T-Rex 25211 Manual

25211-25211B
2015 GMC Sierra
2500/3500 HD
TOOLS REQUIRED:
Phillips Screwdriver
Drill
NOTE:
- We recommend painting all areas exposed behind grille black
prior to installing for best results.
PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE INSTALLATION. Auto makers offer varied models
to each vehicle and occasionally manufacture more than one body style of the same model. To assure your part is correct;
our tech department can be contacted at tech@trexbillet.com to verify fitment or assist with tech questions. All other inquires
can be directed to info@trexbillet.com. In the event you do not have internet access please call 1-800-287-5900.
Step 1
Attach the two U Nuts to each side of the mounting
brackets. (Fig 1)
Step 2
Place the bracket on the inside of the bumper opening.
Drill a 3/16" hole thru the plastic using the bracket as a
guide. Secure on the back of the plastic with the flat nut
and screw bract into place with the #10 screws. (Fig 2)
2015 GMC Sierra 2500/ 3500 HD
Billet Bumper Grille Insert
PARTS LIST
2- Mounting bracket hooks
4- #8 u-nuts
4- #8 1" 6 Head screws
2- 3/4" self drilling screw
2- #8 flat nut
Continued on page 2
25211-25211B
Fig 1
Fig 2
2015 GMC Sierra
2500/3500 HD
page 1
