Connecting Power

Connecting to the AC-Input Power Supply

The device is designed to work with TN power systems. Statement 19
Warning
Step 1 At the rear of the Cisco uBR7200 series universal broadband router, ensure that the power switch on the
power supply is in the OFF (0) position.
Step 2 Slide the cable-retention clip to the left, away from the AC receptacle, and plug in the power cable.
Step 3 Secure the cable in the power supply AC receptacle by sliding the cable-retention clip to the right until
it fits around the connector. The cable-retention clip provides strain relief for the AC power cable. For
additional AC power cable strain relief, secure the cable to the power supply handle by inserting a nylon
cable tie through the hole in the handle and around the cable. See
Figure 3-16
receptacle
Captive
installation
Plug the AC power supply cable into the AC power source.
Step 4
Repeat Step 1 through Step 4 for the second power supply (if present).
Step 5
This completes the procedure for connecting AC-input power. Proceed to the
Cisco uBR7200 Series Router" section on page
Cisco uBR7200 Series Universal Broadband Router Hardware Installation Guide
3-22
Connecting AC-Input Power
Power
screw
AC power cable
Chapter 3
Cable-retention clip
3-25.
Installing the Cisco uBR7200 Series Router
Figure 3-16.
Power
switch
Handle
"Powering On the
OL-5421-03
