. KIOSK-CM4-215 14. Disclaimer 15. Technical Support Chipsee Page 2 of 35... -
Page 3: Kiosk-Cm4-215
KIOSK-CM4-215 KIOSK-CM4-215 Front View Chipsee Page 3 of 35... - Page 4 KIOSK-CM4-215 Rear View Chipsee Page 4 of 35...
- Page 5 KIOSK-CM4-215 Side View 1 Chipsee Page 5 of 35...
- Page 6 KIOSK-CM4-215 Side View 2 Chipsee Page 6 of 35...
-
Page 7: Product Overview
Product Overview ® ® The Cortex -A72 Raspberry Pi series KIOSK-CM4-215 (PN: CS19108RA4215-KK) is a high- quality KIOSK product. It features a 21.5” Ten-point capacitive touch screen with a resolution of 1920 x 1080 pixels and brightness of 500 cd/m . -
Page 8: Ordering Options
® The KIOSK-CM4-215 industrial Pi Kiosk does not include the CM4 Raspberry Pi module by default. If you would like to purchase it with a CM4, you can select it at the Chipsee store during the ordering process. Operating System This product comes with a pre-installed Raspberry Pi OS. -
Page 9: Optional Features
Optional Features The KIOSK-CM4-215 industrial Pi Kiosk does not include the 3G/4G/LTE modules by default. These modules are optional and can be selected at the Chipsee store during the ordering process. The KIOSK-CM4-215 industrial Pi Kiosk includes a 13.56MHz contactless(ISO-14443A) smart card reader, it can be customized and upgraded to a hybrid dual interface contact(ISO-7816) and contactless(ISO-14443) smart card reader while placing an order. -
Page 10: Specifications
KIOSK-CM4-215 Specifications Specifications The KIOSK-CM4-215 industrial Pi Kiosk offers a broad range of performance and connectivity options for scalable integration, providing expandability according to future needs. Some of the key features are listed in the table below. KIOSK-CM4-215 ® Raspberry Pi CM4; Quad Cortex-A72 at 1.5GHz... - Page 11 The default product without the CM4 does not include a Wi-Fi/BT module. You can include a CM4 that has the Wi-Fi/BT module at the Chipsee store during the ordering process. This TF card is designed for storage expansion, as the TF card uses the same pins with WiFi, it can’t be used...
-
Page 12: Label Printer
KIOSK-CM4-215 Label Printer Label Printer The KIOSK-CM4-215 industrial Pi Kiosk features a thermal label printer (SPRT SP-RMD17). Thermal Label Printer Printing Performance Printing Method: Thermal Printing Paper Width: 57.5±0.5mm Printing Density: 8 dots/mm, 384 dots/line Printing Speed: 70mm/second (maximum) Reliability: Printhead Lifespan - 60km Usage Conditions: Print 12 ×... - Page 13 KIOSK-CM4-215 Label Printer AF50KS-E (Jujo Thermal) Thermal Paper Roll: Paper Width: 57.5±0.5mm Outer Diameter: φ60mm (maximum) Inner Diameter: φ13mm±0.3 (minimum) Paper Thickness: 0.06mm~0.08mm Printer Control Commands Character Printing Commands: Supports printing of ANK characters, custom characters, with adjustable character line spacing.
-
Page 14: Barcode Scanner
KIOSK-CM4-215 Barcode Scanner Barcode Scanner The KIOSK-CM4-215 industrial Pi Kiosk features a barcode scanner: Barcode Scanner (Standard) Barcode Scanner (Customized) The scanner module utilizes a specialized image processing chip for barcode recognition, enabling fast and stable code reading even in complex environments. - Page 15 KIOSK-CM4-215 Barcode Scanner It supports reading one-dimensional(1D) and two-dimensional(2D) codes on various media such as paper, screens, and plastics. Triggering Methods: Automatic sensing, continuous reading, command triggering Camera: 1.3MP 720p Scanning Angle: Tilt angle ±85°, rotation 360° Supported Barcode Types: •...
-
Page 16: Smart Card Reader
By default the product ships with a contactless card reader (R20C module). If you want the dual interface (contact and contactless) card reader, you can select it in the Chipsee online shop when placing an order, or contact us directly. -
Page 17: Option 2: Rcr-2900(Contact And Contactless)
Smart Card Reader (Contactless) Option 2: RCR-2900(Contact and contactless) The KIOSK-CM4-215 industrial Pi Kiosk can be customized to integrate a contact and contactless smart card reader instead of the default contactless reader. The RCR-2900 smart card reader supports hybrid dual interface contact(ISO-7816) and contactless(ISO-14443) card reading. -
Page 18: Power Input
KIOSK-CM4-215 Power Input Power Input The KIOSK-CM4-215 industrial Pi Kiosk power input is 100-240V AC 50/60Hz. As shown in the figure below. Power Input Chipsee Page 18 of 35... -
Page 19: Touch Screen
KIOSK-CM4-215 Touch Screen Touch Screen The KIOSK-CM4-215 industrial Pi Kiosk uses a 10-point capacitive touch with 1mm Armored Glass, Single-Point touch in Raspberry Pi OS Software screen. However, the Raspberry Pi OS supports only One-Point touch. The figure below shows the capacitive touch screen connected to the motherboard via the USB connector. -
Page 20: Connectivity
Connectivity Connectivity There are many connectivity options available on the KIOSK-CM4-215 industrial Pi PC. It has 2 x USB 3.0 Host, 1 x USB OTG, 1 x Giga LAN (RJ45) Ethernet connector supporting up to 1 Gbps, and 4 x UART and 1 x CAN terminals (RS232/RS485/CAN). - Page 21 KIOSK-CM4-215 RS232/RS485/CAN RS232 / RS485 / CAN Pin Definition: Pin 5 RS485_3- CPU UART3, RS485 –(B) signal Pin 6 RS485_3+ CPU UART3, RS485 +(A) signal Pin 7 RS232_2_RXD CPU UART2, RS232 RXD signal Pin 8 RS232_2_TXD CPU UART2, RS232 TXD signal...
-
Page 22: Gpio Port
KIOSK-CM4-215 GPIO Port GPIO Port The KIOSK-CM4-215 industrial Pi Kiosk has a phoenix connector, as shown in the figure below. The table below gives details about the definition of every Pin. Attention In order to use the Isolated Output, you need to add an external Isolated Power to the VDD_ISO and GND_ISO. - Page 23 KIOSK-CM4-215 GPIO Port GPIO Connector GPIO Connector Pin Definition: Pin Number Definition Description Pin 12 24V_ISO Isolated Power +24V Input Pin 11 GND_ISO Isolated Ground Pin 10 OUT1 Isolated Output 1 Pin 9 OUT2 Isolated Output 2 Pin 8 OUT3...
-
Page 24: Usb Connectors
KIOSK-CM4-215 USB Connectors USB Connectors There are 2 x USB 3.0 Host, 1 x USB OTG onboard, as shown in the figure below. USB HOST Connectors Attention 1. These two USB host connectors can drive 500mA for each channel at most. - Page 25 KIOSK-CM4-215 USB Connectors Warning Be careful not to touch surrounding electronic components accidentally while plugging in USB devices into the embedded Industrial PC version. Remember to unplug the Type-C cable after flashing OS, otherwise the USB hosts won’t work.
-
Page 26: Lan
KIOSK-CM4-215 The 1 x Giga LAN provides Ethernet connectivity over standardized Ethernet cables as shown in the figure below. The integrated Ethernet interface supports up to 1 Gbps data throughput. These Giga LAN signals come from the CM4 module directly. -
Page 27: Wifi & Bt Module
WiFi & BT Module WiFi & BT Module The default KIOSK-CM4-215 without the CM4 does not include a Wi-Fi/BT module. If you buy a CM4 that has the Wi-Fi/BT module, the product will have Wi-Fi/BT feature. By default the kiosk doesn’t ship with WiFi antenna SMA, nor is there a drill hole. But if you buy the CM4 with Wi-Fi/BT module from us or contact us when placing an order, we can drill hole on the kiosk and install the antenna SMA for you. -
Page 28: 3G/4G/Lte Module
3G/4G/LTE Module 3G/4G/LTE Module The KIOSK-CM4-215 industrial Pi Kiosk is equipped with a mini-PCIe connector that can connect to a 3G/4G/LTE module. The customer will also need a SIM Card Holder and a 3G/ 4G/LTE antenna to ensure 3G/4G/LTE works on the KIOSK-CM4-215. SIM card does NOT support hot plug. - Page 29 KIOSK-CM4-215 3G/4G/LTE Module Figure 967: SIM Card Holder and 3G/4G/LTE Antenna Attention The product does not come shipped with the 3G/4G/LTE module by default. If you need to use 3G/4G/LTE, you can contact us when placing an order, we can install the necessary hardware for you.
- Page 30 KIOSK-CM4-215 3G/4G/LTE Module 4G Antenna Chipsee Page 30 of 35...
-
Page 31: Tf Card Slot
KIOSK-CM4-215 TF Card Slot TF Card Slot The KIOSK-CM4-215 industrial Pi Kiosk features 1 x TF Card (micro SD) slot. A slot can address up to 128GB of memory. TF (micro SD) Card Slot Attention The SD is used for memory extension. It can’t be used for system boot-up. -
Page 32: Audio Connectors
KIOSK-CM4-215 Audio Connectors Audio Connectors The KIOSK-CM4-215 industrial Pi Kiosk features some audio peripherals. It has 1 x 3.5mm audio output jack. Also, the KIOSK-CM4-215 industrial Pi PC has a miniature 2W internal speaker for audio reproduction, as well as a small buzzer for alarm/notification sounds. -
Page 33: Prog Button
KIOSK-CM4-215 PROG Button PROG Button The KIOSK-CM4-215 industrial Pi Kiosk has one button for entering usb download mode, as shown in the figure below. When booting with the button being pressed, the Raspberry Pi will boot from the USB connector. You can use this feature to download the OS software to the internal eMMC. -
Page 34: Mechanical Specifications
KIOSK-CM4-215 Mechanical Specifications Mechanical Specifications KIOSK-CM4-215 For KIOSK-CM4-215, the outer mechanical dimensions are 826 x 380 x 138mm (W x L x H). Technical Drawing Chipsee Page 34 of 35... -
Page 35: Disclaimer
If you cannot find the solution you’re looking for, feel free to contact us. Please email Chipsee Technical Support at support@chipsee.com, providing all relevant information. We value your queries and suggestions and are committed to providing you with the assistance you require.
