Power Supply
connector
FIG. 10 Rear view of the docking station
The new ViewPort design allows simultaneous charging of both the installed battery
and a mounted ViewPoint panel (assuming the use of a PSN2.8 power supply).
The RED LED does not turn Off when the ViewPoint is attached because the
ViewPort is still charging the installed battery AND is still supplying voltage to the
ViewPoint contacts.
It is recommended that you do not attempt to replace the internal Lithium battery.
THis battery has a lifespan of up to 5 years.
If there is a problem with this piece, please contact your AMX sales representative to
make arrangements to ship your panel back to the factory for battery replacement.
ViewPoint Wireless Touch Panels
Retaining
ears (tabs)
Rear view
VPA-DS ViewPort Docking Station
51
