Programming

Shorthand Send Commands

The shorthand commands operate control equipment just like standard Send_Commands still used
in a wide variety of AMX products. However, shorthand commands are smaller byte-for-byte, and
are processed more efficiently. The table below lists the shorthand Send_Commands you can use
with the ViewPoint touch panels. The shorthand command data is 1-byte, non-ASCII format except
for pages, passwords, text, and bitmap names.
Shorthand Send_Commands
@CBF
Sets the OFF
feedback border
color to the speci-
fied color.
@CBN
Sets the ON feed-
back border color
to the specified
color.
@CFF
Sets the OFF
feedback fill color
to the specified
color.
@CFN
Sets the ON feed-
back fill color to
the specified
color.
24
This works only if the specified background color is not the same as the current color.
Syntax:
"'@CBF',<variable text address>,<color_number>"
Variables:
variable text address = 1 - 255
color number = See the Colors and Programming Numbers table on page 23.
Example:
SEND_COMMAND TP,"'@CBF',1,0"
Sets the OFF feedback border color to Red for the variable text button 1.
This works only if the specified background color is not the same as the current color.
Syntax:
"'@CBN',<variable text address>,<color_number>"
Variables:
variable text address = 1 - 255
color number = See the Colors and Programming Numbers table on page 23.
Example:
SEND_COMMAND TP,"'@CBN',2,78"
Sets the ON feedback border color to Grey for variable text button 2.
This only works if the specified background color is not the same as the current color.
Syntax:
"'@CFF',<variable text address>,<color_number>"
Variables:
variable text address = 1 - 255
color number = See the Colors and Programming Numbers table on page 23.
Example:
SEND_COMMAND TP,"'@CFF',1,72"
Sets the OFF feedback fill color to White for variable text button 1.
This only works if the specified background color is not the same as the current color.
Syntax:
"'@CFN',<variable text address>,<color_number>"
Variables:
variable text address = 1 - 255
color number = See the Colors and Programming Numbers table on page 23.
Example:
SEND_COMMAND TP,"'@CFN',1,30"
Sets the ON feedback fill color to Aqua for variable text button 1.
