ROSE DISPLAYS ECONOFRAME WITH SLATWALL HANGER Instruction Sheet

EconoFrame

Parts

Instructions for Hanging

Step 1

Insert corner brackets into split rails
and into rail opposite split rail. Split
rail side is made up of two separate
pieces. Fig. 1
Note: Corner bracket tension tabs
must face toward inside of frame.

Step 2

Finish assembling frame as shown in
Fig. 2 by sliding sides together in the
order shown.

Step 3

Insert hangers into upper portion of
slatwall. Hangers will rest on lower
portion of slatwall. Fig. 3
Note: To ensure that the frame hangs
level use two hangers placed an equal
distance in from each side of the frame.

Step 4

Place the EconoFrame on the hangers
using the bottom channel of the top
Econo rail. Fig. 4

Step 5

Insert poster. Fig 5
The EconoFrame™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSEconoFrameSlatwall
Incept-3.6.02
TM
Corner
Brackets Rails 12EF-100
Instruction Sheet
EconoFrame EconoFrame
Split Rails
Figure 1
solid rail
solid rail
Figure 2
Figure 4
Slatwall
Hangers
06-6068
Figure 3
Figure 5
35 Congress Street, Salem, MA 01970
Tel# 1- 800 631-9707 Fax# 1-800-560-2890
e-mail:signware@rosedisplays.com
