Product Information
respective Controller. Refer to the AXR-NWS NetWave Server instruction manual for more
information.
The 2-way Viewpoint communication uses frequencies from 2.402 GHz to 2.478 GHz
in 1 MHz steps. This results in 76 frequencies. All 16 Group IDs utilize all 76
frequencies. Changing Group IDs basically changes the hopping pattern sequence.

Specifications

The following table lists the specifications for the VPT-CP and VPN-CP.
Specifications
Dimensions (HWD):
Weight:
VPT-CP
VPN-CP
Power:
VPA-BP (battery)
Power supply
Power Consumption:
Operating Frequency:
RF (VPT-CP)
IR (VPT-CP)
RF (VPN-CP)
Buttons:
Display:
Assignable Devices:
VPT-CP
ViewPoint RF
AMX IR
IR other than AMX's
VPN-CP
Device ID
Group ID
ViewPoint
IR
Cables:
External power cable
Programming cable
Connector Ports:
External power
Programming
2
5.99" x 8.75" x 2.78" (15.21 cm x 11.30 cm x 5.08 cm)
2.46 lbs. (1.11 kg) with battery, 1.97 lbs. (0.89 kg) without battery
2.48 lbs. (1.12 kg) with battery, 2.01 lbs. (0.91 kg) without battery
• 7.2 VDC, 6-cell NiMH (nickel metal hydride) rechargeable battery,
3.7 Ah minimum
• VPT-CP: 5 continuous hours with full back lighting
• VPN-CP: 5 continuous hours
13.5 VDC @ 2.8 A
1.3 A @ 13.5 VDC
418 MHz standard (other frequencies available upon request), one-way RF
transmission
38 KHz or 455 KHz, one-way IR transmission
2.4 GHz two-way digital spread spectrum, two-way digital spread spectrum RF
or one-way OM (other manufacturer's) IR signals
Four external programmable push buttons
6" (153.9 mm) color-passive LCD, 256 colors - 320 x 240 (HV) pixel
Device 1
Device 1
Device 2, 3, and/or 4
0 - 255
0 - 15
Device 1, 2, 3, and/or 4
Device 2, 3, and/or 4
6 mm coax male power cable - connects from an external 13.5 VDC power
supply (included)
3-wire, 2.5 mm stereo conductor cable
6 mm coax female power jack - connects to external 13.5 VDC power supply
2.5 mm stereo female conductor jack
ViewPoint Wireless Touch Panels
