- Page 1 Industrial PC HPC-MT6737-035 PN: HPC-MT6737-035 Content can change at anytime, check our website for latest information of this product. www.chipsee.com...
-
Page 2: Table Of Contents
Contents HPC-MT6737-035 1. Overview 2. Ordering Options 3. Hardware Specification 4. Standard Accessories 5. Charging 6. Scanner 7. Buttons 8. TF/SIM Card 9. Camera 10. Rear Lock 11. Dimension 12. Barcode Admin App 13. While Using the Device 13.1. USB 13.2. -
Page 3: Hpc-Mt6737-035
HPC-MT6737-035 HPC-MT6737-035 Front View Chipsee Page 3 of 33... -
Page 4: Rear View
HPC-MT6737-035 Rear View Chipsee Page 4 of 33... -
Page 5: Side View
HPC-MT6737-035 Side View 1 Chipsee Page 5 of 33... - Page 6 HPC-MT6737-035 Side View 2 Chipsee Page 6 of 33...
-
Page 7: Overview
HPC-MT6737-035 Overview Overview The HPC-MT6737-035 is an industrial handheld barcode scanner, it is produced with two- color injection molding, IP65 standard protection, suitable for harsh environments, such as ticket inspection, retail, warehousing, supermarkets, transportation, logistics and other fields. It features a 28nm Quad(4) core, 1.3GHz Cortex-A53 ARM CPU, Android 7.0 operating system, 2GB RAM, 16GB storage, 3.5 inch capacitive touch panel. -
Page 8: Hardware Specification
HPC-MT6737-035 Hardware Specification Hardware Specification Product HPC-MT6737-035 MediaTek MT6737, Quad(4)-Core, 4 x 1.3GHz ARM Cortex-A53 Mali-T720 MP2 Android 7.0 RAM/Storage 2GB+16GB Display 3.5 inch (diagonal), 320x480, capacitive touch Camera 5MP Rear camera WiFi Support for 802.11 a/b/g/n WiFi Bluetooth Support for BT 4.0 (backwards compatible) -
Page 9: Standard Accessories
HPC-MT6737-035 Standard Accessories Standard Accessories The standard accessories include: • 1 x Hand strap. • 1 x USB-A to DC cable. • 1 x USB-A to USB-C cable. • 1 x Charger. Chipsee Page 9 of 33... -
Page 10: Charging
HPC-MT6737-035 Charging Charging You can use the bottom charging port to charge the battery in the device directly. Chipsee Page 10 of 33... -
Page 11: Scanner
HPC-MT6737-035 Scanner Scanner By default, the product ships with a integrated scanner. For 1D bar code, the scanner can read UPC-A, UPC-E, EAN-8, EAN-13, Code128, Code39, Interleaved 2 of 5, Codabar, Matrix 2 of 5. For 2D bar code, the scanner can read Code39, PDF417, Data Matrix. -
Page 12: Buttons
HPC-MT6737-035 Buttons Buttons There are 29 buttons on the device. By default, the three yellow buttons (left yellow button, right yellow button, yellow button on top of the main keyboard) are shortcuts to trigger the scanner. F1, F2, F3 and F4 have no definition by default. -
Page 13: Tf/Sim Card
HPC-MT6737-035 TF/SIM Card TF/SIM Card There is a TF card (microSD) slot on the device, it supports up to 128GB external storage. There is a SIM card slot on the device, as shown in the image below: Chipsee Page 13 of 33... -
Page 14: Camera
HPC-MT6737-035 Camera Camera The device has a rear 5MP camera by default, it also has a flashlight, and supports autofocus. Chipsee Page 14 of 33... -
Page 15: Rear Lock
HPC-MT6737-035 Rear Lock Rear Lock When you need to remove the battery or open the rear case, there is a lock in the rear as shown in the image below. It helps seal the case when it is switched to the “lock” side, and in this case, the rear case cannot be opened. -
Page 16: Dimension
HPC-MT6737-035 Dimension Dimension The dimension of this product is 185 x 71 x 35 mm. Chipsee Page 16 of 33... -
Page 17: Barcode Admin App
HPC-MT6737-035 Barcode Admin App Barcode Admin App The device has a Barcode Admin App to set up the barcode scanner module. Here is how to use it. Click the BarcodeAdmin app in the APP icons: Barcode Scan Function Toggle on and off the barcode scan function:... - Page 18 HPC-MT6737-035 Barcode Admin App Scan by Pressing Key If “Enable Scan Key” is on, you can tick the boxes below to control which keys can trigger a scan (key names may vary on different models): Chipsee Page 18 of 33...
- Page 19 HPC-MT6737-035 Barcode Admin App Output Setting Chipsee Page 19 of 33...
- Page 20 HPC-MT6737-035 Barcode Admin App Trigger method Default mode is short press to trigger a scan, until timeout: Chipsee Page 20 of 33...
- Page 21 HPC-MT6737-035 Barcode Admin App Output Mode Broadcast output: Suitable for APPs developed based on this barcode service. Add data to EditText automatically after scan data: Fill in the data directly after scanning, suitable for any APPs that can be installed.
- Page 22 HPC-MT6737-035 Barcode Admin App Automatic Commit Automatically commit data after scanning (like automatically hit return/confirm button). Data Trim (delete whitespace) For barcodes with prefix whitespace or suffix whitespace, this function automatically deletes them. Chipsee Page 22 of 33...
- Page 23 HPC-MT6737-035 Barcode Admin App Output Separator Add a separator after scanning when output. TAB: Suitable for saving tables, like pressing the Excel line feed button. Dot / Star: Add a (. or *) symbol after scanning. Chipsee Page 23 of 33...
- Page 24 HPC-MT6737-035 Barcode Admin App Tips Settings Set an indication when scanning a barcode. Indicator tone: Select a barcode scan Success sound. Tone volume: The volume of the sound. Indicator Led: If enabled, the power indicator will blink after a successful scan.
- Page 25 HPC-MT6737-035 Barcode Admin App Other Settings Supported Code Setting: Common barcode types are supported out of box, special types need to be checked manually in this setting. Laser Time: The laser is turned on when scanning, this option configures how long the laser would be turned on when scanning.
- Page 26 HPC-MT6737-035 Barcode Admin App Chipsee Page 26 of 33...
- Page 27 HPC-MT6737-035 Barcode Admin App Chipsee Page 27 of 33...
-
Page 28: While Using The Device
HPC-MT6737-035 While Using the Device While Using the Device Do not short circuit the ports with metal, it might damage the circuits inside the device. Cleaning Please use dry, soft cloth when cleaning. Do not use chemical solvent, or the color might fade and the case might deformate. - Page 29 HPC-MT6737-035 Others Avoid exposure to direct strong sunlight or heat, they might affect the internal circuit and the case. Condensation might occur when environment temperature changes rapidly. In this case, wait an hour before using the device, to allow it to adapt to the new environment.
-
Page 30: Safety
HPC-MT6737-035 Safety Safety Please take care of the following aspects when you use this device: Follow the regulations when the device is used in the hospitals. Keep the device and accessories out of children’s reach. Put the batteries in e-waste bins if the old batteries are to be recycled. - Page 31 HPC-MT6737-035 Safety If the wireless signal is poor, go to the coverage area to take advantage of the wireless communication features. Screen performance might change due to significant temperature changes and long time usage. Chipsee Page 31 of 33...
-
Page 32: Trouble Shooting
HPC-MT6737-035 Trouble Shooting Trouble Shooting If below situations occur, please follow the instructions to fix the issues. Contact a professional if none of these help. • Device Does Not Turn On (Not pressing the power button correctly) Hold the power button for at least 2 seconds. -
Page 33: Disclaimer
If you cannot find the solution you’re looking for, feel free to contact us. Please email Chipsee Technical Support at support@chipsee.com, providing all relevant information. We value your queries and suggestions and are committed to providing you with the assistance you require.
