EconoFrame
Instructions for Hanging
Insert corner brackets into split
rails and into rail opposite split
rail. Split rail side is made up of
two separate pieces. Fig. 1
Note: Corner bracket tension
tabs must face toward inside
of frame.
Squeeze sides of MultiClip
together. Fig. 2.
Find top rail of frame and align
the bottom rail of the MultiClip
with the top channel of the top
rail. Slide MultiClip into rail.
Fig. 3 Repeat steps 2 & 3 for
second MultiClip.
Assemble frame following steps in.
Fig. 4 sliding sides together in the
order shown.
Insert poster. Fig 5.
The EconoFrame™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSEconoFrameMC
Incept-8.5.02
TM
Corner
EconoFrame rails
brackets
Instruction Sheet
EconoFrame
12EF100
split rails
Figure 2
solid rail w/
4
3
solid rail
Figure 4
MultiClips
1UP-0101
Figure 1
Figure 3
Figure 5
35 Congress Street, Salem, MA 01970
Tel# 1- 800 631-9707 Fax# 1-800-560-2890
e-mail:signware@rosedisplays.com
