Active or Inactive Diagnostic Trouble Codes:
See Page 44 for Appendix A: J1587 SID and FMI Codes and Their Bendix Blink Code Equivalents
INDEX
How to interpret the first digit of messages received
when Active or Inactive Diagnostic Trouble Code Mode
1st
Blink
Go Here for Troubleshooting Tests
Code
Number
1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No faults (1,1)
2 . . . . . . . . . . . . . . . . . Wheel Speed Sensors - page 22
3 . . . . . . . . . . . . . . . . . Wheel Speed Sensors - page 22
4 . . . . . . . . . . . . . . . . . Wheel Speed Sensors - page 22
5 . . . . . . . . . . . . . . . . . Wheel Speed Sensors - page 22
6 . . . . . . . . . . . . . . . . . . . . . . . . Power Supply - page 27
7 . . . . . . . . . . . . . .Pressure Modulator Valves - page 24
8 . . . . . . . . . . . . . .Pressure Modulator Valves - page 24
9 . . . . . . . . . . . . . .Pressure Modulator Valves - page 24
10 . . . . . . . . . . . . .Pressure Modulator Valves - page 24
11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . J1939 - page 28
12 . . . . . . . . . . . . . . . . . . . Miscellaneous - pages 30-31
13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ECU - page 29
14 . . . . . . . . . . . . . . . . Wheel Speed Sensors - page 22
15 . . . . . . . . . . . . . . . . Wheel Speed Sensors - page 22
16 . . . . . . . . . . . . .Pressure Modulator Valves - page 24
17 . . . . . . . . . . . . .Pressure Modulator Valves - page 24
18 . . . . . . . . Drive Axle Traction Control Valve - page 26
19 . . . . . . . Steer Axle Traction Control Valve - page 26
20 . . . . . . . . Trailer Pressure Modulator Valve - page 24
21 . . . . . . . . . . . . .Steering Angle Sensor - pages 33-33
22 . . . . . . . . . . . . . . . . .Yaw Rate Sensor - pages 34-35
23 . . . . . . . . . . . . Lateral Acceleration Sensor - page 36
24 . . . . . . . . . . Brake Demand/Load Sensors - page 37
Example: For a message sequence of:
3, 2 12, 4
For the first sequence go to page 22 and
for the second sequence go to page 30.
