ROSE DISPLAYS ECONOFRAME WITH WINDOW MOUNTS Instruction Sheet

EconoFrame™

Parts

Instructions for Hanging

Step 1

Locate the two split rails and the
solid rail that is the same length as
the split rails.
Insert corner brackets into side
EconoFrame rails. Insert two corner
brackets into each end of the solid
side rail. Insert one corner bracket
into each end of each split side rail.
Fig. 1 & Fig. 2
Note: Tension tabs on corner
brackets face towards outside of
frame.

Step 2

Slide the Window Mounts
into the top rail of the EconoFrame
rail. Fig. 3

Step 3

Finish assembling frame following the
sequence in Fig. 4.

Step 4

Insert poster. Fig 5
Note: For best performance when
first applied and occasionally
thereafter, press the middle of the
cup (on the cap) to "burp" extra
air out.
The EconoFrame™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSEconoFrameWindowMounts
Incept-12.04.02
Corner EconoFrame
brackets Rails 12EF-100
Instruction Sheet
EconoFrame
Split Rails
Figure 1
Figure 3
Figure 4
Window Mounts
20-0038
Figure 2
Figure 5
35 Congress Street, Salem, MA 01970
Tel# 1- 800 631-9707 Fax# 1-800-560-2890
e-mail:signware@rosedisplays.com
