Alarm Lock PDL 3500 Datasheet

AUDIT TRAIL ACCESS OPTIONS

AL-IR1 Infrared Printer:

AL-DTMII Data Transfer Module:

Prints the event log and Module used to transfer program data
user code with hand-held from the PC to the lock and receive Audit
convenience. Trail from the lock. Can transfer program

DL-WINDOWS SOFTWARE: Version 2.92 or higher

Windows-format software used to create programming, manager users
and schedules, receive Audit Trail from lock, program
the lock using PC or laptop, program the AL-DTMII to
program multiple locks and configure the AL-DTMII to
transfer data.
DL-WINDOWS
Version 2.5.3
ALARM LOCK SYSTEMS INC.
A Division of the NAPCOSecurity Group
345 Bayview Avenue, Amityville, NY 11701
1-800-ALA-LOCK• (631) 789-4871 • www.alarmlock.com
MX993
AL-PRE:
Enables instant, automatic enrollment of
(just tap the prox Card/fob device to the unit's faceplate to enroll)!
Supports all Prox Cards and Prox Keyfobs (supported by PDL5000)
Simultaneous card enrollment, downloading or lock polling – all on just one serial
port. Replaces AL-PCI. 9V Battery operation (6 mos. to 1 year, typical)
Left-hand (LH)

MORTISE LOCK ORDERING INFORMATION

Use Trilogy
PDL3500L
PDL 35 00 DB R /26D EX
Model & Series:
OUTSIDE
PDL35 = Trilogy Prox Mortise Series
Left-hand
Trim:
Reverse (LHR)
00 = Standard Lever
Use Trilogy
75 = Regal Curved Lever
(U.S. Option Only)
PDL3500R
Lock Body:
DB = Dead Bolt
Right-hand (RH)
CR = Class Room
(U.S. Only)
Use Trilogy Handing:
PDL3500R Your Door - Order -
Left Handed L
Right Handed R
Left Hand Reverse Bevel
Right Hand Reverse Bevel
OUTSIDE
(Note: Trim is non-handed. Lock body is field reversible.)
Right-hand
Reverse (RHR)
Use Trilogy U L
PDL3500L
®
ALARM LOCK SYSTEMS, Inc. • A Division of the NAPCO Security Group
345 Bayview Avenue • Amityville, NY • 11701 • USA
1-800-ALA-LOCK • 631-789-4871 • Fax: 631-789-3383 • www.alarmlock.com
Trilogy ® is a registered trademark of Alarm Lock. ©Alarm Lock, 2002 Specifications subject to change. Patents Pending.
data for up to 48 locks.
Prox Card Reader/Enroller
Prox Cards into DL-Windows
Finish:
/3 = US3 Polished Brass
/26 = US26 Polished Chrome
/26D= US26D Satin Chrome
/5 = US5 Antique Brass
/10B = Duronodic
European Model Suffix
Not Used For U.S. Models
*Note: Standard Lever for U.S. Models is
Straight Lever. Standard Lever for
European Models is Curved Tubular Lever
R
L
ALA168
PDL3500 Series
Feature-Rich, Standalone. Proximity/ Digital Locks
With Audit Trail Feature
