ULTERRA® QUEST
BOW-MOUNT TROLLING MOTOR
Owner's Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the ULTERRA QUEST and is the answer not in the manual?

Questions and answers

Related Manuals for MINN KOTA ULTERRA QUEST

Summary of Contents for MINN KOTA ULTERRA QUEST

  • Page 1 ULTERRA® QUEST BOW-MOUNT TROLLING MOTOR Owner's Manual...
  • Page 2 Thank you for choosing Minn Kota. We believe that you should spend more time fishing and less time positioning your boat. That’s why we build the smartest, toughest, most intuitive trolling motors on the water. Every aspect of a Minn Kota trolling motor is thought out and rethought until it’s good enough to bear our name.
  • Page 3 Installing the Ulterra QUEST ............ 10 Stowing and Deploying with the Foot Pedal ......64 BATTERY & WIRING INSTALLATION ............15 Adjusting the Depth (Trim) of the Ulterra QUEST ....65 Boat Rigging & Product Installation .......... 15 Trimming with the Wireless Remote ........65 Conductor Gauge and Circuit Breaker Sizing Table ....
  • Page 4 WARNING You are responsible for the safe and prudent operation of your vessel. We have designed your Minn Kota product to be an accurate and reliable tool that will enhance boat operation and improve your ability to catch fish. This product does not relieve you from the responsibility for safe operation of your boat.
  • Page 5 Minn Kota Limited Two-Year Warranty on the Entire Product JOME warrants to the original retail purchaser only that the purchaser’s new Minn Kota freshwater trolling motor will be materially free from defects in materials and workmanship appearing within two (2) years after the date of purchase. JOME will (at its option) either repair or replace, free of charge, any parts found by JOME to be defective during the term of this warranty.
  • Page 6 KNOW YOUR BOAT Starboard Starboard Port Port Inboard Inboard Outboard Outboard Keel Keel Port Port Starboard Starboard Gunwale Gunwale Transom Transom Stern Stern Gunwale Gunwale Stern Stern Hull Hull 6 | minnkota.johnsonoutdoors.com ©2025 Johnson Outdoors Marine Electronics, Inc.
  • Page 7 FEATURES Advanced GPS Advanced GPS Navigation Navigation Indicator Panel Indicator Panel ULTERRA Coil Cord Slider   Coil Cord Slider SYSTEM STATUS SYSTEM STATUS SYSTEM STATUS Trim Housing Trim Housing Motor Ramp Motor Ramp Steering Housing Steering Housing Indicator Panel Indicator Panel Lifetime Warranty Lifetime Warranty...
  • Page 8 INSTALLING THE ULTERRA QUEST Your new Ulterra QUEST comes with everything you’ll need to install it directly to the boat. The motor can be mounted directly to the bow or coupled with a Minn Kota quick release bracket for ease of mounting and removal. For compatible quick release brackets and to locate your nearest dealer, visit minnkota.johnsonoutdoors.com.
  • Page 9 Shaft and Control Head and that they do not extend off the side of the boat. All six mounting holes must be used when securing the Ulterra QUEST to the boat deck. If the desired mounting location does not allow for all six mounting holes and mounting bolts, a Boat Deck Reinforcement Kit (1854058) should be used or a new mounting location selected.
  • Page 10 NOTICE: The trolling motor weighs up to 90lb. Minn Kota recommends having a second person help with the installation. Remove the four Sideplate Screws using a #3 Phillips Screwdriver. Two of these screws will be located on each side of the mount.
  • Page 11 Drilling Locations Drilling Locations NOTICE: New mounting holes are required when upgrading from an Ulterra to an Ulterra QUEST. New mounting holes will accommodate the higher thrust NOTICE: The mounting surface for the Ulterra QUEST motor and ensure the installation is secure.
  • Page 12 INSTALLING THE ULTERRA QUEST ITEM(S) NEEDED #1 x 3 #2 x 3 #3 x 3 #4 x 3 #5 x 1 Starboard Starboard NOTICE: To prevent seizing of the stainless steel Port Port hardware, do not use high-speed installation tools.
  • Page 13 INSTALLING THE ULTERRA QUEST ITEM(S) NEEDED #1 x 2 #2 x 2 #3 x 2 #4 x 2 #5 x 1 NOTICE: To prevent seizing of the stainless steel Inboard Inboard hardware, do not use high-speed installation tools. Hex Head...
  • Page 14 INSTALLING THE ULTERRA QUEST ITEM(S) NEEDED #1 x 1 #2 x 1 #3 x 1 #4 x 1 #5 x 1 To complete the installation, the last Bolt must be inserted into the Base Extrusion from the bottom up. Take one Hex Head Bolt (Item #1) and apply anti-seize (Item #5) to the Bolt.
  • Page 15 CAUTION These guidelines apply to general rigging to support your Minn Kota motor. Powering multiple motors or additional electrical devices from the same power circuit may impact the recommended conductor gauge and circuit breaker size. If you are using wire longer than that provided with your unit, follow the conductor gauge and circuit breaker sizing table below.
  • Page 16 Lithium Ion batteries, manufacturers may recommend storing in a semi-charged state and charging fully prior to use. If using a crank battery to start a gasoline outboard, Minn Kota recommends using a separate battery/batteries for your Minn Kota trolling motor. Always check with the battery manufacturer for specific maintenance, care and storage instructions. Minn Kota also offers a wide selection of chargers to fit your charging needs.
  • Page 17 Minn Kota recommends using Minn Kota brand chargers to recharge the batteries connected to your Minn Kota trolling motor, as they have been engineered to work with motors that include a bonding wire. Learn more about Minn Kota chargers online at minnkota.johnsonoutdoors.com.
  • Page 18 CONNECTING THE BATTERIES IN SERIES CONNECTING THE BATTERIES IN SERIES (IF REQUIRED FOR YOUR MOTOR) 24-Volt Systems +24 Volts to trolling motor Two 12-volt batteries are required. The batteries must be wired in To trolling motor negative positive (or circuit breaker) series, only as directed in the wiring diagram, to provide 24 volts.
  • Page 19 CONNECTING THE BATTERIES IN SERIES 36-Volt Systems Three 12-volt batteries are required. The batteries must be wired in series, only as directed in the wiring diagram, to provide 36 volts. Make sure that the motor is switched off (speed selector on “0”). +36 Volts to trolling motor To trolling motor negative positive (or circuit breaker)
  • Page 20 Each time the trolling motor is powered "on," the control board will auto-detect the power supplied from the battery system and adjust the thrust output based on a 24V or 36V battery system. To verify power to the trolling motor, connect the Ulterra QUEST to power. At specific points in the installation, power will be disconnected or turned "off"...
  • Page 21 GPS signal strength of one bar, all remaining functions will become available. The Wireless Remote comes from the factory NOTICE: paired to the Ulterra QUEST. NOTICE: Attaching the Lanyard (Item #7) to the Wireless Remote is optional.
  • Page 22 INSTALLING THE FOOT PEDAL Installing the Foot Pedal ITEM(S) NEEDED #14 x 4 #C x 1 Take the Foot Pedal (Item #C) and turn it over. Put a Foot Pedal Pad (Item #14) in each of the pad locations. Foot Pedal Foot Pedal Bottom Bottom...
  • Page 23 Feature & Cable Identification The Ulterra QUEST is pre-installed with Advanced GPS Navigation - including the ability to connect via Ethernet to a Humminbird unit. The motor is also pre-installed with sonar, either Dual Spectrum CHIRP or Built-in MEGA Side Imaging. These features may be installed on their own or in combination with another feature.
  • Page 24 FEATURE & CABLE MANAGEMENT Feature & Cable Management DUAL SPECTRUM CHIRP Your trolling motor may be pre-installed with a transducer system Dual Spectrum CHIRP Lower Unit featuring Humminbird’s Dual Spectrum CHIRP. CHIRP stands for “Compressed High Intensity Radar Pulse.” Dual Spectrum CHIRP is a 2D sonar transducer with a temperature sensor that is integrated into the lower unit of the trolling motor.
  • Page 25 DUAL SPECTRUM CHIRP The integrated design of the Dual Spectrum CHIRP transducer protects it in the lower unit of the trolling motor from underwater hazards and prevents tangles and damage to the transducer cables. In certain situations, air bubbles may adhere to the surface of the Dual Spectrum CHIRP transducer and affect the performance.
  • Page 26 If using cable ties, do not over-tighten. Any excess cable should be bundled in a loose loop of no less than 4” in diameter. The connection cable should be routed to the fish finder following Minn Kota recommendations on routing the cables to optimize mobility and maximize functionality.
  • Page 27 DUAL SPECTRUM CHIRP If installing directly to a Solix or Apex, the connection Fourteen-Pin Fourteen-Pin will be flat on the back of the fish finder display. Connector Connector Align the pins on the Accessory Cable with the Dual Spectrum CHIRP Dual Spectrum CHIRP receptacle on the fish finder.
  • Page 28 DUAL SPECTRUM CHIRP ITEM(S) NEEDED #18 x 1 If installing directly to a Helix Adapter Cable, align Fourteen-Pin Fourteen-Pin Receptacle Receptacle the pins on the accessory cable or extension cable Connector Connector with the receptacle on the Helix Adapter Cable (Item #18).
  • Page 29 Built-in MEGA Side Imaging+ comes available in the Minn Kota flagship families of trolling motors, including Ultrex and Ulterra, with 200 feet of coverage on either side of your boat. With Humminbird MEGA imaging sonar built right into the trolling motor, you now have a crystal clear view of what’s directly to the left and...
  • Page 30 Place the motor in the deployed position. NOTICE: For instructions on deploying the motor, see the “Stowing and Deploying the Ulterra QUEST” section of this manual. Locate the Fourteen-Pin Connector at the end of the Built-in MEGA Side Imaging accessory cable.
  • Page 31 BUILT-IN MEGA SIDE IMAGING If installing directly to a Solix or Apex, the connection Fourteen-Pin Fourteen-Pin will be flat on the back of the fish finder display. Connector Connector Align the pins on the Accessory Cable with the Built-in MEGA Side Built-in MEGA Side receptacle on the fish finder.
  • Page 32 BUILT-IN MEGA SIDE IMAGING ITEM(S) NEEDED #18 x 1 If installing directly to a Helix Adapter Cable, align 4h Fourteen-Pin Fourteen-Pin Receptacle Receptacle the pins on the accessory cable or extension cable Connector Connector with the receptacle on the Helix Adapter Cable (Item #18).
  • Page 33 ADVANCED GPS NAVIGATION Your Minn Kota trolling motor and Humminbird fish finder communicate with each other to change the way you fish. Advanced GPS Navigation offers a large array of features including controlling speed, steering, Spot-Lock, and the ability to record and retrace paths on the water, all at your fingertips.
  • Page 34 Eight-Pin Eight-Pin Connector Connector NOTICE: For instructions on deploying the motor, Advanced GPS Advanced GPS see the “Stowing and Deploying the Ulterra QUEST” Ethernet Connector Ethernet Connector Advanced Advanced Sonar Sonar section of this manual. GPS Ethernet...
  • Page 35 ADVANCED GPS NAVIGATION ITEM(S) NEEDED #15 x 1 Identify the keyed Receptacle on the Ethernet Cable Advanced GPS Advanced GPS (Item #15). It will be keyed to fit with the Eight- Control Control Ethernet Ethernet Eight-Pin Eight-Pin Head Head Connector Connector Pin Advanced GPS Ethernet Connector below the Connector...
  • Page 36 ADVANCED GPS NAVIGATION Take the Receptacle on the end of the Ethernet Receptacle Receptacle Ethernet Cable Ethernet Cable Cable covered in a braided sleeve. The Receptacle with the braided sleeve will be inserted into the Coil Cord and connected to the Advanced GPS Ethernet Bare Bare Braided...
  • Page 37 Cable Cable Cable to secure the connection. Helix Adapter Cable Helix Adapter Cable NOTICE: Minn Kota provides one Helix Adapter Cable (AS EC QDE - Ethernet Adapter Cable - 720074-1) with every trolling motor equipped with Advanced GPS Navigation. Ethernet...
  • Page 38 SECURING ACCESSORY CABLES Securing Accessory Cables NOTICE: If only one cable is present below the Control Head, this installation is not applicable. Before securing accessory cables, please review the "Identifying Trolling Motor Features and Their Associated Cables" section of this document.
  • Page 39 #17 x 1 Place the motor in the stowed position. Control Head Control Head NOTICE: For instructions on stowing the motor, see the “Stowing and Deploying the Ulterra QUEST” Advanced GPS Advanced GPS Ethernet Connector Ethernet Connector section of this manual.
  • Page 40 INSTALLING THE PROP Installing the Prop ITEM(S) NEEDED #10 x 1 #11 x 1 #12 x 1 #13 x 1 CAUTION Drive Drive Disconnect the motor from the battery before beginning any Prop work or maintenance. Take the Drive Pin (Item #13) and slide it through Armature Armature the Hole in the Armature Shaft.
  • Page 41 OPTIMIZING THE PERFORMANCE OF THE ULTERRA QUEST WITH THE WIRELESS REMOTE OR ONE-BOAT NETWORK APP Minn Kota® and Humminbird® have joined forces to bring you the One-Boat Network, including the latest Advanced GPS Navigation Wireless Remote and the One-Boat Network app. The Wireless Remote comes from the factory paired to the trolling motor.
  • Page 42 ONE-BOAT NETWORK ADJUSTMENTS ONE-BOAT NETWORK ADJUSTMENTS KEEL OFFSET The Ulterra QUEST comes from the factory with the Lower Unit NOTICE: When the motor is installed from the factory, parallel to the Mount. When the Lower Unit is parallel to the Mount, the Keel Offset is 0 degrees.
  • Page 43 KEEL OFFSET Press the Menu button on the Wireless Remote. Use the Speed Up or Speed Down button to find the Motor Settings menu. Use the Steer Right button to select Motor Settings. In the Motor Settings Menu, use the Speed Up or Speed Down button to find Setup/Calibration.
  • Page 44 KEEL OFFSET Setting the Keel Offset with the One-Boat Network App Power on the trolling motor by pressing the Power Indicator Panel Indicator Panel button on the Indicator Panel. When the trolling System System motor is on, the System Status LED will be blue.
  • Page 45 KEEL OFFSET In the Motor Settings menu, find and tap Setup and Calibration. In Setup and Calibration, find and tap Keel Mount Offset. Review all safety warnings. Follow the prompts in the One-Boat Network app. If the placement of the trolling motor is pointing forward and parallel to the keel, tap Set.
  • Page 46 STRAIGHT ON DEPLOY Minn Kota recommends setting the Keel Offset when the position of the Lower Unit is parallel with the Keel. Save the Keel Offset before exploring the Straight on Deploy feature. Straight on Deploy uses the position recorded in Keel Offset to know where to position the Lower Unit to be parallel with the Keel.
  • Page 47 STRAIGHT ON DEPLOY To Toggle Straight on Deploy with the One-Boat Network App Open the One-Boat Network (OBN) app on a mobile device. Make sure the mobile device is paired with the trolling motor and that the motor is powered "on." From the OBN home screen, tap the Motor menu.
  • Page 48 STOW ORIENTATION STOW ORIENTATION The Stow Orientation is a term used to describe the lower unit and Prop position when the motor is stowed. The lower unit will automatically rotate into the Stow Orientation when stowing the motor. The Stow Orientation can be set to Prop Left or Prop Right through the Wireless Remote or One-Boat Network app.
  • Page 49 STOW ORIENTATION Setting the Stow Orientation with the One-Boat Network App Open the One-Boat Network (OBN) app on a mobile device. Make sure the mobile device is paired with the trolling motor and that the motor is powered "on." From the OBN home screen, tap the Motor menu. The Motor menu opens the Motor home screen.
  • Page 50 Boat Scale provides a method of adjusting how the trolling motor will perform to account for these and other variables. The Ulterra QUEST comes from the factory with Boat Scale set to zero. Boat Scale can be adjusted up (+2) or down (-2) to increase or decrease how the motor control software applies power while using a navigation mode like Spot-Lock.
  • Page 51 BOAT SCALE Adjusting Boat Scale with the One-Boat Network App Open the One-Boat Network (OBN) app on a mobile device. Make sure the mobile device is paired with the trolling motor and that the motor is powered "on." From the OBN home screen, tap the Motor menu. The Motor menu opens the Motor home screen.
  • Page 52 ONE-BOAT NETWORK BUTTONS Minn Kota trolling motors equipped with Advanced GPS Navigation are compatible with devices enabled with the One-Boat Network (OBN), such as the Wireless Remote and Foot Pedal. OBN functions can be enabled and disabled through customizable OBN buttons on the Wireless Remote and Foot Pedal.
  • Page 53 CUSTOMIZING THE ONE-BOAT NETWORK BUTTONS ON THE WIRELESS REMOTE One-Boat Network functions can be enabled and disabled through four One-Boat Network buttons on the Wireless Remote. The One- Boat Network buttons can be customized to control the following functions, depending on your setup: Function Icon Description...
  • Page 54 CUSTOMIZING THE ONE-BOAT NETWORK BUTTONS ON THE WIRELESS REMOTE Customize the One-Boat Network Buttons on the Wireless Remote On the Wireless Remote, press the Menu button to open the Motor Menu. In the Motor Menu, use the Speed Down Speed Up button to find the Motor Settings menu.
  • Page 55 CUSTOMIZING THE ONE-BOAT NETWORK BUTTON ON THE FOOT PEDAL Minn Kota trolling motors equipped with Advanced GPS Navigation are compatible with devices enabled with the One-Boat Network, such as the Foot Pedal. One-Boat Network functions are enabled and disabled through the Foot Pedal with the One-Boat Network button.
  • Page 56 The radio button next to the desired function will be selected when the Steer Right button is used to customize the function. AutoPilot is the default selection for Ulterra QUEST trolling motors. The function options listed are based on the trolling motor and other devices in the Advanced GPS Navigation network.
  • Page 57 MOTOR WIRING DIAGRAM ULTERRA QUEST The following Motor Wiring Diagram applies to all Ulterra QUEST models. Sonar is either Dual Spectrum CHIRP or Built-in MEGA Side Imaging. Advanced Coil Cord Navigation Trim Sensor Communication Advanced red, Brushless yellow Communication Sonar...
  • Page 58 USING & ADJUSTING THE MOTOR MOUNT FEATURES Become familiar with the features of the motor to maximize the capabilities this product offers. Steering Steering Lower Unit Lower Unit Housing Housing Trim Housing Trim Housing Coil Cord Coil Cord Motor Ramps Motor Ramps Indicator Panel Indicator Panel...
  • Page 59 Stowed SYSTEM STATUS SYSTEM STATUS SYSTEM STATUS Power Power Status LED will not be illuminated. The Ulterra QUEST has an Button Button SYSTEM STATUS auto-shutoff and will automatically power off after 90 minutes of inactivity in the stowed position. LED Patterns STOWED •...
  • Page 60 BATTERY MONITORING Minn Kota understands the importance of maximizing time on the water to gain a competitive edge. Minn Kota QUEST Series trolling motors provide real-time battery and runtime readings of the trolling motor battery system when connected to a compatible Humminbird fish finder.
  • Page 61 STOWING WITH THE WIRELESS REMOTE Press the Steer Right button to select Deploy. The motor will automatically deploy. WARNING As soon as Deploy is selected, the motor will automatically deploy. Be sure that the motor is clear from obstructions and has a clear path of travel. The Prop is disabled while the motor is stowing or deploying to prevent accidental contact with the rotating Prop.
  • Page 62 STOWING WITH THE WIRELESS REMOTE Use the Speed Up or Speed Down button to find Stow. Use the Steer Right button to select it. Once selected, the motor will automatically stow, and the Prop will be disabled. WARNING As soon as Stow is selected, the motor will automatically stow.
  • Page 63 DEPLOYING WITH THE OBN APP STOWING AND DEPLOYING WITH THE ONE-BOAT NETWORK (OBN) APP Deploying with the OBN App Open the One-Boat Network (OBN) app on the mobile device. Make sure the mobile device is paired with the trolling motor. From the OBN home screen, tap the Motor menu.
  • Page 64 STOWING WITH THE OBN APP Stowing with the OBN App Open the One-Boat Network (OBN) app on the mobile device. Make sure the mobile device is paired with the trolling motor. From the OBN home screen, tap the Motor menu. The Motor menu opens the Motor home screen.
  • Page 65 STOWING AND DEPLOYING WITH THE FOOT PEDAL STOWING AND DEPLOYING WITH THE FOOT PEDAL On the Foot Pedal, press the MODE button so Indicator Indicator that the white MODE LED on the Indicator Panel Panel MODE Panel is illuminated, putting the Foot Pedal in MODE MODE Deployment Mode.
  • Page 66 ADJUSTING THE DEPTH (TRIM) OF THE ULTERRA QUEST ADJUSTING THE DEPTH (TRIM) OF THE ULTERRA QUEST Once the boat is on the water, it may be necessary to adjust the trim of the Lower Unit up or down to achieve an optimum depth for motor performance.
  • Page 67 TRIMMING WITH THE WIRELESS REMOTE Once in Ulterra Menu, use the Speed Up Speed Down button to select Trim Up or Trim Down. Trimming up will raise the motor and trimming down will lower the motor. Press and hold the Steer Right button to select it.
  • Page 68 TRIMMING WITH THE OBN APP Trimming with the OBN App Open the One-Boat Network (OBN) app on the mobile device. Make sure the mobile device is paired with the trolling motor. From the OBN home screen, tap the Motor menu. The Motor menu opens the Motor home screen.
  • Page 69 TRIMMING WITH THE FOOT PEDAL Trimming with the Foot Pedal On the Foot Pedal, press the MODE button so Indicator Indicator that the white MODE LED on the Indicator Panel Panel MODE Panel is illuminated, putting the Foot Pedal in MODE MODE Deployment Mode.
  • Page 70 MOTOR ADJUSTMENTS MOTOR ADJUSTMENTS Adjusting the Lift Belt The Lift Belt assists in trimming the Lower Unit up and down. Slack may appear periodically in the Lift Belt along the Shaft of the motor. To maintain tension on the Lift Belt, the screw that holds tension on the Lift Belt may occasionally require small adjustments. Place the motor in the stowed position.
  • Page 71 MOTOR ADJUSTMENTS Greasing the Tilt Shaft and Latch Pin To maintain optimum performance of the Ulterra QUEST, it is recommended that the Tilt Shaft and Latch Pin be greased every season. Minn Kota recommends using a marine-grade grease. Deploy the motor. Once deployed, turn the motor off.
  • Page 72 MOTOR ADJUSTMENTS Installing an External Transducer An external transducer is not included with your trolling motor. An external transducer can be installed onto motors that have Advanced GPS Navigation. Installing an external transducer is not recommended for motors with Built-in MEGA Side Imaging. Mount the External Transducer according to directions provided with the transducer.
  • Page 73 After completing both steps of the Manual Stow Bypass, return to shore and resolve the error or take the motor Scan to find to a Minn Kota authorized service provider. Once the error has been resolved, see the “Manual Stow Bypass additional help.
  • Page 74 MANUAL STOW BYPASS WARNING CAUTION While servicing the motor, stay clear of pinch points and do not Once the motor has been manually stowed, it will be non- wear loose-fitting clothing or loose-fitting jewelry. operational until it is manually recovered. NOTICE: In the event of a Manual Stow Bypass, the Quick Release Pin is removed from the Steering Housing.
  • Page 75 Trim Release Lower Unit Lower Unit Lever Lever NOTICE: Once on shore, take the motor to an Authorized Service Provider or use the Minn Kota Help Center at minnkota.johnsonoutdoors.com. Motor Motor Ramp Ramp ©2025 Johnson Outdoors Marine Electronics, Inc. minnkota.johnsonoutdoors.com | 75...
  • Page 76 MANUAL STOW BYPASS RECOVERY MANUAL STOW BYPASS RECOVERY After completing a Manual Stow Bypass, most motor functions are disabled, and an error will display on the Wireless Remote. If the error that required an emergency stow is resolved, motor operation can be restored through a Manual Stow Bypass Recovery procedure. To recover from a Manual Stow Bypass, the motor must be manually deployed and the Quick Release Pin reinstalled.
  • Page 77 Release Pin Release Pin NOTICE: If the motor is nonfunctional after restoring Retaining Retaining Handle Handle power and reinstalling the Quick Release Pin, contact Ball Ball a Minn Kota authorized service provider. ©2025 Johnson Outdoors Marine Electronics, Inc. minnkota.johnsonoutdoors.com | 77...
  • Page 78 CONTROLLING SPEED & STEERING WITH THE FOOT PEDAL The Foot Pedal is used to operate the Ulterra QUEST trolling motor. The controls on the Foot Pedal are easy to use. The motor can also be controlled with the Advanced GPS Navigation Wireless Remote or One-Boat Network app. Refer to the associated accessory manual for instructions.
  • Page 79 FOOT PEDAL OPERATION WARNING You are responsible for the safe and prudent operation of your vessel. We have designed the Foot Pedal to be an accurate and reliable tool that will enhance boat operation and improve your ability to catch fish. This product does not relieve you from the responsibility for the safe operation of your boat.
  • Page 80 FOOT PEDAL OPERATION Stow/Deploy The Stow/Deploy button is located at the bottom of the Foot WARNING Pedal. It functions to stow and deploy the motor when the Foot Pedal is operating in Deployment Mode. The white MODE When stowing or deploying the motor, keep fingers clear of all MODE on the Indicator Panel will illuminate when in Deployment Mode.
  • Page 81 FOOT PEDAL OPERATION Spot-Lock The Spot-Lock button is located on the bottom-right side of the Foot Pedal and is labeled with an anchor symbol. When the Spot-Lock button is pressed, the location of the motor is recorded to a temporary Spot-Lock location. To engage Spot-Lock, press the Spot-Lock button.
  • Page 82 AutoPilot. There are distinct differences between the two AutoPilot Modes and how they control the boat. Both Locked Heading and Locked Course AutoPilot are valuable tools anglers can use for accurate and precise bait presentation. Minn Kota highly recommends getting on the water and trying both Locked Heading AutoPilot and Locked Course AutoPilot in various fishing situations and applications.
  • Page 83 AUTOPILOT CAUTION This unit uses a magnetic compass to detect the direction of travel. The compass can be adversely affected by magnets or large, ferrous metal objects near (within 12” of) the trolling motor control head. Obstructions on the Prop may cause excessive vibration of the motor control head. This vibration can cause the compass to wander and erratic steering to occur.
  • Page 84 WAYPOINTS WAYPOINTS AND THE ONE-BOAT NETWORK Waypoints are saved latitude/longitude positions. They mark a position of interest, such as favorite fishing areas, structures, or marker buoys. Waypoints work similarly to Spot-Locks. If the One-Boat Network (OBN) button on the Foot Pedal is customized to the Waypoint function, the button will mark WayPoints in the Advanced GPS Navigation System when pressed.
  • Page 85 WAYPOINTS Mark a WayPoint While the trolling motor is running, mark a Waypoint by pressing the One-Boat Network button. The red One-Boat Network LED on the Indicator Panel ONE-BOAT NETWORK will briefly illuminate and then turn off to indicate a One-Boat One-Boat Waypoint is marked.
  • Page 86 The One-Boat Network allows for control of a Shallow Water Anchor (SWA) when one is paired with the Advanced GPS Navigation Bluetooth Network. SWAs that can pair with the Advanced GPS Navigation system include the Minn Kota Bluetooth enabled Raptor and Talon.
  • Page 87 SHALLOW WATER ANCHOR Deploy the Shallow Water Anchor Check to make sure that the Shallow Water Anchor (Raptor/Talon) is powered “on” and paired to the Indicator Indicator Panel Panel trolling motor. Locate the One-Boat Network button located on One-Boat One-Boat the Foot Pedal and double-press it to deploy the Network Network...
  • Page 88 SPOT-LOCK HOW SPOT-LOCK WORKS Spot-Lock uses a single point of reference that is recorded when the Spot-Lock button is pressed. The reference point is a set of GPS coordinates captured at the location of the trolling motor at the moment the button is pressed. This point is recorded and can be saved into one of the Spot-Lock memory locations.
  • Page 89 SPOT-LOCK Toggle Spot-Lock On/Off While the motor is running, Spot-Lock can be turned on by pressing the Spot-Lock button located on the Foot Pedal. The yellow SPOT-LOCK LED on SPOT-LOCK the Indicator Panel is illuminated when Spot-Lock is engaged. NOTICE: In the default Audio Mode, a tone is emitted from the Control Head when Spot-Lock is engaged.
  • Page 90 SERVICE & MAINTENANCE PROP REPLACEMENT TOOLS AND RESOURCES REQUIRED • 9/16” Deep Well Socket INSTALLATION CAUTION Prop Prop Washer Washer Disconnect the motor from all sources of power before Prop Nut Prop Nut beginning any prop work or maintenance. Hold the Prop and loosen the Prop Nut with a 9/16" Prop Prop Deep Well Socket.
  • Page 91 GENERAL MAINTENANCE GENERAL MAINTENANCE • After use, the entire motor should be rinsed with freshwater. This series of motor is not equipped for saltwater exposure. • The composite shaft requires periodic cleaning and lubrication for proper retraction and deployment. A coating of an aqueous-based silicone spray will improve operation.
  • Page 92 To conduct a Trim Reset, press the Power button on the Indicator Panel three times consecutively within a two-second period. b. The blue System Status LED and orange Stowed LED will flash continuously while the Ulterra QUEST goes through an automated sequence.
  • Page 93 Authorized Service Centers Minn Kota has over 800 authorized service centers in the United States and Canada where you can purchase parts or get your products repaired. Please visit our website to locate a service center in your area.
  • Page 94 Minn Kota motors are not subject to the disposal regulations EAG-VO (electric devices directive) that implements the WEEE directive. Nevertheless never dispose of your Minn Kota motor in a garbage bin but at the proper place of collection of your local town council.
  • Page 95 FCC COMPLIANCE FCC COMPLIANCE This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference that may be received, including interference that may cause undesired operation. Changes or modifi cations not expressly approved by Johnson Outdoors Marine Electronics, Inc.
  • Page 96 ULTERRA QUEST - 90/115 THRUST - 24/36 VOLT - 45”/60”/72” SHAFT The parts diagram and parts list provide Minn Kota® WEEE compliance disassembly instructions. For more information about where you should dispose of your waste equipment for recycling and recovery and/or your European Union member state requirements, please contact your dealer or distributor from which your product was purchased.
  • Page 97 PARTS DIAGRAM & PARTS LIST Control Head Parts List Assembly Part # Description Notes Quantity 2774190 CONTROLLER KIT 4.0 QUEST FW *DUAL SPECTRUM CHIRP* 2774191 CONTRLLR KT 4.0 QUEST FW w/GND *MEGA SIDE IMAGING* 2770247 CTRL BOX COVER QUEST FW 411690-1 TROLLING MOTOR WIRELESS REMOTE 2992371...
  • Page 98 PARTS DIAGRAM & PARTS LIST Item Part # Description Notes Quantity 2201721 WASHER - #10 SAE.], SS 2203411 SCREW-#10-24,SHCS,SS, RIE 4606 2202800 BLOCK-BELT 2200800 BELT-RACK, LOWER 2202335 PULLEY, BELY TOP 2202635 PIN-DOWEL, 1/4" OD SS 2206304 TIE WRAP, REUSABLE RED, 6" 2207124 MANUAL, ULTERRA 2207125...
  • Page 99 PARTS DIAGRAM & PARTS LIST ULTERRA QUEST MOTOR 24/36 Volt 90/115 Thrust Motor Parts Diagram Z AA ©2025 Johnson Outdoors Marine Electronics, Inc. minnkota.johnsonoutdoors.com | 99...
  • Page 100 PARTS DIAGRAM & PARTS LIST 24/36 Volt 90/115lb Thrust Motor Parts List Assembly Part # Description Notes Quantity 2441060 MTR ASY 85/115#DSC FW BLK *45"* *DUAL SPECTRUM CHIRP* 2441062 MTR ASY 85/115#DSC FW BLK *60"* *DUAL SPECTRUM CHIRP* 2441063 MTR ASY 90/115#DSC FW BLK *72"* *DUAL SPECTRUM CHIRP* 2441080 MTR ASY 85/115#MSI FW BLK...
  • Page 101 PARTS DIAGRAM & PARTS LIST Item Part # Description Notes Quantity 195-030 CABLE-COM 22GA TWST PAIR 62.38 *45"* 195-032 CABLE-COM 22GA TWST PAIR 76.25 *60"* 195-033 CABLE-COM 22 GA TWST PAIRS *72"* ✖ LEADWIRE RED 8 AWG 60 1/8 *45"* *SEE ASSEMBLY GG* ✖...
  • Page 102 PARTS DIAGRAM & PARTS LIST ULTERRA QUEST STEERING HOUSING Steering Housing Parts Diagram 102 | minnkota.johnsonoutdoors.com ©2025 Johnson Outdoors Marine Electronics, Inc.
  • Page 103 PARTS DIAGRAM & PARTS LIST Steering Housing Parts List Assembly Part # Description Notes Quantity 2996530 ASM, STEERING, FW, BLK Item Part # Description Notes Quantity ✖ PLATE, MOTOR MNT, STEERING ✖ SEAL,ID 12MM, OD 20MM, T 5MM ✖ MOTOR, 24 VDC, 1:130 GEARBOX ✖...
  • Page 104 PARTS DIAGRAM & PARTS LIST Item Part # Description Quantity ✖ VENT FILTER, STEERING HOUSING ✖ MNT, SENSOR, LATCH QRP ✖ SCREW-#4-24 X 1/4 PHCR SS TY B ✖ SCREW-#6-32 X .625 PPH SS ✖ SEAL, UMBRELLA ✖ SCREW-3/8-16 X 1.75 SHCS SSTL ✖...
  • Page 105 PARTS DIAGRAM & PARTS LIST ULTERRA QUEST TRIM HOUSING Trim Housing Parts Diagram 388 386 ©2025 Johnson Outdoors Marine Electronics, Inc. minnkota.johnsonoutdoors.com | 105...
  • Page 106 PARTS DIAGRAM & PARTS LIST Trim Housing Parts List Assembly Part # Description Notes Quantity 2997851 ASM, TRIM MOD,FW, BLK,45" *45"* 2997850 ASM, TRIM MOD,FW, BLK,60" *60"* 2997852 ASM, TRIM MOD,FW, BLK,72" *72”* Item Part # Description Notes Quantity ✖ HOUSING-MID,TRIM, SW, BLK ✖...
  • Page 107 PARTS DIAGRAM & PARTS LIST Item Part # Description Notes Quantity 2201736 WASHER, PLASTIC,.265 ID, .5 OD 2202610 PIN, BELT PULLEY 2204635 SEAL,1/16 O-RING CORD,SILICONE 2201521 COLLAR, OUTPUT TUBE, MACH ✖ BUSHING, FLANGED, 1.0 SHAFT 2200115 LEVER,TRIM RELEASE, MACH. 2202670 PIN, KNURL, HEAD, 4MM X 8MM 2202639 PIN-DOWEL, 1/4 X 1.75 LG...
  • Page 108 PARTS DIAGRAM & PARTS LIST ULTERRA QUEST FOOT PEDAL Foot Pedal Parts Diagram 108 | minnkota.johnsonoutdoors.com ©2025 Johnson Outdoors Marine Electronics, Inc.
  • Page 109 PARTS DIAGRAM & PARTS LIST Foot Pedal Parts List Assembly Part # Description Quantity 2994742 FT PED ASM, ULTERRA QUEST 2994859 BAG ASY-TERROVA/V2,RUB.BUMPERS Item Part # Description Quantity 2204501 BASE PLATE, FOOT PEDAL ✖ PCB ASM, FT PED,ULTERRA 2373440 SCREW-#4-24 X 1/4 PHCR SS TY B...
  • Page 110 PARTS DIAGRAM & PARTS LIST ULTERRA QUEST MOUNT Mount Parts Diagram 110 | minnkota.johnsonoutdoors.com ©2025 Johnson Outdoors Marine Electronics, Inc.
  • Page 111 PARTS DIAGRAM & PARTS LIST Mount Parts List Assembly Part # Description Notes Quantity 2994948 BAG, ASM, INSTINCT, T3 BL HDW Item Part # Description Notes Quantity 2372103 SCREW-#6 X .375 PLASTITE SS 2201906 BASE, EXTRUSION, MACHINED FW 2205106 PAD, DEAD STOP, STOW 2373434 SCREW-1/4-20 X 3/4 SS PPMS 2205518...
  • Page 112 PARTS DIAGRAM & PARTS LIST Item Part # Description Notes Quantity 2373487 SCREW-#8-32 X 3/4" PPH MACH SS 2205412 SHRINK TUBE.75 ID x 2" 2202623 PIN,QCK REL. 5/16 x 3 1/2 2052510 CABLE CLAMP, 3/16", NYLON 2040721 CLAMP-CABLE 3/8" 2052511 CABLE CLAMP,1/4"...
  • Page 113 NOTES ©2025 Johnson Outdoors Marine Electronics, Inc. minnkota.johnsonoutdoors.com | 113...
  • Page 114 Stop buying new batteries and start taking care of the ones you’ve got. Many chargers can actually damage your battery over time – creating shorter run times and shorter overall life. Digitally controlled Minn Kota chargers are designed to provide the fastest charge that protect and extend battery life.
