ROSE DISPLAYS ANOQUICK WITH PEG AND MULTICLIPS Instruction Sheet

AnoQuick™ with Peg

Parts

AnoQuick

Instructions for Hanging

Instructions for Hanging

Step 1

When using AnoQuick to hang 1/8" Sintra or an
equally heavy substrate, have your printer punch
two 1/4" holes along the top and bottom edges of
print — or only the top if no bottom holder is
being used. Fig. 1
Note: Each hole must be centered 1/4" in from the
edge of the substrate.

Step 2

Push both parts of the peg together through each
of the punched holes. Fig. 2

Step 3

Install MultiClip in the top AnoQuick Holder.
Holding clip at slight angle, first insert one round
end, then press down on other round end and push
MultiClip into holder. Fig. 3
Note: For OneUp applications place the
MultiClip in the center of the AnoQuick Holder.
The AnoQuick is a registered trademark of Rose Displays, Ltd. Neither
the manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part # 02INSAnoQw/PegMCEndcap
Incept-8.15.02
12A300R
Instruction Sheet
Pegs
06-1920 1UP-0100
Figure 1
Figure 2
Figure 3
MultiClip End Caps
06-5525
35 Congress Street, Salem MA 01970
Tel# 1-800-631-9707 Fax# 1-800-560-2890
e-mail:signware@rosedisplays.com
